- Page 1 Inspiron 14 7420 2-in-1 Setup and Specifications Regulatory Model: P161G Regulatory Type: P161G001 May 2022 Rev. A01...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Chapter 1: Set up your Inspiron 14 7420 2-in-1................4 Chapter 2: Views of Inspiron 14 7420 2-in-1................... 6 Right....................................... 6 Left......................................6 Top......................................7 Front....................................... 8 Bottom....................................9 Modes.....................................9 Chapter 3: Using the privacy shutter.................... 11 Chapter 4: Specifications of Inspiron 14 7420 2-in-1..............12 Dimensions and weight.............................. -
Page 4: Chapter 1: Set Up Your Inspiron 14 7420 2-In-1
To conserve battery power, the battery might enter power-saving mode. Connect the power adapter and press the power button to turn on the computer. 2. Finish Windows setup. Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 5 Dell Digital Delivery Download software applications, which are purchased but not preinstalled on your computer. For more information on using Dell Digital Delivery, search in the Knowledge Base Resource at www.dell.com/support. SupportAssist SupportAssist proactively and predictively identifies hardware and software issues on your computer and automates the engagement process with Dell Technical support.
-
Page 6: Chapter 2: Views Of Inspiron 14 7420 2-In-1
Views of Inspiron 14 7420 2-in-1 Right 1. SD-card slot Reads from and writes to the SD card. The computer supports the following card types: ● Secure Digital (SD) ● Secure Digital High Capacity (SDHC) ● Secure Digital Extended Capacity (SDXC) 2. -
Page 7: Top
10 seconds to force shut-down the computer. If the power button has a fingerprint reader, place your finger on the power button to log in. NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/support/manuals. NOTE: The power-status light on the power button is available only on computers without the fingerprint reader. -
Page 8: Front
Enables you to video chat, capture photos, and record videos. 4. Camera-status light Turns on when the camera is in use. 5. Right microphone Provides digital sound input for audio recording and voice calls. Views of Inspiron 14 7420 2-in-1... -
Page 9: Bottom
1. Left speaker Provides audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3. Right speaker Provides audio output. - Page 10 Tablet Stand Tent Views of Inspiron 14 7420 2-in-1...
-
Page 11: Chapter 3: Using The Privacy Shutter
Using the privacy shutter 1. Slide the privacy shutter to the left to access the camera lens. 2. Slide the privacy shutter to the right to cover the camera lens. Using the privacy shutter... -
Page 12: Chapter 4: Specifications Of Inspiron 14 7420 2-In-1
Specifications of Inspiron 14 7420 2-in-1 Dimensions and weight The following table lists the height, width, depth, and weight of your Inspiron 14 7420 2-in-1. Table 3. Dimensions and weight Description Values Height: Front height 15.70 mm (0.61 in.) Rear height 17.86 mm (0.70 in.) -
Page 13: Chipset
Chipset The following table lists the details of the chipset supported by your Inspiron 14 7420 2-in-1. Table 5. Chipset Description Values Chipset Integrated in the processor Processor Generation Intel Core i3/i5/i7 DRAM bus width 64-bit Flash EPROM 32 MB... -
Page 14: External Ports
M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Wireless module The following table lists the Wireless Local Area Network (WLAN) modules supported on your Inspiron 14 7420 2-in-1. Table 9. Wireless module specifications Description Option one... -
Page 15: Audio
Option one Option two ● TKIP ● TKIP Bluetooth Bluetooth 5.2 Bluetooth 5.2 Audio The following table lists the audio specifications of your Inspiron 14 7420 2-in-1. Table 10. Audio specifications Description Values Audio controller Realtek ALC3254-CG Stereo conversion Supported... -
Page 16: Media-Card Reader
Media-card reader The following table lists the media cards supported by your Inspiron 14 7420 2-in-1. Table 12. Media-card reader specifications Description Values Media-card type One SD-card slot Media-cards supported ● Secure Digital (SD) ● Secure Digital High Capacity (SDHC) ●... -
Page 17: Touchpad
For more information about touchpad gestures available on Windows, see the Microsoft knowledge base article at support.microsoft.com. Power adapter The following table lists the power adapter specifications of your Inspiron 14 7420 2-in-1. Table 16. Power adapter specifications Description Values... -
Page 18: Battery
Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. Battery The following table lists the battery specifications of your Inspiron 14 7420 2-in-1. Table 17. Battery specifications Description... -
Page 19: Display
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption. -
Page 20: Gpu-Integrated
Memory type NVIDIA GeForce MX550 2 GB GDDR6 Operating and storage environment This table lists the operating and storage specifications of your Inspiron 14 7420 2-in-1. Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 21. Computer environment Description Operating... -
Page 21: Chapter 5: Comfortview
Dell low blue light displays optimize eye comfort with a flicker-free screen. The ComfortView feature reduces the amount of blue light emitted from the monitor to optimize eye comfort. ComfortView mode can be enabled and configured using the Dell CinemaColor (DCC) application. Dell ComfortView is certified by TÜV. -
Page 22: Chapter 6: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 23 Table 23. Secondary behavior (continued) Function key Behavior Fn + Space bar Emoji Fn + Left arrow Home Fn + Right arrow Keyboard shortcuts...
-
Page 24: Chapter 7: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 24. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app...
