Rebotec 133 Series User Manual

BA-Nr.: 02.03.006/2021-09-A01
User Manual
Walking canes

1. Product description

1.1. Introduction
• The product described here is a medical device of risk class I ac-
cording to (EU) 2017/745 MDR.
• In this user manual, you will find information on the safe and proper
initial operation, use, maintenance and care of this product. Care-
fully read this user manual before using the device. Follow the safety
instructions and act accordingly.

2. Features

2.1. Intended purpose
• The product is used for light support and relief in case of restrictions
of the lower extremities.
• It allows the user to pursue their desire for mobility. There must be
sufficient musculature for safe use. Persons with sensory impair-
ments may not be able to use this item. The article does not impose
any special requirements on the education of the user.
Specification:
Designation
133...
Simplex
136...
Handy, left
138...
Handy, right
142...
Anatom, left
144...
Anatom, right
146...
Cane with Fischer handle, left
147...
Cane with Fischer handle, left
148...
Cane with Fisher handle, right
149...
Cane with Fisher handle, right
133.22.15 Simplex 150
133.22.16 Simplex 150, extra long
133.22.17 Simplex 175
142.22.15 Anatom 150, left
144.22.15 Anatom 150, right
142.22.16 Anatom 150, extra long, left
144.22.16 Anatom 150, extra long, right
142.22.17 Anatom 175, left
144.22.17 Anatom 175, right
121.20.10 Hemi, small, left
121.20.20 Hemi, small, right
121.10.10 Hemi, large, left
121.10.20 Hemi, large, right
a=Height adjustable / b=Continuous tube, can be shortened
c=Indoor & outdoor use
1=Standard clip / 2=Squeeze pressure / 3=Squeeze clip
4=Standard pressure
2.2. Conditions of use
• Temperature range: -10 °C to +35 °C; direct radiant heat on the
product must be avoided. Relative humidity: 40% to 85%. Outside
of these conditions, the product must only be used for a short time.
• The product is not suitable for use in swimming pools or saunas, as
surface discolouration and limitations of mechanical strength may
occur.
Read this User Manual
well as for future use and subsequent sales.
EN
3 125 kg c a
3 125 kg c a
3 125 kg c a
3 125 kg c a
3 125 kg c a
3 125 kg c a
- 125 kg c b
3 125 kg c a
- 125 kg c b
3 150 kg c a
3 150 kg c a
3 175 kg c a
3 150 kg c a
3 150 kg c a
3 150 kg c a
3 150 kg c a
3 175 kg c a
3 175 kg c a
3 100 kg c a
3 100 kg c a
3 100 kg c a
3 100 kg c a
before using the device for the first time
REBOTEC
®
Rehabilitationsmittel GmbH
DE-49610 Quakenbrück, Artlandstr. 57- 59
Telephone: +49 (0) 5431/9416-0
Fax: +49 (0) 5431/9416- 66
Web: www.rebotec.de
Email: info@rebotec.de
2.3. Storage & transport
• Temperature range: 5 °C to 25 °C; direct radiant heat on the product
must be avoided. Store the product in dry rooms with a humidity of
up to 65%.
2.4. Disposal
• Disposal and recycling of used products and packaging must be car-
ried out in accordance with currently valid regulations. Please con-
tact a disposal company for further information. The Infection Pro-
tection Act must be observed. Please observe any labels and infor-
mation on packaging material and act accordingly.
3. Symbols & nameplates
Symbol Meaning
Read the man-
ual!
Article number
Language
EN
Important infor-
mation!

4. Warranty

• For this product the manufacturer grants a warranty of 12 months.
Compliance with the general terms and conditions(
), as well as the intended use, are a basic prerequi-
tec.de/agbs
site. The statutory warranty provisions shall apply.
• Unauthorised modifications to this product will void the product's
conformity and the warranty.
4.1. Complaint
• Please contact us before returning the product. To reduce transport
damage, use the original packaging if possible.
• The Infection Protection Act must be complied with.
 Please make sure that the product does not pose a risk of infec-
tion when returned. Enclose an information sheet on safety with
the product. Costs may incur for returns that are not marked non-
objectionable.

5. Safety instructions

Please observe the following safety instructions:
•
Before using the device for the first time, the User
Manual must be read completely in order to avoid hazards
or damage caused by maloperation. Before each use, check the de-
vice for visible damage or deficiencies. In case of malfunctions or
damage of any kind, the device must not be used. Regularly check
the suction foot for damage and wear; replace if necessary.
• The walking aid must be placed on the floor as vertically as possible
when walking. Therefore, never position the walking aid too far away
from the body or forward in the walking direction. Grasp the handle
completely and firmly with one hand. If possible, have an assistant
accompany and support you so that they can catch you if you fall.
• The walking aid must not be used for any other purpose. Therefore,
only use them to support your ability to walk and not, for example,
as a stand-up aid, for levering, moving furniture or other objects. Do
not attach any objects (bag, pouch, etc.) to the walking aid.
• After a long period of disuse: Have the walking aid checked by qual-
ified personnel or a specialist dealer. Do not perform any unauthor-
ised mechanical modifications (product liability!). Do not expose the
and keep it at hand for the user as
Symbol Meaning
Year of manufacture
of Device
Manufacturer
Maximum user
weight in kg
Product complies
with (EU) 2017/745
MDR
www.rebo-
