06
CONFIGURATIONS
DLP HDTV Connection Diagram
PC
USB
Attention: Check your DLP's manual to see if there is a specific
HDMI port used to connect a PC to your HDTV. In addition, change
the input mode on the TV's menu to PC or Computer to ensure the
TV can process the video signal correctly.
IR Emitter
DVI
DLP
VESA 3-pin
stereo cable
3D Glasses
Emitter Port
DVI-to-HDMI Cable
USB Cable
HDMI Port
