Summary of Contents for Shindaiwa DH231
- Page 1 X7502863800 04/10 SHINDAIWA OWNER / OPERATOR’S MANUAL DH231 HEDGE TRIMMER WARNING! Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit.
-
Page 2: Table Of Contents
If you have questions regarding your series of hand-held power equipment, or if you do not understand something in this manual, contact Shindaiwa at the address printed on the back of this Manual. -
Page 3: General Safety Instructions
You must be physically and mentally fit to operate this unit safely. WARNING! Never make unauthorized attachment installations. Always use genuine Shindaiwa parts and accessories when repairing or maintaining this unit. WARNING! ■ Never smoke or light fires near the hedge trimmer. - Page 4 WARNING Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. • ALWAYS stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop before removing obstructions, clearing debris, or servicing unit. •...
-
Page 5: Operating The Hedge Trimmer
Never modify or disable any of the unit’s safety devices. Always use genuine Shindaiwa parts and accessories when repairing or maintaining this machine. Do not make unauthorized modifica- tions to the unit. -
Page 6: Unit Description
Throttle interlock Recoil starter On/Off Switch Air filter Fuel tank DH231-24 2-cycle, horizontal cylinder, air cooled 32mm x 28mm (1.26 X 1.10 in) 22.5cc (1.37 in 5.8 kg (12.8 lb) 1080 x 250 x 210 mm (42.52 x 9.84 x 8.27 in) 0.53 liter (18.0 oz.) -
Page 7: Emission Control
Mixing Fuel WARNING! Alternative fuels, such as E15 (15% ethanol), E-85 (85% ethanol) or any fuels not meeting Shindaiwa requirements are NOT approved for use in Shindaiwa gasoline engines. Use of alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement. -
Page 8: Filling The Fuel Tank
Handling Fuel DANGER Fuel is VERY flammable. Use extreme care when mixing, storing or handling or serious personal injury may result. • Use an approved fuel container. • DO NOT smoke near fuel. • DO NOT allow flames or sparks near fuel. •... -
Page 9: Starting The Engine
Make sure the cutters are clear of obstructions! Pull recoil starter handle upward Start the trimmer by pulling the starting handle rapidly outward IMPORTANT! If the engine fails to start after sev- eral attempts with the choke in the closed position, the engine may be flooded with fuel. -
Page 10: Stopping The Engine
Starting the engine (continued) When the motor starts... Open the choke by moving the choke lever backward (toward the fuel tank). If the engine does not continue to run, repeat the appropriate crank- ing procedures for a cold or warm engine. -
Page 11: Spark Plug
HAVE A BEARING ON THE OUTCOME OF A WARRANTY CLAIM. Fasteners Make sure nuts, bolts, and screws (except carburetor adjusting screws) are tight. Using non-standard replacement parts could invalidate your Shindaiwa warranty. Daily maintenance Daily maintenance Prior to each work day, perform the... -
Page 12: Hour Maintenance
Maintenance (continued) 10 - hour maintenance (more frequently in dusty conditions) Remove the air filter element, and wash the element in clean, neutral solvent or warm soapy water. Rinse the element thoroughly, and then squeeze dry before reassembly. CAUTION! Never operate the unit if the air filter assembly is damaged or missing or if the air filter element is soaked with water! - Page 13 Before reinstalling the filter, inspect the fuel line. If you discover dam- age or deterioration, the unit should be removed from service unitl it can be inspected by a Shindaiwa-trained service technician. CAUTION! Make sure you do not pierce the fuel line with the end of the hooked wire.
-
Page 14: Cutter Blade Adjustment
Remove two 4 mm screws from the top tail plate and remove tail plate. CAUTION! Operating the trimmer with worn or improperly adjusted cutters will reduce cutter performance and may also damage your machine. Never operate the machine with damaged or worn cutters. -
Page 15: Long Term Storage
(ASL) (96.0 kPa). To maintain proper engine operation and emission compliance above 1,100 feet ASL the carburetor may need to be adjusted by an authorized Shindaiwa service dealer. If the engine is adjusted for operation above 1,100 feet ASL, the carburetor must be re-adjusted when operating the engine below 1,100 feet ASL, otherwise severe engine damage may result. -
Page 16: Troubleshooting Guide
89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. ENGINE DOES NOT START Possible Cause Consult with an authorized Shindaiwa servicing dealer. Faulty recoil starter. Fluid in the crankcase. Internal damage. Tighten and re-test. - Page 17 89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. Consult with an authorized Shindaiwa servicing dealer. Consult with an authorized Shindaiwa servicing dealer.
- Page 18 Restart. Idle engine until cool. Adjust idle. Check Specifi cations page for correct idle speed. Consult with an authorized Shindaiwa servicing dealer. Adjust idle. Check Specifi cations page for correct idle speed.
-
Page 19: Warranty
The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as prescribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your Shindaiwa unit to an authorized Shindaiwa servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made. - Page 20 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/ tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the Shindaiwa oil label and covered in your operator’s manual.
- Page 21 Authorized Dealer within 100 miles, ECHO Inc. will pay to ship the unit to the nearest authorized dealer. If you have questions regarding your warranty coverage, you should contact ECHO Inc. at 1-800-673-1558, web site WWW.ECHO-USA.COM or contact Shindaiwa at 1-877-986- 7783, web site WWW.SHINDAIWA.COM.
- Page 22 NOTES...
- Page 23 NOTES...
-
Page 24: Servicing Information
Genuine Shindaiwa Parts and Assemblies for your Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number, Type and Serial Number of the unit with you. You can find these numbers on the engine. For future reference, write them in the space provided below.
