FEATURES
16 outer handle and inner accent finish combinations
•
Outer handle finish and trim plate finish are always the
•
same
Trimplate, diverter control, temperature control
•
Brass construction
•
Must order correct rough valve to complete:
•
R1051 One Function
R1052 Two function Dedicated
R1053 Three function Dedicated
R1055 Three function shared
Includes ROHL logo on trim plate
•
Consult your local House of Rohl showroom for additional information and specifications. For complete warranty details and a list of showrooms, go to houseofrohl.com
ECLISSI™ 1/2" THERMOSTATIC TRIM WITH DIVERTER
EC12W2IW
COLORS/FINISHES
Faucet and handle finishes:
Polished Chrome
•
Satin Nickel
•
Matte Black*
•
Satin Gold*
•
Accent finish options:
Polished Chrome
•
Satin Nickel
•
Matte Black*
•
Satin Gold*
•
Ø8 5/8"
Ø2 3/4"
OFF
H
C
houseofrohl.com
WARRANTY
• Limited Lifetime
(*) 5-Year Limited Warranty
