- Page 1 Manual DLC-010 09-05-22 Cover LINK...
-
Page 2: Table Of Contents
Page 8 Page 10 Calibration ................Correction ................. Page 11 Dead Man Switch settings ............. Page 11 DLC-010 in combination with LinkTouch & PLP-REM(-350) Installation instructions ............Page 12 Page 13 Calibration ................Dead Man Switch settings ............. Page 13... -
Page 3: Box Content
Ingress protection rate: IP54 IEC Protection Class: Class I Introduction The DLC-010 is a controller for the DuraCover System The device has following functionalities: • Programmable open and close positions • Local control (via key switch) and/or remote control (via LinkTouch + PLP-REM(-350)) •... -
Page 4: Dlc-010 Overview
“FORCE” Slide switch DIP switch CAN switch In case the DLC-010 is at the start or end posi- tion of the CAN bus, make sure to switch the CAN CAN LED Flashes when CAN communication load switch to the right position. (termination re-... -
Page 5: Dlc-010 As Stand-Alone Unit
Connect the ‘open’ and ‘close’ terminals of the key switch to the key switch terminal blocks (terminal nrs 9, 10, 11, 12) Make sure DIP switch 1 is set to the OFF position, so the DLC-010 will be controlled locally, via the keyswitch... -
Page 6: Calibration
During calibration, the ‘open’ and ‘close’ position of the DuraCover System During correction, the ‘open’ and ‘close’ position can be updated without are saved in the memory of the DLC-010. After this calibration, the user can restarting the full calibration process. This function is only possible if a cali- open and close the cover safely without crossing the end positions. -
Page 7: Dlc-010 In Combination With Linktouch & Plp-Rem
Settings menu 230VAC * The DLC-010 can always be controlled with a Key-switch, even when a LinkTouch is confi gured * Also see LinkTouch manual ** We recommend using a shielded twisted pair cable (min. 0,5mm² - up to 200m) -
Page 8: Operation Modes
Operation Modes CALIBRATION The status LED blinks green. MODE STATUS LED COVER MOVEMENT FILTERPUMP The cover can be controlled locally (via the key switch) and remote (via Link- Touch), but only in DMS mode: the cover stops immediately when the con- Disabled when cover NORMAL Green... -
Page 9: Troubleshooting
Check DIP switch 1 position DIP switch 1 must be ON can not be started Check CAN LED Fix the CAN wiring Declaraction of Conformity Declarations of conformity covering this product are available for download from the House of Duratech website: www.duratech.be... - Page 10 VISION HEAT FLOW COVER Tube LINK Driver Moonlight Hot Splash Inverter VISION Spectra HEAT Sun Spring COVER Motor LINK Touch VISION Adagio Pro HEAT Dura V COVER Wall Duct LINK Controller VISION HEAT LINK Dura Vi COVER Cable Duct Cover VISION Wall Conduits HEAT...
