Hold Delay

Hold delay defines how long the button must be held before it sends a button held event. Values range from 0-20
in 250ms increments (0-5 seconds). If set to 0, the hold delay doesn't send an event message.
The following table shows disable event bit definitions.
Byte
7:3
2
1
0

LED Configuration

To control LED behavior, use the LED configuration byte defined in the following table.
Only available in firmware v2.0 or newer.
Bits Description
7:3 Unused
2 Blinks LED after message ACK is received (confirmed messages only). 0 means LED blinks after a device
receives an ACK message ACK. 1 means LED doesn't blink after a receiving an ACK message ACK. Does
not apply to unconfirmed messages.
1 Blinks LED after a send. 0 means LED blinks after a send, 1 means LED doesn't blink after a send.
0 LED illuminates during button press. 0 means LED illuminates during button press, 1 means LED doesn't
illuminate during button press.
TM
Reveal Wireless Dual Push Button User Guide
Description
Disable button hold event. Set to disable, clear to enable.
Disable button released event. Set to disable, clear to enable.
Disable button pressed event. Set to disable, clear to enable.
Description
Unused
Disable button hold event. Set to disable, clear to enable.
Disable button released event. Set to disable, clear to enable.
Disable button pressed event. Set to disable, clear to enable.
For confirmed messages (acknowledgments), the blink occurs after the message is sent and
the ACK received.
For unconfirmed messages (no acknowledgments), the blink occurs after the message is
sent.
