Summary of Contents for nanoradar SR-PA24R
- Page 1 24G Radar Altimeter （SR-PA24R） User Manual Version：V1.0 Hunan Nanoradar Science and Technology Co., Ltd.
- Page 2 Any improper use may cause damage or injury, and Nanoradar would not bear the corresponding loss and liability. Product copyright is retained by Nanoradar. Reproduction in any form shall not be done without permission.
-
Page 3: Table Of Contents
Content 1 SR-PA24R Introduction....................4 2 Precautions........................4 3 Radar Parameter......................5 4 quick use steps......................5 4.1 Pin Definition....................5 4.2 Test........................5 5 Data Parsing........................ 6 6 open source platform....................6 6.1 Radar installation and wiring................7 6.2 MissionPlanner Ground station for flight control parameter setting....8... -
Page 4: Sr-Pa24R Introduction
1 SR-PA24R Introduction SR-PA24R is a professional 24G millimeter-wave radar altimeter for industrial drones. It uses 24GHz-ISM frequency band, with 2cm measurement accuracy, compact size, high sensitivity, light weight, easy integration and stable performance. The radar can output the distance from the drone to the ground in real time with strong anti-interference ability. -
Page 5: Radar Parameter
1.5W(typical value) Working Temperature -40~80℃ Weight 120g Dimension 130x70x14.5mm(LxWxH) 4 Quick use steps Pin Definition SR-PA24R Interface pin definitions, as shown in Table 2: Table 2 SR-PA24R pin definition Definition Range VCC(red) 5~20V DC GND(black) UART_RX (white) TTL 3.3V DC UART_TX (yellow) TTL 3.3VDC... -
Page 6: Data Parsing
Serial port debugging assistant software Note: The TX and RX pins of the USB to TTL adapter and the TX and RX pins of the SR-PA24R Radar need to be cross-connected. 5Data Parsing The 24G radar altimeter outputs data through the serial port, 115200bps, 8N1, no... -
Page 7: Radar Installation And Wiring
The following is a brief description of the integrated application settings of the SR-PA24R on the APM flight control platform. Flight Control Hardware: PixhawkV3 Flight Control Software: ArduPilot Copter 3.5.5 Ground station software: MissionPlanner 1.3.62... -
Page 8: Missionplanner Ground Station For Flight Control Parameter Setting
Pic 3 Radar Installation reference MissionPlanner Ground station for flight control parameter setting （ 1 ） Set the TELEM2 serial port parameters, the SERIAL2 baud rate is set to 115200bit/s (SERIAL2_BAUD is set to 115), and the communication protocol is set to Lidar (SERIAL2_PROTOCOL is set to 9), as shown in the following figure:... -
Page 9: Faq
7 FAQ （1）What is the angular accuracy of the SR-PA24R? The SR-PA24R is a 24GHz radar sensor is with one transmitter one reciever antenna, which can not be used to measure the angle of the target. （2）When SR-PA24R facing vegetation and ground/water surface when measuring... - Page 10 reference point is the ground or the water surface. If the aircraft fly above 5m, the airflow will not affect the vegetation below. If the vegetation density is high, then the detected height will be the distance from vegetation to the aircraft.
