Installation and Operation Instructions
MOD9200LON Spread Spectrum
Wireless LonWorks® Network Transceiver
8.26"
(209.8mm)
RJ45
RS232
8.78"
(223mm)
TOP VIEW
7.625"
(184.5mm)
TOP
SIDE VIEW
Figure #1
Page 1 of 3
Ø0.190 (4 PLCS.)
Data Link LED
Active LED
Antenna
Version : 1.0
I0000688
