Basic Features

Viewing TV using the 3D function

¦
O
→ Picture → 3D → ENTERE
MENU
IMPORTANT HEALTH AND SAFETY INFORMATION FOR
3D PICTURES.
Read and understand the following safety information
before using the TV's 3D function.
[
WARNING
x
Some viewers may experience discomfort while
viewing 3D TV such as dizziness, nausea and
headaches. If you experience any such symptom,
stop viewing 3D TV, remove 3D Active Glasses and
rest.
x
Watching 3D images for an extended period of time
may cause eye strain. If you feel eye strain, stop
viewing 3D TV, remove your 3D Active Glasses and
rest.
x
A responsible adult should frequently check on
children who are using the 3D function. If there are
any reports of tired eyes, headaches, dizziness, or
nausea, have the child stop viewing 3D TV and rest.
x
Do not use the 3D Active Glasses for other purposes
(such as general eyeglasses, sunglasses, protective
goggles, etc.)
x
Do not use the 3D function or 3D Active Glasses
while walking or moving around. Using the 3D
function or 3D Active Glasses while moving around
may result in injuries due to running into objects,
tripping, and/or falling.
3D
This exciting new feature enables you to view
3D content. In order to fully enjoy this feature,
you must purchase a pair of Samsung 3D Active
Glasses (SSG-2100AB, SSG-2200AR, SSG-
2200KR) to view 3D video.
Samsung 3D Active Glasses are sold separately.
For more detailed purchasing information, contact the retailer
where you purchased this TV.
If there is any obstacle between the emitter and 3D
Active Glasses, the proper 3D effect may not be
obtained.
18
English
3D emitter
■ 3D Mode: Select the 3D input format.
If you want to feel the 3D effect fully, please wear
the 3D Active Glasses first, and then select 3D
Mode from the list below that provides the best
3d viewing experience.
When watching 3D images, turn on 3D Active
Glasses.
3D Mode
Off
2D → 3D
Side by Side
Top & Bottom
Line by Line
Vertical Stripe
Checker
Board
Frame
Sequential
"Side by Side" and "Top & Bottom" are available
when the resolution is 720p, 1080i and 1080p in
HDMI and USB mode or when set to PC and the
PC is connected through an HDMI/DVI cable.
"Vertical Strip", "Line by Line" and "Checker
Board" are available when the resolution is set to
PC and the PC is connected through an HDMI/
DVI cable.
"Frame Sequential" displays the frequency (60Hz
only) when the resolution is set to PC.
■ 3D → 2D (Off / On): Displays the image for the left eye
only.
This function is deactivated when 3D Mode is set
to "2D → 3D" or Off.
■ 3D View Point: The overall adjustment of 3D
perspective.
This function is deactivated when 3D Mode is set
to "2D → 3D" or Off.
■ Depth: Adjusts focus / depth in "2D → 3D" mode.
This function is only activated when the 3D Mode
is "2D → 3D".
■ Picture Correction: Adjusts the images for the left and
right eye.
Operation
Turns the 3D function off.
Changes a 2D image to 3D.
Displays two images next to
each other.
Displays one image above
another.
Displays the images for the left
and right eye alternately in rows.
Displays the images for the
left and right eye alternately in
columns.
Displays the images for the
left and right eye alternately in
pixels.
Displays the images for the
left and right eye alternately in
frames.
