This manual conTains The illusTraTed parTs lisT for models:
scZ61V-31fX
scZ61V-32BV
scZ72V-34fX
© 2010
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
30
29
35
with a serial number of f5000001 to f5099999
with a serial number of f5100001 to f5199999
with a serial number of f5200001 to f5299999
ILLUSTRATED
PARTS
MANUAL
Model SCZ
Cheetah
Part No. 06209
Printed 11/10
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHEETAH SCZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scag Power Equipment CHEETAH SCZ

Summary of Contents for Scag Power Equipment CHEETAH SCZ

  • Page 1 This manual conTains The illusTraTed parTs lisT for models: scZ61V-31fX scZ61V-32BV scZ72V-34fX © 2010 Scag Power Equipment Division of Metalcraft of Mayville, Inc. ILLUSTRATED PARTS MANUAL Model SCZ Cheetah with a serial number of f5000001 to f5099999 with a serial number of f5100001 to f5199999 with a serial number of f5200001 to f5299999 Part No.

  • Page 3: Table Of Contents

    Table of contents Table of contents 61V & 72V cuTTer decKs ...2 cuTTer decK conTrols ...4 sheeT meTal componenTs ...6 scZ roll-oVer proTecTion sYsTem ...8 scZ suspension sYsTem ...10 scZ sTeerinG & fooT plaTform componenTs ...12 scZ driVe sYsTem componenTs ...14 scZ speed conTrol componenTs ...16 scZ BraKe componenTs ...18 scZ hYdraulic sYsTem ...20...

  • Page 4: 61V & 72V Cutter Decks

    61V & 72V cuTTer decKs 7 14 section 8 72V Only 35 33...
  • Page 5 section 8 ref. part no. description 425431 Belt Cover, 61V 425417 Belt Cover, 72V 481625-01 Knob w/Stud 04020-09 Nut, 5/8-11 UNC 04001-172 Bolt, Hex Head 1/4-20 x 1” 48926 Tapered Hub, 1.125” Bore 483286 Pulley, 6.32” Dia. 484050 Pulley, 7.50” Dia. 483157 Belt 484159...

  • Page 6: Cutter Deck Controls

    cuTTer decK conTrols 23 27 CUTTER DECK section 8...
  • Page 7 section 8 ref. part no. description 481477 Grip, Deck Latch 462253 Deck Latch Assembly w/Grip 43668 Spacer, Deck Latch 484191 Spring, Torsion Return Lever 483345 Ring Pin Assembly w/Lanyard 425574 Adjustment Bracket, Upper Cut Height 425361 Adjustment Bracket, Lower Cut Height 484115 Slide, Height Adjustment 43487...

  • Page 8: Sheet Metal Components

    sheeT meTal componenTs 42 44 section 8 18 17...
  • Page 9 section 8 ref. part no. description 462265 Hood Assembly w/Decals 04040-05 Flatwasher, 3/8-.406 x .812 x .065 424634 Lock, Hood Latch 483507 Spring, Hood Latch 424633 Latch, Hood 04009-07 Bolt, Shoulder 04001-21 Bolt, Hex Head 3/8-16 x 1-3/4” 43740 Spacer, Hood 483471 Disc, Anti-Friction 04010-30...

  • Page 10: Scz Roll-Over Protection System

    scZ roll-oVer proTecTion sYsTem section 8...
  • Page 11 section 8 scZ roll-oVer proTecTion sYsTem ref. part no. description 462246 ROPS, Foldable SCZ 484168 Pin Assembly (incl. #3, #4) 484170 Spring, ROPS 484169 Clip, ROPS 04001-90 Bolt, Hex Head 1/2-13 x 3-1/4” 04021-07 Nut, Elastic Stop 1/2-13 484167 Spring Clip, ROPS 04021-19 Nut, Center Lock 1/2-13 04040-13...

  • Page 12: Scz Suspension System

    scZ suspension sYsTem 8 41 40 20 section 8...
  • Page 13 section 8 ref. part no. description 484125 Seat Assembly 483559 Cable, Seat Stop 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4” 04019-02 Nut, Serrated Flange 1/4-20 43606 Sleeve, Seat Base Mount 04001-45 Bolt, Hex Head 3/8-16 x 2” 04041-07 Flatwasher, 3/8-.391 x .938 x .105 04021-09 Nut, Elastic Stop 3/8-16 483371...

  • Page 14: Scz Steering & Foot Platform Components

    section 8 scZ sTeerinG & fooT plaTform componenTs 12 17 To Transaxle...
  • Page 15 section 8 scZ sTeerinG & fooT plaTform componenTs ref. part no. description 461914 Handle Bar w/Grip, LH 461923 Handle Bar w/Grip, RH 482340 Grip, Control Handle 04030-03 Lockwasher, 5/16-” Spring 04001-09 Bolt, Hex Head 5/16-18 x 1’ 483238 Pivot, Control Lever 483269 Knob, Control Handle 483250...

  • Page 16: Scz Drive System Components

    scZ driVe sYsTem componenTs section 8...
  • Page 17 section 8 scZ driVe sYsTem componenTs ref. part no. description 04003-21 Bolt, Carriage 3/8-16 x 2-1/2” 04001-54 Bolt, Hex Head 3/8-16 x 3” 04001-19 Bolt, Hex Head 3/8-16 x 1” 04019-04 Nut, Serrated Flange 3/8-16 425385 Mounting Bracket, Spring - Idler Arm 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2”...

  • Page 18: Scz Speed Control Components

    scZ speed conTrol componenTs 22 23 section 8...
  • Page 19 section 8 scZ speed conTrol componenTs ref. part no. description 484093 Knob, Soft Touch 04020-12 Nut, Jam 3/8-16 UNC 452142 Lever Weldment, Speed Control SCZ 04009-11 Bolt, Shoulder 3/8 x 1” 04040-05 Flatwasher, 3/8-.406 x .812 x .065 483601 Spring, Speed Control 04009-14 Bolt, Shoulder 3/8 x 3/8”...

  • Page 20: Scz Brake Components

    section 8 scZ BraKe componenTs 20 21...
  • Page 21 section 8 ref. part no. description 04004-53 Link, Lower Brake 484177 Rod End, 3/8-24 04020-14 Nut, Jam 3/8-24 UNF 04061-01 Cotter Pin 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4” 484149 Bearing, Self Align 43503 Pivot 484188 Linkage, Upper Brake 483339 Rod End, 3/8-24 RH 04020-25 Nut, Jam 3/8-24 UNF...

  • Page 22: Scz Hydraulic System

    section 8 scZ hYdraulic sYsTem...
  • Page 23 section 8 ref. part no. description 483797 Transaxle, LH 04017-04 Bolt, Hex Head 1/4-20 X 1/2” Serrated Flange 04003-02 Bolt, Carriage 1/4-20 x 3/4” 425390 Cover, Oil Reservoir 04003-12 Bolt, Carriage 5/16-18 x 3/4” 425421 Plate, Hydro Tank Mount 462251 Hydraulic Tank Assembly (incl.

  • Page 24: Scz Fuel System - Epa Phase 2

    scZ fuel sYsTem - epa phase 2 (models produced prior to 1/1/2011) 2011 SCZ EPA Phase 2 section 8 ENGINE...
  • Page 25 section 8 scZ fuel sYsTem - epa phase 2 (models produced prior to 1/1/2011) ref. part no. description 484323 Fuel Gauge 482571 Bushing, .56 Dia. Viton 483792 Cap, Fuel Tank 462245 Fuel Tank Assembly, RH (incl. #1, 2, 5, 6) 484242 Grommet 484145...

  • Page 26: Scz Fuel System - Epa Phase 3

    scZ fuel sYsTem - epa phase 3 (models produced after to 1/1/2011) Purge Tank section 8 ENGINE To Engine Purge Port Purge Tank 2011 SCZ EPA Phase 3...
  • Page 27 section 8 (models produced after to 1/1/2011) ref. part no. description 484323 Fuel Gauge 482571 Bushing, .56 Dia. Viton 484286 Fuel Cap, Tethered 462294 Fuel Tank Assembly, RH (incl. #1, 2, 5, 6, 22, 23) 484242 Grommet 484145 Fuel Tube Assembly, RH 48059-01 Clamp, Fuel Hose 1/4”...

  • Page 28: Scz Engine & Attaching Parts

    section 8 scZ enGine & aTTachinG parTs...
  • Page 29 section 8 scZ enGine & aTTachinG parTs ref. part no. description **484183 Engine, 31hp Kawasaki FX **484233 Engine, 32hp Briggs & Stratton **484232 Engine, 34hp Kawasaki FX 484303 Hose, Oil Drain, Kawasaki (incl. # 3) 484171 Hose, OIl Drain, Briggs & Stratton (incl. # 3) 48771-02 Plug 484155...

  • Page 30: Zt-5400 Transaxle Assembly

    ZT-5400 TransaXle assemBlY * - Included with Seal Kit Item # 75 section 8...
  • Page 31 section 8 ZT-5400 TransaXle assemBlY ref. part no. description HG71946 Kit, Housing Main, LH HG71947 Kit, Housing Main, RH HG71948 Kit, Housing Side, LH HG71948 Kit, Housing Side, RH HG52973 Insert, 1/2-13 x 1-1/2” UNC HG52974 Screw, Hex Flange 5/16-18 x 1-1/2” HG50928 Tube, Sealant HG71995...

  • Page 32: Scz Electrical System

    scZ elecTrical sYsTem CHOKE THROTTLE section 8 STARTER STARTER GROUND...
  • Page 33 section 8 ref. part no. description 484098 Pulley, 5.80 Dia. - 1.125 Bore 04063-23 Kay, 1/4 x 1/4 x 3-1/4” 461661 Electric Clutch w/Tag (GT-3.5) 461826 Electric Clutch w/Tag (GT-5) - 72V 452157 Weldment, Anti-Rotation 482543 Wire Harness Adapter, Kawasaki 482849 Wire Harness Adapter, Briggs &...

  • Page 34: Replacement Decals And Information Plates

    replacemenT decals and informaTion plaTes forWard reVerse WarninG insTall BelT coVer Before operaTinG machine read operaTor's manual Heavy Duty Commercial MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING PATENTS: 4,487,006 4,885,903 4,991,382 4,998,948 5,133,176 5,826,416 6,192,666 6,766,633 7,065,946 7,197,863 section 8 4,920,733 4,967,543 5,042,239...
  • Page 35 section 8 replacemenT decals and informaTion plaTes ref. part no. description 483407 Decal, Spinning Blades 483406 Decal, Knives 483201 Decal, 61” Velocity Plus 483693 Decal, 72” Velocity Plus 483633 Decal, Seat Replacement 483044 Decal, Patents 482100 Decal, Traction Control 483405 Decal, Warning 48404 Decal, Made in USA...

  • Page 36: Scz Electrical Schematic

    scZ elecTrical schemaTic SWITCH RELAY YEL W/RED STRIPE 20 AMP FUSE YELLOW 20 AMP FUSE YELLOW DIODE GROUND ENGINE MODULE PLUG SWITCH BLUE BLUE CLUTCH BLACK BLACK DIODE (600V 6A) MAIN HARNESS TO OPERATOR PLATFORM HARNESS CONNECTOR BROWN BROWN ORANGE ORANGE BRAKE INTERLOCK...
