Summary of Contents for Siemens EH8 BE15 Series
- Page 1 Induction hob with integrated ventila- tion system EH8..BE15. Information for Use Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Futher information and explanations are available online: 1.2 Intended use Table of contents Only a licensed professional may connect ap- Safety .............. 2 pliances without plugs. Damage caused by in- correct connection is not covered under the Avoiding material damage........ 5 warranty. - Page 3 Safety en 1.3 Restriction on user group WARNING ‒ Risk of poisoning! This appliance may be used by children aged Risk of poisoning from flue gases being 8 or over and by people who have reduced drawn back in. Room-air-dependent heat-pro- physical, sensory or mental abilities or inad- ducing appliances (e.g.
-
Page 4: Safety
en Safety Metal objects on the hob quickly become very WARNING ‒ Risk of fire! hot. Leaving fat or oil cooking on an unattended ▶ Never place metal objects (such as knives, hob can be dangerous and may lead to fires. forks, spoons and lids) on the hob. ▶... -
Page 5: Avoiding Material Damage
Avoiding material damage en When cooking in a bain marie, the hob and An appliance with a cracked or broken sur- cooking container could shatter due to over- face can cause cuts. ▶ Do not use the appliance if it has a cracked heating. -
Page 6: Suitable Cookware
en Suitable cookware Lift lids as infrequently as possible. Adjust the fan speed to the amount of steam pro- ¡ When you lift the lid, a lot of energy escapes. duced during cooking. ¡ The lower the fan speed, the less energy is con- Use a glass lid. -
Page 7: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance 5.1 Cooking with induction 5.4 The control panel In comparison to conventional hobs, induction techno- Individual details, such as colour and shape, may differ logy brings with it a series of changes and has a num- from the figure. -
Page 8: Operating Modes
en Operating modes 5.5 Distribution of the cooking zones Area Highest power level 18 cm dia- Power level 9 1800 W The specified power has been measured with the meter powerBoost 3100 W standard pots, which are described in IEC/EN 60335-2-6. The power may vary depending on the size of the cookware or cookware material. -
Page 9: Basic Operation
Basic operation en 8 Basic operation 8.1 Switching the hob on and off Within the next 10 seconds, select the required power level: ▶ Switch the hob on and off using the main switch . Touch to call up power level . ‒... - Page 10 en Hood control Boiled potatoes 4. - 5. 15 - 30 Fish, breaded and frozen, e.g. 6 - 7 8 - 15 fish fingers Pasta 6 - 7 6 - 10 Prawns and scampi 7 - 8 4 - 10 Stew 3. - 4. 120 - 180 Sautéing fresh vegetables and 7 - 8 10 - 20 mushrooms Soups...
-
Page 11: Powerboost
Time-setting options en 9.3 Automatic start for the ventilation You can find out how to change this setting in section → "Basic settings", Page 12. system Note: The run-on function only switches on if at least If you select a power level for a cooking zone, the auto- one cooking zone has been switched on for at least matic start switches on. -
Page 12: Childproof Lock
en Childproof lock 11.1 Activating the PowerBoost function 11.2 Deactivating the PowerBoost function Select the cooking zone. Select the cooking zone. Select power level and then touch the symbol. Touch the symbol. The display goes out and The ... -
Page 13: Cookware Test
Cookware test en Display Setting Value Power limitation - Switched off. Maximum power of the hob Enables the total power of the hob to be lim- - 1000 W. Lowest power setting. ited, if necessary, based on the conditions of ... - Page 14 17.1 Cleaning products You can obtain suitable cleaning products and glass scrapers from customer service, a retailer or the online shop siemens-home.bsh-group.com . ATTENTION! Unsuitable cleaning products may damage the sur- faces of the appliance.
- Page 15 Cleaning and servicing en 17.3 Cleaning the hob Remove the four odour filters or acoustics filters, and dispose of them properly. Clean the hob after every use to stop cooking residues from getting burnt on. Requirement: The hob must be cold. Do not allow the hob to cool down if it has sugar stains, plastic or alu- minium foil on it.
- Page 16 en Cleaning and servicing Cleaning the grease filters manually Press and hold until an audible signal sounds. a The display stops lighting up. The saturation indic- Dismantle the grease filter. ator for the odour filters is reset. 17.6 Cleaning the grease filters The grease filters filter the grease from the cooking va- pour.
- Page 17 FAQs en Hold the overflow container with one hand and un- Empty the overflow container and rinse it out. screw it with the other hand. If required, unscrew the screw and clean the over- Hold the overflow container level to prevent liquid flow container without the screw in the dishwasher.
- Page 18 en FAQs 18.2 Noises Question Answer Why can I hear noises ¡ Noises may be generated while using the hob depending on the base material of while I'm cooking? the cookware. These noises are normal for induction technology. They do not in- dicate that there is a fault.
- Page 19 Troubleshooting en Question Answer How often do I need to ¡ Clean the overflow container frequently. clean the overflow con- You can find further information about how to clean the overflow container under tainer? → "Cleaning and servicing", Page 14. How often do I need to ¡...
- Page 20 en Disposal Fault Cause and troubleshooting There is hot cookware in the vicinity of the control panel. The cooking zone has been and signal tone switched off to protect the electronics. ▶ Remove the cookware. Wait a few seconds. Touch any button. When the fault display goes out, you can continue cooking.
- Page 21 Test dishes en The product number (E no.) can also be found on the glass ceramic. You can also display the customer ser- vice index (KI) and the production number (FD) in the basic settings. → Page 12 Make a note of your appliance's details and the Cus- tomer Service telephone number to find them again quickly.
- Page 22 en Test dishes 22.6 Cooking rice pudding without a lid Milk temperature: 7 °C 1. Add the ingredients to the milk and heat the mixture up while stirring continuously. 2. Once the milk has reached approx. 90 °C, select the recommended power level and leave it to simmer on a low heat for approx.
- Page 24 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001576748* 9001576748 (020331) ...
