- Page 1 EF501R user BLUEBIRD version 1.0 manual...
-
Page 2: Registered Trademark
Bluebird Inc. and is copyright protected. • Bluebird and stylized Bluebird Logo are registered trademarks and symbols of Bluebird Inc. • Qualcomm ® IZat™ is a registered trademark of Qualcomm Atheros, Inc.trademark of Qualcomm Atheros, Inc. -
Page 3: Safety Information
Safety Information Symbols This manual uses the following symbols to indicate hazards and additional information. Symbol Name Description Warning Indicates situations that could cause injury to yourself or others. Indicates situations that could cause damage to your device or Caution other equipment. - Page 4 Safety Information Environment • Do not use the device while driving or operating heavy machinery. Doing so may result in death or serious injury. • Do not use the device in locations with combustible goods. Doing so may result in an explosion.
-
Page 5: Package Contents
Package Contents Package Contents EF501R device Battery Battery cover USB cable (Type C) • The illustrations may differ from your actual items. • To purchase additional accessories, contact your sales representative. • You can download your User Manual from www.mypidion.com. The paper version may be available for some regions. -
Page 6: Your Device
Your Device Front Name Description Allows user to hear the person they are talking to while on Receiver the phone. Indicates the status of the battery. The charging LED turns Charging LED red when the battery is charging and turns green when the battery is fully charged. - Page 7 Your Device Name Description Displays more option menus. If you tap and hold this button Menu button for a few seconds, the apps you previously opened will be listed. Tap any app to open it. Home button Returns to the Home screen. Speaker Emits sound.
- Page 8 Your Device Back Name Description Locks the battery cover so that it does not become Left battery lock detached from the device. Illuminates your surroundings when using the camera and Flash related apps. Rear camera Takes photos and record videos (13 Megapixel). Handstrap hole Secures the handstrap.
- Page 9 Your Device Bottom and Top Name Description Scans barcodes by emitting a red laser when you press the Barcode scanner related button. Headset jack Connects to the headset. Secondary Acts as sub microphone, removing noise and echoes. microphone Captures sound for calling, video recording, and speech Primary microphone recognition.
-
Page 10: Device Specification
Device Specification Physical Characteristics Dimensions (L x W x D) 166.5 X 88.75 X 28.9 mm Weight 360 g 5.0 inch HD (1280 X 720), Gorilla Glass 3 Display Capacitive Touch Screen Battery Rechargeable, 3.8 V, 6,400 mAh, Li-ion Customer-accessible microSD slot for removable Expansion slot memory cards with a capacity of up to 64 GB SIM/SAM slot... - Page 11 Device Specification User Environment Characteristics Durability TankSmith™ Technology Operating temperature -10 °C to 50 °C (14 °F to 122 °F) Storage temperature -40 °C to 70 °C (-40 °F to 158 °F) Humidity 95%, non-condensing Communication Options L TE B2 (850~1910 MHz, 24.50 dBm*) B4 (2500~2570 MHz, 24.50 dBm*) B5 (824~849 MHz, 24.00 dBm*) HSPA+/HSPA/UMTS...
- Page 12 Device Specification Bluetooth 4.2 BLE, Class 2 (2402~2480 MHz, 0.00 dBm) WPAN Radio (optional) Bluetooth (BDR/EDR) (2402~2480 MHz, 9.60 dBm) RFID NFC (13.56 MHz) * Conducted Power (dBm) WiFi in 5.15~5.25 GHz band="Indoor use only” Accessories Battery, Battery Cover, USB cable (Type C), Accessories Handstrap •...
- Page 13 Device Specification This device is compliant with the RED article 10.10 requirement because the information is available on the package. (Country: United Kingdom) Regulatory Articles • Article 10(2): Manufacturers shall ensure that radio equipment shall be so constructed that it can be operated in at least one Member State without infringing applicable requirements on the use of radio spectrum.
-
Page 14: Troubleshooting
You can contact your local sales representative or you can send the device via a delivery service to Bluebird’s Korean headquarters. When sending the package, make sure you pay for the shipping fee in advance. When the repair is finished, Bluebird will cover the shipping cost. -
Page 15: Safety Regulatory
Safety Regulatory FCC Cautions This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 16 Safety Regulatory Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 10 mm for body worn must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components.
-
Page 17: Warranty And Support
• We receive the products for our after-sales service through mail, delivery services and hand delivery only in principle. • If you bought the product from a party other than Bluebird or an authorized Bluebird reseller, you need to register the product before using our after-sales service. - Page 18 • Do not intentionally damage the label on the product. • A damaged label may result in a disadvantage to the customer. • When you return the product to Bluebird for service, please put the product in a protective box.
- Page 19 Bluebird will repair or replace the defective product according to its warranty policy. • If the defective product within the range of warranty is not repairable or replaceable, Bluebird shall refund the purchasing price within a designated period from the date of receiving a notice of defect.
- Page 20 (GMT Time: +9 Hours) The center is closed on Saturdays, Sundays, and Korean national holidays. Customer Service Center #1103, Gplus Kolon Digital Tower 11F, Digital-ro 26-gil 123, Guro-gu, Seoul, Republic of Korea(08390) Bluebird constantly strives to bring utmost satisfaction to all our customers.
