Uni-bond E-915 Series Installation Manual

Wire Colour Function
Red Power
Black Ground
Yellow

Pattern Selection

Surface Mount: 2 Holes @ 4 " centres •
1.0 Pattern Selection
- Tap yellow wire to red wire (Power) momentarily to change patterns (see Flash Patterns)
To return to pattern NO. 1, touch yellow wire to red wire (Power) quickly 3 times.
-
1.1

Flash Patterns

NO.
1 Random Patterns
2 Alternating Single Flash
3 Alternating Double Flash
4 Alternating Quad Flash
5 Alternating Quint Flash
6 Alternating Quick Flash
7 Alternating Continuous High Intensity Flash
8 Alternating Single Flash / Quad Flash
9 Alternating Single Flash / High Intensity Flash
10 Simultaneous Single Flash
11 Simultaneous Double Flash
12 Simultaneous Quad Flash
13 Simultaneous Quint Flash
14 Simultaneous Quick Flash
15 Simultaneous High Intensity Flash
16 Simultaneous Single Flash / Quad Flash
17 Simultaneous Single Flash / High Intensity Flash
18 Steady Light on 3 Diodes & Single Flash on 3 Diodes
19 Steady Light on All
2.0 Suggested Switch Connection
Battery Ground
Ground
Power
Pattern Selection
For more information, visit our website at: www.unibondlighting.com
INSTALLATION MANUAL
Light should be fused with 5 Amp Fuse (
Flash Patterns
(switches sold separately)
E-915 Series LED Warning Lights
Connect To
+12/24 VDC (Power)
-
(Ground)
+12/24 VDC (Power)
E-915AA / E-915BB / E-915RR / E-915WW
E-915AA / E-915BB / E-915RR / E-915WW
E-915AA / E-915BB / E-915RR / E-915WW
E-915AA / E-915BB / E-915RR / E-915WW
E-915AA / E-915BB / E-915RR / E-915WW
From Battery Positive
Switch #1
ST307
(OFF-ON-Momentary ON)
For Synchronizing 2+ Lights
(
refer to Synchronization Manual
ATM05 sold separately
SAE Class 1
Jumper Wires
)
)
