This manual conTains The illusTraTed parTs lisT for models:
sTWc48V-25cV
sTWc48V-26Ka-lc
sTWc52V-25Ka
sTWc52V-26Ka-lc
sTWc61V-26Ka-lc
sTWc61V-27cV
smTc-48V
smWc-52V
smWc-61V
© 2008
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
30
29
35
with a serial number of e4300001 to e4399999
with a serial number of e4400001 to e4499999
with a serial number of d6900001 to d6999999
with a serial number of d7000001 to d7099999
with a serial number of d7100001 to d7199999
with a serial number of d7200001 to d7299999
with a serial number of d9100001 to d9199999
with a serial number of d9200001 to d9299999
with a serial number of d9300001 to d9399999
ILLUSTRATED
PARTS
MANUAL
Model STWC
Wildcat
Part No. 06199
Printed 9/08
Printed in USA
Advertisement
Table of Contents
Related Manuals for Scag Power Equipment STWC WILDCAT SMTC-48V
Summary of Contents for Scag Power Equipment STWC WILDCAT SMTC-48V
- Page 1 © 2008 Scag Power Equipment Division of Metalcraft of Mayville, Inc. ILLUSTRATED PARTS MANUAL Model STWC Wildcat with a serial number of e4300001 to e4399999 with a serial number of e4400001 to e4499999...
-
Page 3: Table Of Contents
Table of contents Table of contents 48V & 52V cuTTer decKs ...2 61V cuTTer decK ...4 cuTTer decK conTrols ...6 sheeT meTal componenTs ...8 sTWc roll-oVer proTecTion sYsTem ...10 driVe sYsTem componenTs ...12 enGine and aTTachinG parTs ...14 sTeerinG componenTs ...16 BraKe componenTs ...18 fuel and hYdraulic sYsTem ...20 elecTrical sYsTem - Kohler &... -
Page 4: 52V Cutter Decks
6 7 8 5 25 * 52" cutter deck has a notch for anti-scalp roller 48V & 52V cuTTer decKs section 8 64 60 62 61 59 58 66 63 STC 2006 CD4852 Rev.1... -
Page 5: V & 52V Cutter Decks
section 8 ref. part no. description 461854 Cutter Deck Velocity Plus 461858 Cutter Deck Velocity Plus 43686 Boss, Spring Anchor 04019-04 Nut, 3/8-16 Serrated Flange 481625-01 Wing Nut, 3/8-16 481632 Anti-Scalp Wheel 04003-26 Bolt, Carriage 3/8-16 x 4” 422478 Bracket, Anti-Scalp Wheel 04017-27 Bolt, Serrated Flange 3/8-16 x 1”... -
Page 6: Cutter Deck
6 7 8 5 25 61V cuTTer decK "A" "A" 2 80 section 8 64 60 62 61 59 58 66 63 STWC 2006 CD61... - Page 7 section 8 ref. part no. description 461862 Cutter Deck Velocity Plus 43687 Boss, Spring Anchor 424371 Bracket, LH Spring Anchor 61V 481625-01 Wing Nut, 3/8-16 481632 Anti-Scalp Wheel 04003-26 Bolt, Carriage 3/8-16 x 4” 422478 Bracket, Anti-Scalp Wheel 04017-27 Bolt, Serr. Flng. 3/8-16 x 1” 04043-06 Flatwasher, 5/8”...
-
Page 8: Cutter Deck Controls
cuTTer decK conTrols CUTTER DECK section 8 STC 2006 CDC... -
Page 9: Cutter Deck Controls
section 8 ref. part no. description 482624 Rod, Deck Lift Linkage 04020-28 Nut, Jam 1/2-20 LH Thread 481766 Rod End, 1/2-20 Female LH Thread 04050-10 Retaining Ring, 1/2” Ext. “E” 483062 Slide, Deck Height Adjust 43487 Pin, Deck Lift 423463 Bracket, Cutting Height Adjustment 04001-22 Bolt, Hex Hd. -
Page 10: Sheet Metal Components
sheeT meTal componenTs 18 19 section 8 26hp Kawasaki 7 8 20 STWC 2008 SMC... -
Page 11: Sheet Metal Components
section 8 ref. part no. description 461918 Main Frame Assembly w/Decals 04001-73 Bolt, Hex Hd. 5/16-18 x 3-3/4” 482938 Back Cover 04019-04 Nut, Serr. Flng. 3/8-16 461989 Plate, Seat Mounting 482939 Cushion Cover 43462 Pin Retainer, Spring 481389 Spring Battery (not available through Scag) 423571 Battery Cover 482553... - Page 12 STC / STWC SUSPENSION SEAT - ILLUSTRATED PARTS LIST Ref. Part No. Description 9292 Suspension Seat Assembly w/seat belt 04001-178 Bolt, Hex Head 7/16-20 x 1” 04040-11 Flatwasher, 7/16-.500 x 1.25 x .083 483594 Retractable Seat Belt 482950 Armrest Only 482945 Armrest Assembly Kit, LH 482946...
-
Page 13: Stwc Roll-Over Protection System
section 8 sTWc roll-oVer proTecTion sYsTem STWC 2007 ROPS... - Page 14 section 8 sTWc roll-oVer proTecTion sYsTem ref. part no. description 461956 STWC Foldable ROPS 04001-145 Bolt, Hex Hd. 1/2-13 x 3-1/2” 04021-19 Nut, Center Lock 1/2-13 483412 Retractable Seat Belt 04040-13 Flatwasher, 1/2 (.562 x 1.375 x .109") 481625-03 Thumb Screw, 5/16-18 NC x 3/4” 04062-06 Hair Pin, Cotter 483262...
-
Page 15: Drive System Components
driVe sYsTem componenTs section 8 STWC 2008 DSC... - Page 16 section 8 ref. part no. description 04021-09 Nut, Elastic Stop 3/8-16 04019-04 Nut, Serr. Flng. 3/8-16 483087 Spring, Pump Idler 43286 Spacer 04001-22 Bolt, Hex Hd. 3/8-16 x 2-3/4” 461603 Idler Arm Assy., Pump Drive 04063-14 Key, 5 x 5 x 25mm 483172 Belt, Transmission 483415...
-
Page 17: Engine And Attaching Parts
section 8 enGine and aTTachinG parTs SC 2004 EAPKA... - Page 18 section 8 enGine and aTTachinG parTs ref. part no. description 483685 Engine, Kohler Command 25hp 482900 Engine, 27HP Kohler 482827 Engine, 25HP Kawasaki 483126 Engine, 26HP Kawasaki Liquid-Cooled 423770 Bumper, Rear 41031 Weight, Rear (Shield) 61V Only 424107 Shield, Rear 52V Only 04019-04 Nut, Serr.
-
Page 19: Steering Components
sTeerinG componenTs 29, 29A section 8 To Pump STC 2006 SSC REV 1... - Page 20 section 8 ref. part no. description 482340 Grip, Control Lever 461914 Handle Bar, LH (Incl. item 1) 461923 Handle Bar, RH (Incl. item 1) 04001-09 Bolt, Hex Hd. 5/16-18 x 1” 04030-03 Lockwasher, 5/16” 483269 Knob 04040-15 Flatwasher, 5/16 (.375 x .875 x .083") 04060-01 Roll Pin, Spring 5/32 x 3/4”...
-
Page 21: Brake Components
40 16 17 35 31 11 3 BraKe componenTs section 8 15 14 13 12 STC 2002 BSC... - Page 22 section 8 ref. part no. description 04019-06 Nut, Serr. Flng. 1/2-13 48807 Spring 04001-08 Bolt, Hex Hd. 5/16-18 x 3/4” 04001-163 Bolt, Hex Hd. 1/2-13 x 3-3/4” 04001-52 Bolt, Hex Hd. 1/2-13 x 2-1/2” 04021-19 Nut, 1/2-13 Center Lock 483190 Wheel Motor, Hydro-Gear 04063-25 Key, Woodruff 5/16 x 1”...
-
Page 23: Fuel And Hydraulic System
fuel and hYdraulic sYsTem 3 55 45 46 18 19 33 47 48 enGine 35 32 54 48 47 49 section 8 20 19 STWC 2005 FHS... - Page 24 section 8 ref. part no. description 482643 Pump, BDP-10A-316 (LH) 482644 Pump, BDP-10A-419 (RH) 482266-01 Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose 48572-02 Fitting, 1/2” JIC x 5/8" O-Ring 48811 Hose, 3/8" Pushlock (Specify length) 482573 Bushing 482574 Fitting 482266-01 Elbow, 90 Degree 9/16"...
-
Page 25: Electrical System - Kohler & Kawasaki Air-Cooled
elecTrical sYsTem - Kohler & KaWasaKi air-cooled section 8 STWC 2008 ESKH... - Page 26 section 8 elecTrical sYsTem - Kohler & KaWasaKi air-cooled ref. part no. description 483355 Hourmeter 48298 Fuse, 20 Amp 483366 Key, Ignition 462069 Key Assembly w/Fob 48017-04 Nut, Hex 5/8-32 48017-03 Lockwasher, 5/8” Internal 461660 Electric PTO Clutch GT3.5 48798 Switch, Ignition 483957 Switch, PTO...
-
Page 27: Electrical System - 26Hp Kawasaki Liquid-Cooled
elecTrical sYsTem - 26hp KaWasaKi liQuid-cooled section 8 STWC 2008 ESKALC... - Page 28 section 8 elecTrical sYsTem 26hp KaWasaKi liQuid-cooled ref. part no. description 483355 Hourmeter 48298 Fuse, 20 amp 483366 Key, Ignition 462069 Key Assembly w/Fob 48017-04 Nut, Hex 5/8-32 48017-03 Lockwasher, 5/8” Internal 461660 Electric PTO Clutch GT3.5 48798 Switch, Ignition 483957 Switch, PTO 48788...
-
Page 29: Hydraulic Pump Assembly
PORT "A" SIDE hYdraulic pump assemBlY PORT "B" SIDE section 8... -
Page 30: Hydraulic Pump Assembly
section 8 ref. part no. description HG 70516 Housing Kit HG 70573 End Cap Kit HG 50641 Straight Headless Pin HG 50969 Hex Flng. Bolt, M8-1.25 x 60mm HG 51232 Housing O-Ring HG 2513027 Charge Pump Kit HG 50273 Gerotor Assembly HG 9004101-1340 O-Ring HG 50095... -
Page 31: Replacement Decals And Information Plates
replacemenT decals and informaTion plaTes forWard reVerse 482100 WarninG insTall BelT coVer Before operaTinG machine read operaTor's manual MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING PATENTS: 4,487,006 4,885,903 4,920,733 4,967,543 4,991,382 4,998,948 5,042,239 5,117,617 5,133,176 5,826,416 5,832,708 5,865,018 6,192,666 6,766,633 6,892,519 6,996,962... - Page 32 section 8 replacemenT decals and informaTion plaTes ref. part no. description 483407 Decal, Danger-Spinning Blades 483406 Decal, Warning-Rotating Blades 483199 Decal, 48V 483200 Decal, 52V 483201 Decal, 61V 483158 Decal, ROPS 483044 Decal, Patents 482100 Decal, Traction Control 481971 Decal, Heavy Duty Commercial 48404 Decal, Metalcraft - Made in USA 483402...
-
Page 33: Electrical Schematic - Kohler & Kawasaki Air-Cooled
elecTrical schemaTic - Kohler & KaWasaKi air-cooled KAWASAKI ADAPTER HARNESS WHITE MAGNETO RED W/YEL STRIPE FUEL SOLENOID YELLOW RECTIFIER GRN W/WHT STRIPE SOLENOID MAIN HARNESS KOHLER ADAPTER HARNESS GRN W/WHT STRIPE WHITE ENGINE PLUG YELLOW SOLENOID "B+" MAIN HARNESS BLACK BLACK BLACK GROUND... -
Page 34: Electrical Schematic - 26Hp Kawasaki Liquid-Cooled
section 8 elecTrical schemaTic - 26hp KaWasaKi liQuid-cooled SWITCH BLACK BLACK BLACK GROUND CLUTCH (600V 2A) HOURMETER MAIN HARNESS WATER TEMP GAUGE SWITCH 20 AMP FUSES DIODE ENGINE ADAPTER HARNESS ADAPTER HARNESS WHITE YELLOW GRN W/WHT STRIPE WHITE W/BLACK STRIPE RED W/YEL STRIPE RELAY BRAKE...
