Operation Manual
360° Metal Sheet Bending Machine
61856
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.
Advertisement
Related Manuals for XPOtool 61856
Summary of Contents for XPOtool 61856
- Page 1 Operation Manual 360° Metal Sheet Bending Machine 61856 Illustration similar, may vary depending on model Read and follow the operating instructions and safety information before using for the first time. Technical changes reserved! Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
- Page 2 To allow for a smooth execution of your complaint or return, it is important to contact our customer service team before returning the goods. Returns Department WilTec Wildanger Technik GmbH Königsbenden 28 52249 Eschweiler E-mail: service@wiltec.info Tel: +49 2403 55592–0 Fax: +49 2403 55592–15 https://www.XPOtool.com Item 61856 Page 2 The Tool Experts 05 2022-1...
- Page 3 Do not use the tool if under the influence of alcohol, drugs, or medicine, that alter your con- sciousness. • Never stand on the tool. Should the tool tilt over, serious injuries or damages might follow. https://www.XPOtool.com Item 61856 Page 3 The Tool Experts 05 2022-1...
- Page 4 11. Should you wish to form an entire 360° ring, make sure to clamp the end of your workpiece between the vice and die. Entirely bend your workpiece around and cut off the overspill. https://www.XPOtool.com Item 61856 Page 4 The Tool Experts...
- Page 5 (depending on the length of your workpiece). Thus, the bending is “stopped” at the right position. 11. Should you wish to repeat bends at another angle, use the stop (2). https://www.XPOtool.com Item 61856 Page 5 The Tool Experts 05 2022-1...
- Page 6 8. Now set the spring pins (25) of the spring-forming die “B” (30) into the holes 4 and 5. 9. Finish bending by completely bending the piece around the dies. Figure 2 Figure 3 https://www.XPOtool.com Item 61856 Page 6 The Tool Experts 05 2022-1...
- Page 7 Exploded view and parts list https://www.XPOtool.com Item 61856 Page 7 The Tool Experts 05 2022-1...
- Page 8 Mounting disc for spring-forming die 1 Important notice: The reprint or reproduction, even of excerpts, and any commercial use, even in part, of this instruction manual require the written permission of WilTec Wildanger Technik GmbH. https://www.XPOtool.com Item 61856 Page 8 The Tool Experts 05 2022-1...
