SHINDAIWA OWNER'S/OPERATOR'S MANUAL
HT230/DH230 HEDGE TRIMMER
WARNIG!
●
Read this manual and familiarize ypurself with its contens.
This machine is designed for trimming hedges.
●
●
Do not use this machine for other purposes.
●
Minimize the risk of injury to yourself and others.
●
Do not operate or service this machine unless you clearly
understand this manual.
●
Keep this manual accessible so that you can reread it
whenever you have a question about its use.
HT230
DH230
Advertisement
Table of Contents
Related Manuals for Shindaiwa HT230
Summary of Contents for Shindaiwa HT230
- Page 1 ENGLISH (Original instructions) FRANÇAIS (Inatructions originales) ITALIANO (Istruaioni originali) SHINDAIWA OWNER’S/OPERATOR’S MANUAL HT230/DH230 HEDGE TRIMMER HT230 DH230 WARNIG! ● Read this manual and familiarize ypurself with its contens. This machine is designed for trimming hedges. ● ● Do not use this machine for other purposes.
-
