03
EQUIPmENT IN-DEPTH
IR Emitter
Note: The effective range of the IR Emitter is 15 feet.
Back of IR Emitter
Front of IR Emitter
Thumbwheel to adjust
stereoscopic depth in game
VESA Stereo Cable Port
For DLP HDTVs, connect
VESA stereo cable to display.
Power indicator light
USB connection
to computer
Backlit 3D Vision
ON/OFF button
