Joy-it BUTTON22 Quick Start Manual

High-current microswitch button with led light

BUTTON22

High-current microswitch button with LED light

1. GENERAL INFORMATION

Dear customer,

Thank you for purchasing our product. In the following, we will show you

which things should be noted during the use.

Should you encounter any unexpected problems, do not hesitate to

This manual is about the Button22A, Button22B and Button22C. In the

following, you will find how to connect your button and what you have to

consider during your usage.

For your own safety, this product may only be

installed by a qualified electrician! Working on

electric devices / systems implies the hazard of

electric shocks which may cause serious injuries or

even death!

Table of Contents

Need help?

Do you have a question about the BUTTON22 and is the answer not in the manual?

Page 1 BUTTON22 High-current microswitch button with LED light 1. GENERAL INFORMATION Dear customer, Thank you for purchasing our product. In the following, we will show you which things should be noted during the use. Should you encounter any unexpected problems, do not hesitate to contact us.
Page 2 2. LATCHING OR MOMENTARY We offer this type of buttons as latching or momentary. Here, latching means that the button holds the pressed position. Momentary means that the button automatically resumes its original position after being pressed. This is, for example, marked in the article number of our buttons as L (latching) or as M (momentary).
Page 3 4. CONNECTION BUTTON 22B Cable Connection 3 to 8 V Black Yellow Blue When using the buttons 22B, you can use NC or NO, as required, by using both cables of the corresponding color for the power supply. 5. CONNECTION BUTTON 22C With this button you always connect red to black.
Page 4 SIMAC Electronics GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germa- Possibility of return in your area: We will send you a parcel stamp with which you can return the device to us free of charge. Please contact us by email at Service@joy-it.net or by telephone. Information on packaging: If you do not have suitable packaging material or do not wish to use your own, please contact us and we will send you suitable packaging.
