USB-4301 User's Guide
Screw terminal – pins 1-28
The screw terminals on the bottom edge of the USB-4301 (pins 1 to 28) provide the following connections:
Two counter input connections (
Two counter gate connections (
Two counter output connections (
Eight digital input connections (
One pull-up/down control connection (
One oscillator output connection (
One interrupt input connection (
Two voltage output power connections (
Two ground connections (
Seven pins are reserved (
Screw terminal – pins 29-56
The screw terminals on the top edge of the USB-4301 (pins 29 to 56) provide the following connections:
Three counter input connections (
Three counter gate connections (
Three counter output connections (
Eight digital output connections (
One pull-up/down control connection (
Two ground connections (
Nine pins are reserved (
Pin 29
USB-4301
Pin 1
Figure 3. USB-4301 screw terminal pin numbering
and
)
INP1
INP2
and
)
GAT1
GAT2
and
OUT1
OUT2
to
)
DI0
DI7
)
DI CTL
)
OSC
)
INT
)
+5V
)
GND
). Do not connect signals to these pins.
RSVD
–
)
INP3
INP5
–
)
GAT3
GAT5
–
OUT3
OUT5
to
)
DO0
DO7
)
DI CTL
)
GND
). Do not connect signals to these pins.
RSVD
13
Pin 56
Pin 28
)
)
