- Page 1 MASK LIGHT AMPLIFIED MIC QUICK REFERENCE GUIDE 1002682-00 REV A © 2021 Gentex Corporation. Gentex is a registered trademark of Gentex Corporation or its affiliates.
-
Page 2: Installation
INSTALLATION Follow these steps to install the Mask Light Amplified Mic. For removal, reverse the order of operations. Align the external assembly such that the screws match with the two outer holes on mask. NOTE: Do not remove rubber cover. - Page 3 Orient the internal assembly such that it bends over the top and the switch will be at the bottom of the mask cavity when installed. Align the internal assembly pins to match the inner holes in the mask. Press the internal assembly into place until the push pins snap together.
-
Page 4: Operation
Communications Test Set or other microphone test equipment OPERATION Follow these steps to operate the Mask Light Amplified Mic. POWER ON/OFF Use tongue switch to toggle the LED on and off. LED BRIGHTNESS Press and hold the tongue switch to cycle through the three (3) brightness... -
Page 5: Inspection And Maintenance
INSPECTION & MAINTENANCE This section contains instructions for organizational inspection and maintenance of the Mask Light Amplified Mic . Perform the inspections listed in Table 1 each time the Mask Light Amplified Microphone requires inspection Table 1 – Inspection and Maintenance... -
Page 6: Troubleshooting
TROUBLESHOOTING This section contains the most common problems that can occur with the Mask Light Amplified Mic along with probable causes of malfunction and recommended corrective actions . Table 1 – Inspection and Maintenance Item Problem Probable Cause Remedy Loose or broken or not properly A. -
Page 7: Replacement Parts
REPLACEMENT PARTS This section contains the part numbers for spare replaceable parts and kits for this product . Part Number Description 1001682-00 Mask Light Amplified Microphone Assembly 1001682-02 External Assembly, Mask Light Amplified Microphone Replacement Kit 1001682-01 Internal Assembly, Mask Light Amplified Microphone Replacement Kit 1002682-00 Quick Reference Guide, Mask Light AM...
