All manuals and user guides at all-guides.com Introduction 2 2 Introduction Thank you for choosing the MicroSys SBC-LS1046A Single Board Computer system. This manual should help you to get the best performance and details out all of its features. 2.1 Safety and Handling Precautions... -
Page 8: Short Description
Power Supply 12V DC stabilized / 2 A ■ Cable adapter for the power supply ■ USB cable type A – mini B ■ Micro-SD-Card with U-Boot and root file system miriac SBC-LS1046A-TSN_User Manual V 2.0 8/68 © MicroSys Electronics GmbH 20178... -
Page 9: Functional Coverage
✓ RTC backup Battery ✓ Manual Reset Button ✓ Reset / Power LEDs 2x red, 1x green ✓ User LEDs 4x RGB Table 2-2 Functional coverage miriac SBC-LS1046A-TSN_User Manual V 2.0 9/68 © MicroSys Electronics GmbH 20178... -
Page 10: Quick Start Guide
■ TFTP server available for downloading within the network (Hint: may run on the same PC as the serial Terminal) ■ SD card as mass storage and/or boot media miriac SBC-LS1046A-TSN_User Manual V 2.0 10/68 © MicroSys Electronics GmbH 20178... -
Page 11: Board Preparation And Power-Up
Connect other peripherals (USB, LAN ...) as far as intended. ■ Connect the power line to the PWR connector, while the power supply is still switched off. ■ Switch on power. Figure 3-1 System setup example miriac SBC-LS1046A-TSN_User Manual V 2.0 11/68 © MicroSys Electronics GmbH 20178... -
Page 12: Operation
Waking secondary cores to start from fbcf0000 All (4) cores are up. Using SERDES1 Protocol: 4403 (0x1133) Using SERDES2 Protocol: 34952 (0x8888) NAND: 512 MiB MMC: *** Warning - bad CRC, using default environment serial miriac SBC-LS1046A-TSN_User Manual V 2.0 12/68 © MicroSys Electronics GmbH 20178... -
Page 13: Linux
For detailed setup instructions, refer to the text document “linux-fsl-sdk-v2.0-1703- mpxls1046.txt” delivered in the "Linux" directory along with the unit! The text document mentioned here may refer to an older version. miriac SBC-LS1046A-TSN_User Manual V 2.0 13/68 © MicroSys Electronics GmbH 20178... -
Page 14: System Description
3.0 / 8Gbps PCIe connector Lane x4 Root complex operations Serdes 4, 5, 0, 7 USB 3.0 Phy USB connector type A USB 3.0 Phy USB connector type A miriac SBC-LS1046A-TSN_User Manual V 2.0 14/68 © MicroSys Electronics GmbH 20178... - Page 15 10/100/1000 Mbps 10/100/1000 Mbps TSN Switch 1 RGMII 1 10/100/1000 Mbps 10/100/1000 Mbps 10/100/1000 Mbps 10/100/1000 Mbps TSN Switch 2 RGMII 2 10/100/1000 Mbps 10/100/1000 Mbps 10/100/1000 Mbps 10/100/1000 Mbps miriac SBC-LS1046A-TSN_User Manual V 2.0 15/68 © MicroSys Electronics GmbH 20178...
- Page 16 JTAG 10 pin header Controller Power Management Primary Supply LM25116MH Input: 9-30V DC Output: 5V DC / peak 8A Backup Supply Battery CR2032 (RTC backup) Table 4-1 Feature Overview miriac SBC-LS1046A-TSN_User Manual V 2.0 16/68 © MicroSys Electronics GmbH 20178...
-
Page 17: Mechanical Dimensions
The following drawing shows the mechanical outline of the MPX-LS1046A module that is plugged in the CRX06 carrier board. This drawing is not to scale. For 3D data files please contact MicroSys. Figure 4-2 Mechanical Dimensions Module miriac SBC-LS1046A-TSN_User Manual V 2.0... -
Page 18: Sbc-Ls1046A-Tsn
4.3.2 SBC-LS1046A-TSN The following drawing shows the mechanical outline of the SBC-LS1046A-TSN assembly. This drawing is not to scale. For 3D data files please contact MicroSys. Figure 4-3 CRX06 Mechanical Dimensions miriac SBC-LS1046A-TSN_User Manual V 2.0 18/68 © MicroSys Electronics GmbH 20178... -
Page 19: Connector Layout - Top
All manuals and user guides at all-guides.com System Description 4 4.4 Connector Layout – Top Figure 4-4 Top connectors miriac SBC-LS1046A-TSN_User Manual V 2.0 19/68 © MicroSys Electronics GmbH 20178... -
Page 20: Power Supply
■ The primary step-down converter produces 5V DC / max. 8A peak from the input supply which supplies both the LS1046A module and peripheral devices on the carrierboard CRX06. miriac SBC-LS1046A-TSN_User Manual V 2.0 20/68 © MicroSys Electronics GmbH 20178... -
Page 21: Rtc Backup Battery
The following diagram shows the Power Supply structure: 4.5.4 RTC Backup Battery The RTC on the module is supplied from replaceable CR2032 battery. Part Reference: BAT1 Manufacturer: Renata Batteries Type: VBH2032-1 Used with: CR2032 battery miriac SBC-LS1046A-TSN_User Manual V 2.0 21/68 © MicroSys Electronics GmbH 20178... -
Page 22: Current Measurement
5V path supplying the CPU module. For automated measurements there’s a MAX9611AUB current sense amplifier. It is interfaced by I²C. 4.5.6 Fuses There are no fuses on the SBC-LS1046A-TSN. miriac SBC-LS1046A-TSN_User Manual V 2.0 22/68 © MicroSys Electronics GmbH 20178... -
Page 23: System Core, Boot Configuration And On-Board Memory
Please see chapter 0 for a description of the JTAG connector. 5.3 Reset Structure Figure 5-1 Reset Structure (carrier CRX06 Revision 2) miriac SBC-LS1046A-TSN_User Manual V 2.0 23/68 © MicroSys Electronics GmbH 20178... - Page 24 The following voltages on the carrier board are monitored by a Maxim MAX6751KA29 chip: Voltage Monitoring Voltage Limit 3,3V Undervoltage Typ. 2,925V [2,867V-2,984V] 1,8V Undervoltage Typ. 1,72V [1,69V-1,75V] Table 5-2 Voltage monitoring limits (carrier) miriac SBC-LS1046A-TSN_User Manual V 2.0 24/68 © MicroSys Electronics GmbH 20178...
-
Page 25: Clock Distribution
← ← ← ← 10R ← RX_CLK RXCK EC1_GTX MII1- ← ← ← ← ← ← ← CLK125 _CLK125 SPI- → → → → → → SPI-CLK SPI_CLK SHIFT miriac SBC-LS1046A-TSN_User Manual V 2.0 25/68 © MicroSys Electronics GmbH 20178... - Page 26 PCIeT_LR1 AB18 REFCLK2 SD1- → PCIeC_LR1 REFCLK2 AB19 PCIE Signal Signal SRD- PCIE- → → PCIeT_LR4 CLK1+ CLK+ SRD- PCIE- → → PCIeC_LR4 CLK1- CLK- Table 5-3 Clock distribution miriac SBC-LS1046A-TSN_User Manual V 2.0 26/68 © MicroSys Electronics GmbH 20178...
-
Page 27: Boot Configuration
The BOOT-SELx pins are decoded to the following configuration (1= high, 0=low): LS1046A BOOT-SEL2 | BOOT-SEL1 = Signal SDHC NAND =[10] =[11] =[01] IFC_AD08 IFC_AD09 IFC_AD10 IFC_AD11 IFC_AD12 IFC_AD13 IFC_AD14 IFC_AD15 IFC_CLE Table 5-4 Hard wired boot signals miriac SBC-LS1046A-TSN_User Manual V 2.0 27/68 © MicroSys Electronics GmbH 20178... -
Page 28: Nand Flash
IFC_AD2 data line ↔ ↔ 1,8V IFC-AD1 IFC_AD1 data line ↔ ↔ 1,8V IFC-AD0 IFC_AD0 data line n.c. Not connect n.c. Not connect Table 5-5 NAND Flash pin assignments miriac SBC-LS1046A-TSN_User Manual V 2.0 28/68 © MicroSys Electronics GmbH 20178... -
Page 29: Qspi Flash
Range Name Name ← LVTTL QSPI_A_CS0 ← LVTTL QSPI_A_SCK ← ↔ LVTTL QSPI_A_DATA0 ↔ LVTTL QSPI_A_DATA1 ↔ LVTTL QSPI_A_DATA2 ↔ LVTTL QSPI_A_DATA3 +1.8V Table 5-6 QSPI Flash pin assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 29/68 © MicroSys Electronics GmbH 20178... -
Page 30: I²C Bus
GP input pins of the MAX7325 port expander can be read correctly. This can be achieved by setting the default value 1 of Bit 0 in MODE1 register to 0. miriac SBC-LS1046A-TSN_User Manual V 2.0 30/68 © MicroSys Electronics GmbH 20178... -
Page 31: I2C-2
Function PCA9517ADP I2C buffer for external busses 0x7F MAX9611AUB Current Monitor for module consumption Table 5-9 I²C2 bus map I²C-2 is not available when SD-card boot mode is selected! miriac SBC-LS1046A-TSN_User Manual V 2.0 31/68 © MicroSys Electronics GmbH 20178... - Page 32 The I²C bus 2 has the following layout: I/O Range: LVTTL Device (Signal Name) (Signal Name) LS1046A IIC2_SCL IIC2_SDA ↓ ↕ Module Connector I2C2_SCL I2C2_SDA ↓ ↕ MAX9611AUB ↓ ↕ PCA9517ADP Table 5-10 I²C-2 pin assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 32/68 © MicroSys Electronics GmbH 20178...
-
Page 33: Peripherals
LAN6 RJ45 connector 1G ✓ LAN7 RJ45 connector 1G ✓ LAN8 RJ45 connector 1G ✓ RJ45 connector 10G LAN9 ✓ LAN10 RJ45 connector 10G Table 6-1 Connector reference overview miriac SBC-LS1046A-TSN_User Manual V 2.0 33/68 © MicroSys Electronics GmbH 20178... -
Page 34: Module Connector
All manuals and user guides at all-guides.com Peripherals 6 6.2 Module Connector The carrierboard CRX06 provides a connector “ST4” which accepts compatible CPU modules from the MicroSys MPX2-family. Manufacturer: Type: MM70-314-310-B1-1-R300 Used with: MicroSys MPX2 module family 6.3 Serdes usage Serdes names reference to connector names. -
Page 35: Srd1 (Xfi / Sgmii)
Port 1 is connected to a 10G RJ-45 socket “LAN10”. It uses the SerDes Lanes 1 provided by the LS1046A CPU configured as SGMII port. The SGMII lanes connect to a Marvell PHY 88X3310P. 88X3310P LS1046A Name Signal Name ← ← SRD-TX1+ SRD-TX1+ SD1-TX0 miriac SBC-LS1046A-TSN_User Manual V 2.0 35/68 © MicroSys Electronics GmbH 20178... -
Page 36: Srd6 (Xfi / Sgmii)
SD-TX3 SRD2-TXQ+ SRD2-TXS- ← ← SRD-TX2- AE11 SD-TX3# SRD2-TXQ- SRD2-RXS+ → → SRD-RX2+ AG11 SD-RX3 SRD2-RXQ+ SRD2-RXS- → → SRD-RX2- AH11 SD-RX3# SRD2-RXQ- Table 6-6 SerDes 2 pin assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 36/68 © MicroSys Electronics GmbH 20178... -
Page 37: Srd3 (Qsgmii / Sgmii)
In case of QSGMII the system offers 4 ports 10/100/1000 Mbit. Connect to: LAN7-A, LAN7-B, LAN8-A, LAN8-B In case of SGMII the system offers only 1 port 10/100/1000 Mbit. Connect to: LAN7-A miriac SBC-LS1046A-TSN_User Manual V 2.0 37/68 © MicroSys Electronics GmbH 20178... -
Page 38: Tsn 1-4 Connections
MII1-RXD3 MII_RXD3 ← ← MII4-TX_CLK MII1-TXCK MII_TX_CLK ← ← MII4-TXD0 MII1-TXD0 MII_TXD0 ← ← MII4-TXD1 MII1-TXD1 MII_TXD1 ← ← MII4-TXD2 T100 MII1-TXD2 MII_TXD2 ← ← MII4-TXD3 T101 MII1-TXD3 MII_TXD3 miriac SBC-LS1046A-TSN_User Manual V 2.0 38/68 © MicroSys Electronics GmbH 20178... -
Page 39: Tsn 5-8 Connections
→ MII4-RXD2 MII2-RXD2 MII_RXD2 → → MII4-RXD3 MII2-RXD3 MII_RXD3 ← ← MII4-TX_CLK MII2-TXCK MII_TX_CLK ← ← MII4-TXD0 MII2-TXD0 MII_TXD0 ← ← MII4-TXD1 MII2-TXD1 MII_TXD1 ← ← MII4-TXD2 MII2-TXD2 MII_TXD2 miriac SBC-LS1046A-TSN_User Manual V 2.0 39/68 © MicroSys Electronics GmbH 20178... -
Page 40: Mdio1 Addressing
Table 6-11 LAN / MDIO1 / Addressing 6.4.8 MDIO2 addressing MDIO2 is connected to Phys: 2x 88X3310P. Part component Address 88X3310P Addr = 0x10h 88X3310P Addr = 0x11h Table 6-12 LAN / MDIO2 / Addressing miriac SBC-LS1046A-TSN_User Manual V 2.0 40/68 © MicroSys Electronics GmbH 20178... -
Page 41: Pcie Connections
PCIPWR. Voltage has to be exactly 12V. There is just protection for reverse polarity but no protection for overvoltage. Part Reference PCIPWR Manufacturer: Würth Elektronik Type: 691 382 010 002 Mates with: 691 381 000 002 miriac SBC-LS1046A-TSN_User Manual V 2.0 41/68 © MicroSys Electronics GmbH 20178... - Page 42 RSVD1 RFCLK+ RFCLK- PET0+ PET0- PER0+ PER0- PRSNT2# RSVD2 PET1+ PET1- PER1+ PER1- PET2+ PET2- PER2+ PER2- PET3+ PET3- PER3+ PER3- RSVD3 PRSNT2# RSVD4 Table 6-15 mPCIe Slot pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 42/68 © MicroSys Electronics GmbH 20178...
- Page 43 PET3+ SRD-TX7+ AD19 SD2_TX3_P ← ← PET3- SRD-TX7- AE19 SD2_TX3_N → → PER3+ SRD-RX7+ AG19 SD2_RX3_P → → PER3- SRD-RX7- AH19 SD2_RX3_N Table 6-16 PCIe Slot SerDes 4 assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 43/68 © MicroSys Electronics GmbH 20178...
-
Page 44: Microsd Card Slot
The microSD card slot uses a copy of the reference voltage on pin B81 of the module connector ST4 as I/O voltage (3.3V). This voltage is generated on the carrierboard. miriac SBC-LS1046A-TSN_User Manual V 2.0 44/68 © MicroSys Electronics GmbH 20178... -
Page 45: Usb
USB port 1 can be individually enabled and has a separate overcurrent signal. USB1_PWRFAULT is a high-active signal. A logic high level signals the port is in an overcurrent situation miriac SBC-LS1046A-TSN_User Manual V 2.0 45/68 © MicroSys Electronics GmbH 20178... -
Page 46: Usb2
USB port 2 can be individually enabled and has a separate overcurrent signal. USB2_PWRFAULT is a high-active signal. A logic high level signals the port is in an overcurrent situation miriac SBC-LS1046A-TSN_User Manual V 2.0 46/68 © MicroSys Electronics GmbH 20178... -
Page 47: Usb3
Used with: cables The following table shows the internal connections: LS1046A Signal Signal Name → Vbus+ UART1-RXD UART1_SIN ← UART1-TXD UART1_SOUT Table 6-20 USB Host-Only Port 3 pin assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 47/68 © MicroSys Electronics GmbH 20178... -
Page 48: Mcu Connector
All manuals and user guides at all-guides.com Peripherals 6 6.8 MCU Connector The connector “MCU” is for production test only. Part Reference: Manufacturer: Tag-Connect Type: TC2050-IDC-FP Signal Please contact MicroSys Table 6-21 MCU Connector Pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 48/68 © MicroSys Electronics GmbH 20178... -
Page 49: Jtag 1 Connector (Processor)
B106 TRST# TRST# ← ← JTDO B104 JTDO → → JTCK B105 JTCK → → PRST# B110 PRST# PORESET# → → JTDI B103 JTDI Table 6-22 JTAG Connector Pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 49/68 © MicroSys Electronics GmbH 20178... -
Page 50: Jtag 2 Connector (Carrier Components)
→ TDI ➔ J22 ➔ J23 ➔ J41 ➔ J42 ➔ J36 ➔ J31 (chain) → → TRST# J22, J23, J31, J36, J41, J42 Table 6-23 JTAG Connector Pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 50/68 © MicroSys Electronics GmbH 20178... -
Page 51: I2C / Spi Extension (Jp1)
UART2 is available on the following extension connector including hardware handshaking with RTS/CTS. The I/O range is LVTTL. UART1 handshaking RTS/CTS is available on the following extension connector. The I/O range is LVTTL. miriac SBC-LS1046A-TSN_User Manual V 2.0 51/68 © MicroSys Electronics GmbH 20178... - Page 52 ↔ GPIO-2 GPIO2_10 ↔ ↔ GPIO-3 B123 GPIO-3-18 GPIO2_11 ↔ ↔ GPIO-0 B122 GPIO-0-18 GPIO2_12 ↔ ↔ GPIO-1 B121 GPIO-1-18 +3.3V Table 6-25 I2C / SPI Extension Connector Pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 52/68 © MicroSys Electronics GmbH 20178...
-
Page 53: Fan Connector (Pwe)
All manuals and user guides at all-guides.com Peripherals 6 6.13 Fan Connector (PWE) The SBC-LS1046A-TSN provides a fan connector marked with „PWE“. In case a fan is necessary MicroSys recommends to use a 5V rated fan. Part Reference: Manufacturer: Würth Elektronik... -
Page 54: Switches, Buttons And Jumpers
The following table shows the internal connections of the BOOT-SEL pins: Microcontroller Switch Signal Signal Name → → BOOT-SEL1 T134 BOOT-SEL1 PTD4 → → BOOT-SEL2 T133 BOOT-SEL2 PTD5 Table 7-2 BOOT-SELx pin assignment miriac SBC-LS1046A-TSN_User Manual V 2.0 54/68 © MicroSys Electronics GmbH 20178... -
Page 55: Board Configuration Switch
EEPROM on I²C Bus1: Setting SW 2-1 SW 2-2 Description Watchdog disabled Watchdog active EEPROM J25: address 0x57 EEPROM J25: address 0x55 Table 7-3 Configuration switch settings miriac SBC-LS1046A-TSN_User Manual V 2.0 55/68 © MicroSys Electronics GmbH 20178... -
Page 56: Reset Button
The following table shows the internal connections: Microcontroller Signal Signal Name 1 & 3 +3,3V RST- → 2 & 4 ($39166) → → T136 RST-IN# PTC7 Table 7-4 Reset button pinout miriac SBC-LS1046A-TSN_User Manual V 2.0 56/68 © MicroSys Electronics GmbH 20178... -
Page 57: Leds
Default: 3 blinks – 1000Mbps / 2 blinks – 100 Mbps LAN10 / 1 blink – 10 Mbps / 0 blinks – no link LED-10G2-2 Right Yellow LED: off Table 8-1 Indicator LEDs miriac SBC-LS1046A-TSN_User Manual V 2.0 57/68 © MicroSys Electronics GmbH 20178... -
Page 58: Rj45 Leds Qsgmii
Green LED: configurable Default: 3 blinks – 1000Mbps / 2 blinks – 100 Mbps LAN6-A LAN3-LED0 P2_LED0 / 1 blink – 10 Mbps / 0 blinks – no link miriac SBC-LS1046A-TSN_User Manual V 2.0 58/68 © MicroSys Electronics GmbH 20178... -
Page 59: Rj45 Leds Tsn
/ 1 blink – 10 Mbps / 0 blinks – no link LAN2-A TSN2-LED2 Yellow LED: off Green LED: configurable LAN2-B TSN6-LED1 Default: On = Link / Off = no Link / Blink = Activity miriac SBC-LS1046A-TSN_User Manual V 2.0 59/68 © MicroSys Electronics GmbH 20178... - Page 60 Yellow LED: off LAN4-B TSN8-LED1 Green LED: configurable Default: On = Link / Off = no Link / Blink = Activity LAN4-B TSN8-LED2 Yellow LED: off Table 8-3 Indicator LEDs miriac SBC-LS1046A-TSN_User Manual V 2.0 60/68 © MicroSys Electronics GmbH 20178...
-
Page 61: Power And Reset Leds
LED ON: Power-up sequence of the module is finished, power is good Green LED OFF: Power fail LED ON: Module reset is active LED OFF: Reset is inactive Blue General Purpose LED Table 8-5 Indicator LEDs – Module miriac SBC-LS1046A-TSN_User Manual V 2.0 61/68 © MicroSys Electronics GmbH 20178... -
Page 62: Rgb Leds
LED5 0x15 LED6 LED7 is not connected LED8 LED9 0x16 LED10 LED11 is not connected LED12 LED13 0x17 LED14 LED15 is not connected Table 8-5 RGB LEDs – Carrier miriac SBC-LS1046A-TSN_User Manual V 2.0 62/68 © MicroSys Electronics GmbH 20178... -
Page 63: Software
Either boot option can be selected by the Boot Device Switch (see chapter 7). 9.2 Operating System Support MicroSys Electronics GmbH offers Linux and Microware OS-9 RTOS support for the board. Other Operating Systems are available on request only. -
Page 64: Flash Layout
0x0000_FFFF RCW + PBL 64kB 0x0001_0000 0x0003_FFFF FMAN Microcode 192kB 0x0004_0000 0x000F_FFFF reserved 768kB 0x0010_0000 0x001F_FFFF U-Boot 0x0020_0000 0x0023_FFFF Environment 256kB 0x0024_0000 SPI-SIZE-1 free Table 9-3 QSPI Flash layout miriac SBC-LS1046A-TSN_User Manual V 2.0 64/68 © MicroSys Electronics GmbH 20178... -
Page 65: Appendix
SBC ....................Single Board Computer SDRAM ..........Synchronous Dynamic Random Access Memory SerDes ............Serializer/Deserializer, Serializer/Deserializer SOM ......................System On Module UART ............Universal Asynchronous Receiver Transmitter USB ..................... Universal Serial Bus miriac SBC-LS1046A-TSN_User Manual V 2.0 65/68 © MicroSys Electronics GmbH 20178... -
Page 66: Table Of Figures
Table 6-8 Port 4 pin assignment ..................39 Table 6-9 Port 0-3 pin assignment ..................39 Table 6-10 Port 4-7 pin assignment ..................40 Table 6-11 LAN / MDIO1 / Addressing ................. 40 miriac SBC-LS1046A-TSN_User Manual V 2.0 66/68 © MicroSys Electronics GmbH 20178... - Page 67 Table 8-1 Indicator LEDs ..................... 57 Table 9-1 NAND Flash layout ....................64 Table 9-2 SD Card layout ..................... 64 Table 9-3 QSPI Flash layout ....................64 Table 11-1 Document history ....................68 miriac SBC-LS1046A-TSN_User Manual V 2.0 67/68 © MicroSys Electronics GmbH 20178...
-
Page 68: History
All manuals and user guides at all-guides.com History 11 11 History Date Version Change Description 2017-10-25 Release Version for carrier CRX06 Revision 1 2018-07-16 Changes to carrier CRX06-R2 Table 11-1 Document history miriac SBC-LS1046A-TSN_User Manual V 2.0 68/68 © MicroSys Electronics GmbH 20178...
