  • Page 1 INSTRUCTION MANUAL 3-Tier 4x4ft Raised Garden Bed SKY2375 Ver. 2...
  • Page 2 NOTICE Please retain these instructions for future reference. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. •...
  • Page 3 PARTS CORNER CORNER CORNER CONNECTOR I CONNECTOR II CONNECTOR III 8 PCS 2 PCS 2 PCS CORNER CAP 12 PCS NOTE: Complete assembly on a flat level surface. PRODUCT ASSEMBLY - BOTTOM TIER Slide two part 1 long panels into two part 4 corner connectors, then repeat to assemble a second side.
  • Page 4 PRODUCT ASSEMBLY - BOTTOM TIER Connect the two side assemblies by inserting four part 1 long panels between the empty grooves on the part D corner connectors, two panels per side. Attach four part 7 corners caps to the bottom of the part 4 corner connectors with eight part 1 screws, two screws per cap.
  • Page 5 PRODUCT ASSEMBLY - MIDDLE TIER Assemble two sides by inserting two part 1 long panels between two part 4 corner connectors. Assemble a second side by inserting two part 1 long panels between a part 5 and 6 corner connectors. Connect the two side assemblies by inserting four part 2 medium panels between the empty grooves on the part 4, 5, and 6 corner connectors, two panels per side.
  • Page 6 PRODUCT ASSEMBLY – TOP TIER Assemble two sides by inserting two part 1 long panels between two part 4 corner connectors. Assemble a second side by inserting two part A long panels between a part 5 and 6 corner connectors. Connect the two side assemblies by inserting four part 3 short panels between the empty grooves on the part 4, 5, and 6 corner connectors, two panels per side.
  • Page 7 FINAL ASSEMBLY Stack the assembled tiers as shown below and overlap the three sets of part D corner connectors. Make sure the part A & B are fed into the grooves at the bottom of the part E corner connectors. Attach eight part 7 corner caps with sixteen part A screws, two screws per cap.
  • Page 8 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
