Modulex MSP-080F Installation Manual page 2

Lighting Fixture
Installation Guide
SLICK JIAKARI
MSP-080F/20A/DL/3
Installation Details Installation Diagram
Install the mounting equipment
for ceiling cut out
1
Ceiling cut out
1 Cut out a hole and install the
mounting frame
Φ82
2 Slide the metal fittings from upper
side
3 Use a screw driver and tighten the
metal fittings
On step 2, please fix the metal
a fitting firmly with your fingers.
If not, it may cause falling of fixtures
Make sure to tighten the metal
fittings securely with a screwdriver.
b
(torque 1.0 〜2.0 N・m) If it is loose,
Metal fitting
it may cause falling of the fixture
Wiring connection
Please connect according to
the description of a power supply.
When connecting the driver,
careful attention should be
paid to connecting ＋ and −.
Metal part in a cable point,
please don't touch with bare
hand directly.
Installation to ceiling
Install the safety wire to the
1
mounting frame.
Install the fixture to the mounting
2
frame.
Make sure to install the safety wire
h
to the mounting frame securely.
2
Use clean soft cloth to clean up and
maintain inner side of the body.
i
Make sure the fixture will not touch
any objects in ceiling.
Caution
a
Mounting frame
2
Ceiling
3
Push tight
Wiring diagram
PE N L
DC700mA
35.6V
L N PE +
Driver
CAUTION！
Do not reverse polarity！
h
Safety wire
1
Ceiling
Mounting frame
Safety wire
b
Standard to screw
torque 1.0〜2.0N・m
MAX
+RED
-BLACK
LED
-
＋ RED
− BLACK
i
Inside
Clean gloves
（Contact）
