Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum efficiency. The specific models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2019
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
Cheetah
Models:
SCZ61V-27FX
SCZ61V-31CV-EFI
SCZ61V-31FX
SCZ61RD-31FX
SCZ61V-37BV-EFI
SCZ72V-31FX
SCZ72V-37BV-EFI
PART NO. 03436
PRINTED 9/2018
PRINTED IN USA
