SENSOR-SPECIFIC MESSAGES
Chapter 5 – Sensor-Specific Messages

Uplink Messages

The following table shows sensor specific uplink messages (sensor to web application). Uplink messages common
to all sensors are in the previous chapter.
Button ID
0x01
0x01
0x01
0x02
0x02
0x02
0x12
0x12
0x12
If buttons 1 and 2 are pressed within 0.25 seconds of each other, the device sends a message indicating they were
pressed at the same time (button ID 0x12 and event 0x00) and does not send messages for individual button
presses (button ID 0x01 and 0x02). After the buttons have been pressed together, when either button is released,
the device sends a released message (button ID 0x12 and event 0x01). If the buttons are pressed together and one
is released, the released button won't issue any new message until the other button is also released.

Downlink Messages

The following table shows sensor specific downlink messages (sensor to web application). Downlink messages
common to all sensors are in the Common Messages chapter.
Byte
0
1
2
3
4
5
6
Disable Event Bit Definitions
Bits
7:3
16
Event Payload Description
0x00 Button 1 pressed
0x01 Button 1 released
0x02 Button 1 held
0x00 Button 2 pressed
0x01 Button 2 released
0x02 Button 2 held
0x00 Buttons 1 and 2 pressed together
0x01 Buttons 1 and 2 released (either button released)
0x02 Buttons 1 and 2 held together
Description
Disable events for Button 1 only. (Refer to Disable Event Bit Definitions)
Hold delay for Button 1 only
Disable events for Button 2 only. (Refer to Disable Event Bit Definitions.)
Hold delay for Button 2 only
Disable events for 1-2 Button combination. (Refer to Disable Event Bit Definitions.)
Hold delay for 1-2 Button combination
LED configuration (version 2.0 or later),
Description
Unused
