- Page 1 SMALL FORM-FACTOR PLUGGABLE (SFP+/SFP28) MODULE INSTALLATION GUIDE...
-
Page 2: Table Of Contents
Contents Introduction ................................3 Laser Compliance ..............................3 Federal Communications Commission Notice ..................... 3 Installing the Transceiver Module ........................4 Removing the Transceiver Module ........................5 Appendix ................................6 Product Overview ................................... 6 Bail Latch Color ..................................6 EdgeOS Default Settings ............................... 6 SFP+ Module Specifications .............................. -
Page 3: Introduction
Introduction These installation instructions provide overview and specification information for small form-factor pluggable (SFP+/SFP28) modules, as well as instructions for installing and removing the modules. Laser Compliance The fiber-optic SFP+/SFP28 modules contain a laser that is classified as a “Class 1 Laser Product” in accordance with US FDA regulations and the IEC 60825-1. -
Page 4: Installing The Transceiver Module
Installing the Transceiver Module Small form factor transceiver modules (including SFP+ and SFP28 modules) plug into the SFP cage of a Silver Peak chassis. The installation process is identical for SFP+ and SFP28 modules. CAUTION: Observe electrostatic discharge (ESD) precautions when handling transceiver modules. -
Page 5: Removing The Transceiver Module
4. Inspect and clean the now uncovered fiber-optic end faces of the LC connectors. 5. Remove the dust cap from the module. Save the dust cap for future use. 6. Connect the LC connectors of the fiber-optic cable to the module. Removing the Transceiver Module To remove a transceiver (SFP+ or SFP28) module from an SFP cage, perform the following procedure. -
Page 6: Appendix
Appendix Product Overview Silver Peak small form-factor pluggable (SFP+ and SFP28) transceiver modules are hot-pluggable and field-replaceable. You can use the SFP modules for connecting to other devices. Only use Silver Peak SFP+/SFP28 modules in your Silver Peak chassis. Each module has an internal serial EEPROM that is encoded with security information. -
Page 7: Sfp+ Module Specifications
SFP+ Module Specifications EC-SFP-SR Parameter Minimum Maximum Optical Output Power (1G) –9.5 dBm –1 dBm Optical Receive Sensitivity (1G) –17 dBm Maximum Input Power (1G) + 0.5 dBm Optical Output Power (10G) –5 dBm –1 dBm Optical Receive Sensitivity (10G) –11.1 dBm Maximum Input Power (10G) + 0.5 dBm EC-SFP-LR Parameter Minimum Maximum Optical Output Power (1G) –11 dBm –3 dBm Optical Receive Sensitivity (1G) –19 dBm Maximum Input Power (1G) – 3 dBm Optical Output Power (10G) –8.2 dBm + 0.5 dBm ... -
Page 8: Fiber-Optic Cable Specifications
Fiber-Optic Cable Specifications EC‐SFP‐SR When Operated in 1000Base‐SX Mode Wavelength: 850 nanometers Modal Core Size Bandwidth Transmission Distance Cable Type Connector Type Cable Color (micron) (MHz/km) 62.5 160 220 m (722 feet) Multi‐mode, OM1 LC fiber Optics Orange 62.5 200 275 m (902 feet) Multi‐mode, OM1 LC fiber Optics Orange 50 400 500 m (1640 feet) Multi‐mode, OM2 LC fiber Optics Orange 50 500 550 m (1804 feet) Multi‐mode, OM2 LC fiber Optics Orange ... - Page 9 EC‐SFP‐LR When Operated in 10GBase‐LR Mode Wavelength: 1310 nanometers Core Size Transmission Distance Cable Type Connector Type Cable Color (micron) 9 10 km (6.21 miles) Single‐mode, OS2 LC fiber Optics Yellow EC‐SFP28‐25G‐SR When Operated in 10GBase‐SR Mode Wavelength: 850 nanometers Modal Core Size Bandwidth Transmission Distance Cable Type Connector Type Cable Color (micron) (MHz/km) 50 4700 550 m (1804 feet) Multi‐mode, OM4 LC fiber Optics Aqua EC‐SFP28‐25G‐SR When Operated in 25GBase‐SR Mode Wavelength: 850 nanometers ...
- Page 10 Document 201845 Rev. A www.arubanetworks.com 6280 America Center Drive, San Jose, CA 95002 1.877.210.7325 (toll-free in USA) | +1.408.935.1850 | www.silver-peak.com/support...
