Ink Bird IHT-2PB Manual

Bluetooth digital food thermometer with 2 external probes
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IHT-2PB
Bluetooth Digital Food
Thermometer
With 2 External Probes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IHT-2PB and is the answer not in the manual?

Questions and answers

Related Manuals for Ink Bird IHT-2PB

Summary of Contents for Ink Bird IHT-2PB

  • Page 1 IHT-2PB Bluetooth Digital Food Thermometer With 2 External Probes...

  • Page 3: Table Of Contents

    Contents Overview Features & Specifications Product Diagram Connection ● Free App Download ● Bluetooth Connection Key Definition Operation Instructions ● App Operating Functions ● Menu Instruction ● Parameter Setting Guide ● Operating Functions Of The Built-In Probe (unplugging the external probes) ●...

  • Page 4: Overview

    Features & Specifications ● Product Name: Bluetooth Digital Food Thermometer ● Product Model：IHT-2PB ● About 328 feet (100 meters) of Bluetooth controlling range in an open field ● 3 stainless steel probes for temperature measuring ●...

  • Page 5: Product Diagram

    Product Diagram ➀ LCD Screen & Backlight ➄ Probe 1/2 Sockets ➁ HOLD/UP Button ➅ Battery Charge Port ➂ SET Button ➆ Built-in Probe ➃ POWER/DOWN Button ➇ Magnetic Back - 02 -...

  • Page 6: Connection

    Connection Free App Download Get INKBIRD APP from Google Play or App Store for free, or you can scan the QR codes below to download the app directly. INKBIRD APP Please make sure the following requirements are met to download the apps smoothly: -Your devices must be running IOS11/Android 5.0 or above to download the app.
  • Page 7 Now you can add the device needed. Click “+” in the top right corner to add the device. - 04 -...
  • Page 8 Turn on the device. Make sure the Bluetooth icon is flashing. Search for device, please ensure that the equipment is within 10 meters. - 05 -...
  • Page 9 APP matching: The devices need to authorize the match. Click the SET button of the device IHT-2 PB to agree on authorization and allow the application to match the device. Connect successfully. - 06 -...

  • Page 10: Key Definition

    Key Definition Press and hold the button for 2 seconds to enter the menu for function setting. During the setting process, press the button to choose functions; press and hold the button for 2 seconds to quit and save setting changes. Press the button to turn on the device.

  • Page 11: Operation Instructions

    Operation Instructions App Operating Functions Operation Interface ● Ink@IHT-2PB#... Ink@IHT-2PB#... ℉ 77.7 191.0 ℉ Default Beef ℉ 76.3 Beef 170.0 ℉ Default Hold Timing ℉ 170.0 Default Reset Start ℉ 77.9 Hold Timing Reset Start - 08 -...
  • Page 12 Setting Menu ● Setting Device More Temperature unit ℃ ℉ Key sound Screen backlinght time Temperature correction ℉ ℉ ℉ - 09 -...
  • Page 13 More Settings ● Setting Device More Need a pop-up notification about temperature? Modification of equipment name Ink@IHT-2PB#366 REMOVE THE DEVICE vision 62:00:A1 1.0.8 :1C:4F: - 10 -...

  • Page 14: Menu Instruction

    Menu Instruction MENU DIS- SETTING DEFAULT FUNCTIONS ITEMS PLAY RANGE VALUES Celsius/ Fahrenheit Key sound ON or OFF Backlight 5~60S active time Alarm function ON/OFF for the built-in probe -50.0℃~300℃ 77.0℃ Alarm value for the built-in probe -58.0℉~572℉ 170℉ -4.9℃~4.9℃ 0.0℃...

  • Page 15: Parameter Setting Guide

    Parameter Setting Guide Temperature Display Unit of ℃/℉ Step 1: press and hold button for 2 seconds to enter the menu for function setting, then press the button to choose CF function. Step 2: press button to choose ℃ or ℉. NOTE: All parameters will be restored to their default values once you change the temperature unit.
  • Page 16 Step 3: press and hold button for 2 seconds to quit and save changes. (All changes will be automatically saved if there is no operation in 30 seconds.) Backlight Active Time Step 1: press and hold button for 2 seconds to enter the menu for function setting, then press the button to choose BLT function.
  • Page 17 Step 2: press button to choose ON or OFF. Step 3: press and hold button for 2 seconds to quit and save changes. (All changes will be automatically saved if there is no operation in 30 seconds.) Alarm Value Setting for the Built-in Probe Step 1: press and hold button for 2 seconds to enter the menu for function setting, then press the button to...
  • Page 18 Step 2: press button to increase or decrease the value; long press to quickly increase or decrease the value. Step 3: press and hold button for 2 seconds to quit and save changes. (All changes will be automatically saved if there is no operation in 30 seconds.) When the current temperature is 75.5℉, the screen displays 75.8℉...
  • Page 19 Step 1: press and hold button for 2 seconds to enter the menu for function setting, then press the button to choose TS1 function. Step 2: press button to increase or decrease the value; long press to quickly increase or decrease the value. Step 3: press and hold button for 2 seconds to quit and save changes.
  • Page 20 When the current temperature is 75.5℉, the screen displays 75.8℉ after setting the CA1 value as 0.3℉. Alarm Function for P2 (the External Probe 2) Step 1: press and hold button for 2 seconds to enter the menu for function setting, then press the button to choose ALM2 function.
  • Page 21 Step 2: press button to increase or decrease the value; long press or to quickly increase or decrease the value. Step 3: press and hold button for 2 seconds to quit and save changes. (All changes will be automatically saved if there is no operation in 30 seconds.) Temperature Calibration for P2 (the External Probe 2) Step 1: press and hold...

  • Page 22: Operating Functions Of The Built-In Probe

    When the current temperature is 75.5℉, the screen displays 75.8℉ after setting the CA2 value as 0.3℉. Operating Functions Of The Built-In Probe (unplugging the external probes) Screen Display Without plugging the external probes, the built-in probe is the current channel. The LCD screen displays data of the current channel in priority.
  • Page 23 Turn ON/OFF Automatically: The device is automatically turned on by unfolding the built-in probe. It is turned off when you fold the probe back. Manually: Press button to turn on the device. Regardless of the probe being folded or unfolded, you can press and hold button for 2 seconds to turn off the device.

  • Page 24: Bbq Functions (Plugging The External Probes)

    Backlight Backlight helps you check data conveniently. Without any operation, the backlight will keep activated for the time of BLT parameter, then be off automatically . You can press any button to activate it when it’s off. If you unfold the probe, the backlight will be activated automatically when the probe detects a temperature change.
  • Page 25 When you plug the external probe P2, the P2 probe is the current channel. The LCD screen displays data of the current channel in priority. P2 symbol appears on the screen. When ALM2=ON (the alarm function of P2 probe is on),the screen displays SET TEMP and the alarm value of P2probe.
  • Page 26 Alarm 1&2 Function When you set ALM1 (or ALM2) as OFF, the alarm function of P1 (or P2) probe is off, and the screen only display the current measured temperature. When you set ALM1 (or ALM2) as ON, the alarm function of P1 (or P2) probe is on, and the screen displays the alarm value of P1(or P2) probe (TS1/2) and the current measured temperature.

  • Page 27: Q&A About Abnormalities

    Display Switch Over Press and hold button for 3 seconds to switch to display data of the built-in probe. The screen will automatically return to display data of the current channels in 20 seconds if there is no more manual switchover.

  • Page 28: Important Notes/Warning

    contact with the P2 jack. contact with the P2 jack. If the display problem is still unsolved, or the screen If the display problem is still unsolved, or the screen displays “Er2”, please contact INKBIRD. displays “Er2”, please contact INKBIRD. Q4: Why can’t you turn on/off the thermometer by Q4: Why can’t you turn on/off the thermometer by folding/unfolding the probe?

  • Page 29: Product Warranty

    microwave ovens. microwave ovens. ● Please do not use the product beyond the temperature ● Please do not use the product beyond the temperature range from -50℃ to 300℃ (-58℉ to 572℉), or it may cause range from -50℃ to 300℃ (-58℉ to 572℉), or it may cause damages.
  • Page 30 pursuant to Part 15 of the FCC Rules. These limits are pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against designed to provide reasonable protection against harmful interference in a residential installation. This harmful interference in a residential installation.

  • Page 31: Meat Temperature &Doneness Chart

    Meat Temperature &Doneness Chart MEAT Rare M.Rare Medium M.Well Done 49℃/ 54℃/ 60℃/ 66℃/ Beef 77℃/170℉ 120℉ 130℉ 140℉ 150℉ 49℃/ 54℃/ 60℃/ 66℃/ 77℃/170℉ Veal 120℉ 130℉ 140℉ 150℉ 49℃/ 54℃/ 60℃/ 66℃/ 77℃/170℉ Lamb 120℉ 130℉ 140℉ 150℉ Pork 63℃/145℉...
  • Page 32 INKBIRD TECH.C.L. Support@inkbird.com Factory address: 6th Floor, Building 713, Pengji Liantang Industrial Area, NO.2 Pengxing Rd, Luohu Disctrict, Shenzhen, China Office address: Room 1803, Guowei Building, NO.68 Guowei Rd, Xianhu Community, Liantang, Luohu District,Shenzhen, China V5.0...
  • Page 33 骑马订 80*160mm 2021.12.17 修改内容：1.更新地址 2.更新版本号 2022.01.21 修改内容：1.15,16,17,19页内容修改 2.更新版本号 3.添加法国EPR认证标 2022.03.22 修改内容： 1.封底公司信息更新 2.版本号更新 2022.04.6 修改内容： 1.下载二维码更换（BBQGO PRO APP更 换为INKBIRDAPP 相应的文字和APP截图也更换） 2.版本号更新...
