- Page 1 LITHIUM IRON PHOSPHATE BATTERY FEN4850 (Outdoor battery for Telecom-5G) OPERATION MANUAL Version 1.0 NARADA POWER SOURCE CO., LTD Email: intl@narada.biz Website: en.naradapower.com...
-
Page 2: Table Of Contents
CONTENTS Notes Safety and Warning Product Introduction Product Features Main application Dimension Layout Working principle Technical Characteristic Discharge performance Charge performance Operation Three Parameter settings Operation condition Four Storage and Installation Storage Installation Five Maintenance General Troubleshooting and Solutions Annex1 Annex2 Annex3 Annex4... -
Page 3: Product Features
Narada FEN4850 lithium iron phosphate battery is a safe and reliable 5G micro-station backup The equipment shall be installed by the professional trained staff. power system, which can meet the backup power supply requirements of 5G micro stations, Battery maintenance should be carried out by the experienced professionals and aware of the network equipment, communication equipment, transmission equipment. -
Page 4: Dimension
Fig.1-1 Structural Drawing of FEN4850 Batteries Table 1-2 Instruction for Layout of Front Panel Detailed Information Marks Functions FEN4850 battery has 4 power input and output ports, each Power Input/ input and output port can input and output power Output Terminals independently, please see Annex 3 for details. -
Page 5: Working Principle
When grid power failure, lithium inside system supply DC power to the load, to ensure uninterrupted power supply as power system. Battery Management System (BMS) Smart BMS technology is adopted for battery modules of FEN4850 battery to assure smart automatic management for batteries. Features of BMS are shown as below:... -
Page 6: Discharge Performance
Battery modules can be controlled Chapter Two/02 remotely by staffs in control center. FEN4850 battery are in line with the requirements of the development of modern communications technology. Discharge performance It is combined by technologies of power source and computer. Parameters and status of rectifiers and AC/DC distributions can be detected and controlled. -
Page 7: Parameter Settings
Three/03 Chapter Four/04 Parameter settings Storage Lead-acid batteries can be replaced by lithium battery of FEN4850 battery if power is matched. ■ Storage temperature range: 0°C to 40°C. Table 3-1 is new parameter settings of power plant for lithium battery. -
Page 8: Installation
Installation 2.Installation the handle and corner guard Install the handle and corner protector on the battery with the mounting bolt provided by Narada. In order to facilitate the transportation of the battery, and protect the battery terminal from being Unboxing & Inspection ■... - Page 9 ■ 6.Battery output connection ■ Connect the battery and the device busbar through the power cable provided by Narada, and the cable has an anti-misconnection setting. ■ The red of the power cable is the positive, and the black is the negative.(See Annex 3) ■...
-
Page 10: General
Remove some unimportant load Protection against over current FEN4850 batteries can be used at an altitude of less than 5000 meters. If the altitude more and charge battery than 5000 meters, it will affect the battery performance and life due to... -
Page 11: Annex1
Annex 1-Instructions for LED Flash Annex 2 – Instructions for Parallel Communication FEN4850 battery packs are automatic assigned addresses through CAN bus for parallel Annex Table 1.1 – RUN Indicators Description communication, and RS485 interface realizes communication with PC or other intelligent terminals. -
Page 12: Annex3
