Summary of Contents for Bluebird EK430
- Page 1 EK430 ENTERPRISE KEY-BASED TOUCH MOBILE COMPUTER QUICK GUIDE...
-
Page 2: Registered Trademark
BLUEBIRD is an emerging global brand, striving to lead the market in performance and mobility. Their products represent reliability, innovation, and innovative technology. Bluebird is a registered trademark from the global brand of Bluebird Inc. and is copyright protected. • Bluebird and stylized Bluebird Logo are registered trademarks and symbols of Bluebird Inc. -
Page 3: Safety Information
1 Safety Information 1.1 Symbols This manual uses the following symbols to indicate hazards and additional information. Symbol Name Description Warning Indicates situations that could cause injury to yourself or others. Caution Indicates situations that could cause damage to your device or other equipment. Note Indicates additional information that can help you get the most out of the device. -
Page 4: Frequency Interference
Safety Information 1.3 Environment • Do not use the device while driving or operating heavy machinery. Doing so may result in death or serious injury. • Do not use the device in locations with combustible goods. Doing so may result in an explosion. •... -
Page 5: Package Contents
2 Overview 2.1 Package Contents The package includes: EK450 device Handstrap... -
Page 6: Your Device
Overview 2.2 Your Device 2.2.1 Front and Back Front Camera Proximity / Light sensor Charging / Notification LED Flash NFC Antenna Rear Camera Application Application Notification LED Notification LED Speaker Audio Jack External Device Connector C-Type Connector Handstrap Hole Scan Button Scan Button Battery Release Battery Release... - Page 7 Overview 2.2.2 Bottom and Top Barcode Reader Charging Connector...
-
Page 8: Turning The Device On Or Off
3 Basics 3.1 Turning the Device On or Off 3.1.1 Turning the Device On Press and hold the Power button for a few seconds. 3.1.2 Turning the Device Off Press and hold the Power button for a few seconds. Tap Power off. •... -
Page 9: Using The Touch Screen
Basic 3.2 Using the Touchscreen Use finger gestures to use the touchscreen effectively. • Do not touch the screen with any sharp objects. • Do not apply too much pressure to the touchscreen. Gesture Name Description Briefly touch an item to open, launch, or select it. Place two fingers on the screen and spread them apart to zoom Zoom in or out in. -
Page 10: Connecting To A Wi-Fi Network
Basic 3.3 Connecting to a Wi-Fi Network On the Home screen, tap > WLAN. Turn on a Wi-Fi networking and tap the network you want to join. If necessary, enter the password for the network. If you don’t know the password, contact the administrator for the network. -
Page 11: Device Specification
4 Device Specification Physical Characteristics Dimensions (W x H x D) 210 x 76 x 37 mm Weight 450g Display 4.3-Inch (480 x 800) WVGA, IPS Imager Window Corning Gorilla Glass Touchpanel Capacitive multi-touch Backlight LED backlight User replaceable Battery Li-Ion, 3.6V, 6,800mAh Power Smart Battery... -
Page 12: Communication Options
Device Specification User Environment Characteristics Operating Temp -20° C to 50° C / -4° F to 122° F Storage Temp -40°C to 70°C / -40°F to 158°F Humidity 5% to 95% RH (Non-condensing) Multiple 6 ft./1.8 m drops to concrete across the Drop Spec operating temperature range per MIL-STD-810G +/-15kVdc air discharge... -
Page 13: Troubleshooting
You can contact your local sales representative or you can send the device via a delivery service to Bluebird’s Korean headquarters. When sending the package, make sure you pay for the shipping fee in advance. When the repair is finished, Bluebird will cover the shipping cost. -
Page 14: Safety Regulatory
6 Safety Regulatory FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 15: Hearing Damage
Safety Regulatory EU Caution 5G / Wi-Fi Restrictions Maximum Power of RF This Enterprise Key-Based Touch Mobile Computer offers the following frequency bands in EU areas only and with the following maximum radio-frequency power: GSM 900: < 35 dBm • DCS 1800: <... -
Page 16: Power Adapter
The body SAR limit of EU (CE) is 2 W/kg averaged over one gram of tissue. This model EK430 has also been tested against this SAR limited. The highest SAR value reported under this standard during product certification for use at the body is 0.79 W/kg (5mm Separation Distance) and Limbs is 1.76 W/kg (0mm Separation Distance). -
Page 17: Warranty And Support
• We receive the products for our after-sales service through mail, delivery services and hand delivery only in principle. • If you bought the product from a party other than Bluebird or an authorized Bluebird reseller, you need to register the product before using our after-sales service. - Page 18 Safety Regulatory E-Label Users are able to access the 'E-Label Information' in no more than three steps in a device's menu. The actual steps are : Settings > System > Regulatory labels...
- Page 19 Warranty and Support Charged services • In the following cases, it will be charged when requesting for after-sales service. –– Service request due to inappropriate use of the device by the customer –– Loss of PIN number –– Use of programs that might affect the program (over-clock, forceful changes in the input of the system, personal developments) •...
-
Page 20: Warranty Certificate
Bluebird will repair or replace the defective product according to its warranty policy. • If the defective product within the range of warranty is not repairable or replaceable, Bluebird shall refund the purchasing price within a designated period from the date of receiving a notice of defect. - Page 21 (GMT Time: +9 Hours) The center is closed on Saturdays, Sundays, and Korean national holidays. Customer Service Center #1103, Gplus Kolon Digital Tower 11F, Digital-ro 26-gil 123, Guro-gu, Seoul, Republic of Korea(08390) Bluebird constantly strives to bring utmost satisfaction to all our customers.
