- Page 1 Core Health & Fitness LEVERAGE® ROW OWNER’S MANUAL...
- Page 2 TABLE OF CONTENTS PRODUCT SPOTLIGHT ............................. 2 ..................3 Warnings IMPORTANT LABEL LOCATIONS ............................. 6 EXERCISE GUIDELINES ............................. 7 INSTALLATION ............................. 8 ..................9 Hardware SUPPORT AND SERVICE ............................16 MAINTENANCE ............................17 WARRANTY ............................18 Page 1...
- Page 3 PRODUCT SPOTLIGHT NP-L3004 Leverage® Row Overall Weight Width Length Height User Weight 550 lbs (250 kg) 51” (130 cm) 79” (201 cm) 46” (117 cm) 0-350 lbs (0-159 kgs) All products may be covered by US and Foreign Patents and Patents Pending.
- Page 4 Check for damaged parts It is the sole responsibility of the purchaser of Nautilus® Leverage® to read the owner’s manual, warning labels and DO NOT use any equipment that is damaged and or has instruct all individuals, whether they are the end user or worn or broken parts.
- Page 5 16. It is the purchaser’s sole responsibility to properly Contact appropriate staff or Nautilus Service. instruct its end users and supervising personnel as to the proper operating procedures of all Nautilus equipment. 6. Ensure all adjustment and locking features are properly secured before using the equipment.
- Page 6 19. Routinely inspect all fasteners that join attachments and framework tighten as needed to maintain the integrity of the unit. 20. Perform regular maintenance checks on the NAUTILUS equipment. Also, pay close attention to all areas most susceptible to wear.
- Page 7 IMPORTANT LABEL LOCATIONS This page shows examples of the Nautilus® Leverage Strength® warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged each sample indicated includes its corresponding part number so that replacements may be ordered.
- Page 8 Also, be certain that all the stickers (safety, instructional and/or other) are read and understood by each user. • All users should be instructed on the proper use of NAUTILUS as well as those actions that should be avoided. •...
- Page 9 Nyloc nut is used.) • All NAUTILUS Strength equipment MUST be secured to the floor using either 10mm or 3/8in. (grade 5 minimum) bolts. • This Installation Instructions Manual must be used in conjunction with the equipment’s Owner’s Manual. The Owner’s manual describes equipment setup and instructs members on how to use it correctly and safely.
- Page 10 Hardware The following hardware is referenced in this assembly manual by the numbers below. Part No. Descrip on 110-3373 Screw, M10x1.5, 85mm, SHC, HK, AS, NKL, Gr-10.9 110-3402 SCREW, #8-18, 3/4", HI-LOW, PHT, PH, CS, BO 110-3576 SCREW, M8-1X50, SHHM, HE, SS 110-3930 SCREW,M10x1.5,140mm,SHC,HK,AS,NKL,PT,GR12.9 110-3936 SCREW,M10x1.5,70mm,HHC,HE,AS,ZC,GR12.9 110-3973 NUT,M10X1.5,AS,ZC,NYLON...
- Page 11 Assembly Instructions Attach the rear support frame to the main frame with two M10x1.5, 70mm bolts (#5), four #11 washers and two #9 nuts. Attach the left weldment to the main frame with two M10x1.5, 130mm bolts, #11 washers & #9 nuts vertically through the frame spacers.
- Page 12 Bearing Orientation: Lift Arms to Main Frame Repeat on left side weldment. With cotter pin secured, press in the end-caps until they snap into place securely, both left and right sides. Lower right lift arm onto bumper and confirm good alignment for the stop, adjust the coupling basket as necessary by loosening the two M8x1.25, 25mm bolts under the arm.
- Page 13 Independently assemble left and right lift assemblies by connecting the long weldment link to the bell crank weldment with a M10x1.5, 140mm bolt, #11 washer & #10 nylok nut. Please note the two bell cranks are non-symmetrical. Note the bearing differences when installing. Secure the right lift assembly to the main frame.
- Page 14 Connect the long weldment link to the main frame by passing a M10x1.5, 85mm bolt through the rod end and securing with #11 washer and #6 nut. Repeat steps 10-11 on the left hand side. Press in the end-caps 731-7683 until they snap into place securely, both left and right sides.
- Page 15 25 mm 25 mm 20 mm 20 mm # Part No. Description 1 731-6107 PIN, COTTER,3.2mmDIA x 32mm LONG 2 731-6104 Slotted Hex Nut,Low,M16X1.5mm 3 731-7111 WASHER,M16,30mmOD,1mmTHK 4 731-2595 TAPPER ROLLER BEARING, 30304 GB 297-9 5 731-0842 ASSY, BRG, TAPER, 30205 7 731-6430 BAR, PIVOT AXLE, L2, LONG 8 731-0355 WASHER,PLAIN,M8,NARROW 9 110-3576 SCREW, M8-1X50, SHHM, HE, SS...
- Page 16 Remove the set screw 731-0570 from the end of the chest pad assembly. Pull down on the pop pin to install the chest pad. Reinstall set screw once chest pad post is through weldment. Attach seat assembly to carriage with four M8x1.5, 20mm bolts and #8 washers.
- Page 17 SUPPORT AND SERVICE The Nautilus Support website provides a wealth of resources to help you get the best experience from your Strength unit. It is important to check the website periodically for updated video content, Owner’s Manual and Installation Instructions, Service Bulletins, and other information. The resourc- es include: •...
- Page 18 MAINTENANCE With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines out- lined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired.
- Page 19 WARRANTY Core Health & Fitness, LLC Limited Warranty Commercial Fitness Products CORE HEALTH & FITNESS, LLC, warrants to the original purchaser that its Commercial Fitness Products are free of defects in workmanship and materials. Mechanical parts are covered for a period of two (2) years from date of purchase. Electronic parts are covered for one (1) year from the date of purchase.
- Page 20 © 2018 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8418, REV B...
