- Page 1 Operation Manual Model C25L Manual Polarimeter Measurement Range ±180° Cat. No. 4601P...
-
Page 2: Table Of Contents
This product is designed and intended for use only as a polarimeter system. Modifying the product in any manner for use not originally intended shall automatically void the manufacturer’s warranty. In no event shall VEE GEE Scientific LLC be held liable for any incidental or indirect damage arising from the use of modified or altered product. -
Page 3: Introduction
The VEE GEE Model C25L is designed to measure the angle of rotation caused by passing polarized light through an optically active substance. Measurements can be made with an accuracy of ±0.1 by utilizing a large, ±180°, full circle Vernier scale. -
Page 4: Components
Polarimeter Body Included Parts Upon receiving your VEE GEE Model C25L Polarimeter, check to see that all parts are functioning and focusing properly and that the following items are supplied with your instrument: 1. Assembled Polarimeter Body (1 ea.) 2. Power Cable (NEMA 5 or Euro Schuko depending on voltage) (1 ea.) 3. -
Page 5: Replacement Parts
Windows Bubble Trap Jack Cell Chamber Replacement Parts Replacement parts can be ordered through your VEE GEE dealer. Contact us for more information. Item Part No. Factory replacement 100mm Sample Cell with bubble trap 4600P-SC100 Factory replacement 200mm Sample Cell with bubble trap... -
Page 6: Setup
4. Flip the power switch to the on position, labeled “|”. 5. The C25L polarimeter utilizes an LED illuminator and therefore requires no warm up period before use. 6. Observe the field of view through the eyepiece and rotate the eyepiece focus adjustment (figure 2) until the edges of the round field of view are sharply focused. -
Page 7: Instrument Accuracy
Operation (continued) Instrument Accuracy Your VEE GEE polarimeter was calibrated at the factory during production. Follow the instructions below to check the accuracy of your instrument and make adjustments if necessary. 1. Ensure the the ambient room temperature of your work area is 20°C (±2°C). Fill the sample cell with distilled water that is at room temperature. - Page 8 Printed in USA No. VGMNL092319-C25L...
