- Page 1 Basic Facial Chair/Table User Manual & Equipment www.skinact.com Toll Free: 1.800.418.0830 International: 818.834.6640 www.spaandequipment.com...
- Page 2 Spa and Equipment/SkinAct shall not be liable for incidental or consequential damages arising out of the furnishing, per- formance, or use of this document and the program material which it describes.
- Page 3 • If you have gone through the troubleshooting steps in this manual and an issue persists, please call Spa and Equip- ment/SkinAct for further assistance: 1(800)418-0830 • OPERATE AT YOUR OWN RISK AND USE COMMON SENSE: OWNER/OPERATOR IS RESPONSIBLE FOR HIS/HER OWN SAFETY AS WELL AS ANYONE NEAR OR ON THE UNIT.
- Page 4 Removing From The Box/Assembly • Please keep all original packaging materials. • TEAM LIFT: Make sure to have at least two people to lift and move the unit. • If you have a furniture dolly or a pallet jack, you can use one of those to help with moving the box.
- Page 5 Assembly • Take the two L-shaped rods and remove the wing nuts from the threaded ends. • Insert the L-shaped rods into their brackets on the bottom of the middle seat cushion. Make sure to insert from the outside as in the photo below. Arrows show insertion direction. •...
- Page 6 Assembly • Attach both wing nuts to the threaded ends of the L-shaped rods after the rods are in their holes on the frame. • Next take both U-shaped rods and remove the wing nuts. • Ensure the U-shaped rods face this direction. They will insert into their holes as in the photo below.
- Page 7 Assembly • Next take the shorter T-shaped rod to the foot rest section of the chair. • Remove the screw at the end of the shorter T-shaped rod. Do not lose the screw. • Insert the rod into the hole on the bracket on the frame (photo on next page).
- Page 8 Assembly • Undo the nuts and bolts on the two foot rest section brackets (1) & (2). • Then put the two ends of the T-shaped rod into the foot rest brackets and replace the nuts and bolts (3). • Tighten the nuts and bolts by hand. Then use two 10mm wrenches for a few turns (4).
- Page 9 Assembly • The foot rest section is done! The procedure is exactly the same for the long T-shaped bracket and the backrest sec- tion. Remember to turn the nuts and bolts a few turns with two 10mm wrenches. • Also, do not forget to put the screw back at the end of the long T-shaped rod.
- Page 10 Assembly • Next you can attach the table paper holder. This step is very simple. First, unscrew the screw on the short end. • Insert the table paper holder into its bracket and replace the screw on the short end. •...
- Page 11 Assembly • The last things to do are attach the head rest pillow and put the arm rests on. • For the arm rests, simply insert the rods of the arm rests into the holes and push the arm rests in until they are seated. •...
- Page 12 Measurements 73” 44.5” 30” P.12...
- Page 13 Measurements 24.5” 33” 20” 44.5” 28” 20.5” 24.5” P.13...
-
Page 14: Dimensions & Specifications
• Clean and sanitize the upholstery after each treatment. • Every six months, visually inspect the parts of the unit. If there are any abnormal noises or vibrations during operation, call Spaandequipment/SkinAct and describe the situation. P.14... -
Page 15: Troubleshooting
Troubleshooting Issue Possible Reason Solution Section(s) loose or Fasteners are loose Check all nuts, bolts, wobbly and screws. Tighten any loose ones. Broken part(s) Replace broken part(s). Warranty • This item has a 1-year limited warranty for malfunctions and manufacture defects only (parts, labor, and shipping not includ- ed).
