Polymer Lithium-ion Cell
Product Specification
Model: NL 3540108H
Approved
Accepted by Clients
Narada Power Source Co., Ltd
Address Wensan Rd. 459, Hangzhou, China CODE 310000
+86-21 5410 7268 Shanghai
+86-21 5410 7268 Shanghai
www.naradabattery.com
Specification Number B103540108H-01B
Edition No.1
Issue Date 2009-12-17
Total Page: 12
Reviewed
Prepared
+86-0755 2649 5056 Shenzhen
Advertisement
Table of Contents
Related Manuals for Narada NL 3540108H
Summary of Contents for Narada NL 3540108H
- Page 1 Model: NL 3540108H Approved Reviewed Prepared Accepted by Clients Narada Power Source Co., Ltd Address Wensan Rd. 459, Hangzhou, China CODE 310000 TEL +86-0571 2627 6088(Hangzhou) +86-0755 2649 5060 Shenzhen +86-21 5410 7268 Shanghai FAX +86-0571 2627 6058(Hangzhou) +86-0755 2649 5056 Shenzhen +86-21 5410 7268 Shanghai www.naradabattery.com...
- Page 2 NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification Revision History REVISION DATE RESON FOR CHANGE Arrow.com. Arrow.com. Downloaded from Downloaded from...
-
Page 3: Table Of Contents
NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification Content 1 Scope ……………………………………………………………………… 3 2 Description and Model …………………………………………………... 3 2.1 Description ……………………………………………………………………….. 3 2.2 Model …………………………………………………………………………….. 3 3 Technical Information …………………………………………………… 3 4 Cell Dimensions and Appearances ……………………….…….……….. -
Page 4: Scope
1 Scope This product specification defines the requirements of the rechargeable polymer lithium-ion cell supplied to the customer by Narada Power Source Co., Ltd. Should there be any dissidence in the test items or instructions, the customers are advised to contact Narada to find a solution. -
Page 5: Cell Dimensions And Appearances
NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification 4 Cell Dimensions and Appearances 4.1 Dimensions Item Battery Note Thickness (mm) 3.6(Cell) Pressure of measuring apparatus on 4.8(PCB) battery/cell is 300gf; cell dimension isn’t Width (mm) 40.5 include that of tab-lead. -
Page 6: Rest Time
NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification 5.4 Rest time Unless otherwise specified, the rest time between charge and discharge should be 30 minutes. 5.5 Initial Characteristics Item Test Instructions Criteria Test using AC Impedance method after... -
Page 7: Environmental Test (Only For References)
NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification 5.7 Environmental Test (only for reference) Item Test Instructions Criteria After full charge, store at 40 No leakage, no rust, 1 High Temp. and (90%~95%RH) for 48h. After test,... -
Page 8: Safety Characters Test
NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification 5.8 Safety Characters Test (only for reference) Item Test Instructions Criteria Connect cell with thermocouple and then place in ventilated cabinet, charge cell with a constant current of 3C... -
Page 9: Guidebook For Polymer Lithium-Ion Batteries
NL 3540108H Specification 7 Guidebook for polymer lithium-ion batteries Note the following advice to ensure right use of Narada polymer lithium-ion cell. Narada should not be responsible for any problem resulted from abuse. DANGER To prevent the possibility of cell leakage, catch fire, or explosion, pay attention to the following item. - Page 10 NARADA POWER SOURCE CO., LTD Polymer Li-ion Battery NL 3540108H Specification WARNINGS! 1.Do not use or leave the cell at very high temperature (for example, at strong direct sunlight or in a vehicle in extremely hot weather). Otherwise, it can overheat or fire or its performance will be degenerate and its service life will be decreased.
-
