- Page 1 PureLite XStream Self-Contained Powered Air Purifying Visor System User Manual This product is covered by one or more patents. For more information visit www.gentexcorp.com/patents 414607...
-
Page 3: Table Of Contents
TABLE OF CONTENTS User Instructions Approval for Use Suitability for Use Preparation for Use Wearing and Using Parts List Servicing Storage Technical Specification Decontamination & Return Procedure Customer Support... -
Page 5: User Instructions
USER INSTRUCTIONS Please read these instructions and then store them in a safe place for future reference. The PureLite XStream must be fitted and used in accordance with these instructions. Introduction The PureLite XStream is a self-contained, lightweight Powered Air Purifying unit intended for protection against solid dusts, impacts to eyes and face, and eye and face protection from liquid chemical splash. -
Page 6: Approval For Use
APPROVAL FOR USE This product is NOT APPROVED BY NIOSH. The PureLite XStream has been assessed under Article 10 and 11B assessments conducted by: British Standards Institution, Maylands Avenue, Hemel Hempstead, Herts, HP2 4SQ, UK. (Notified Body Number: 0086) Respiratory Protection BS EN 12941 1999, respiratory devices, powered filtering devices class TH2P. - Page 7 • The PureLite XStream is only for use by trained, competent personnel • In the power-off state little or no respiratory protection is to be expected, and this is considered to be an abnormal situation • In the power-off state there will be a rapid buildup of carbon dioxide and depletion of oxygen may occur •...
-
Page 8: Preparation For Use
PREPARATION FOR USE The following tasks must be performed prior to use: Battery Charging and Installation The nominal recharge time for a flat battery pack is 14 hours. The battery pack must be fully charged before first use. To install and charge the battery pack: •... - Page 9 Visual Inspection • Check the face seal material for damage • Check the face seal attachment to the chassis and visor of the PureLite XStream • Check the visor seal for damage Replace any damaged parts including scratched or damaged visors. Airflow Pre-Use Check Fig.
-
Page 10: Wearing And Using
WEARING AND USING Fitting the PureLite XStream • Adjust the crown strap length on the headband as shown in Fig. 5A so that the headband rests against brow • Adjust headband diameter by pulling the knob out and rotating for head size, push the knob in to secure as shown in Fig. - Page 11 Removing the PureLite XStream • Switch off the fan/motor by operating the red on/off switch • Pull out the knob and to release headband and remove Cleaning the PureLite XStream • Use a clean cloth with a mild solution of a household liquid soap and water. (PUREWIPE cleaning wipes are recommended for this purpose) •...
-
Page 12: Parts List
PARTS LIST Complete Kit Product Order Description Designation Number Complete unit with filters, battery, PureLite XStream PL03001-1 battery charger, airflow indicator, storage/carry bag, user manual Spare/Replacement Parts Reference Fig. 7 on opposite page. Item# Order# Description PL01173-5SP Visor Assembly PL01176-4SP Head Cover &... - Page 13 Accessories Reference Fig. 7 Item# Order# Description PL01182SP-4SP Charge Cradle Fig. 7...
-
Page 14: Servicing
SERVICING CAUTION: Dust on the unit, its parts, and filters from usage should be handled in a safe manner in accordance with the manufacturer’s safety data information. Visor Overlay (optional) Replacement Install a new set of visor overlays by adhering to the main visor using the adhesive strips provided. - Page 15 Face Seal Replacement Replace the face seal as shown in Fig. 9 below. • Unsnap the face seal from the snaps starting from the center of the visor snap studs on face seal • Remove the head band (see Headband assembly and Fig. 10 on page 12) and remove the crown pad by separating the hook &...
- Page 16 SERVICING (CONTINUED) Headband Assembly Replacement Remove face seal and visor (shown in Figs. 8 and 9 on pages 10-11). NOTE: The visor stiffener does not need to be removed from the visor. Install the face seal on the headband (as described on page 11) and install the new headband assembly as shown in Fig.
- Page 17 Air Filter Replacement CAUTION: Dust on the unit, its parts, and filters from usage should be handled in a safe manner in accordance with the manufacturer’s safety data information. Lift the cover as shown in Fig. 1 and replace air filter as shown in Fig. 3: •...
- Page 18 SERVICING (CONTINUED) Fan/Motor Assembly Replacement Lift the cover as shown in Fig. 1 and replace fan/motor assembly as shown in Fig. 11 on opposite page: • Disconnect fan/motor electrical lead from the electronics unit • Remove the two screws securing the front air duct •...
- Page 19 Fig. 1 Fig. 11...
- Page 20 SERVICING (CONTINUED) Electronics Unit Replacement Lift the cover as shown in Fig. 1 and replace the electronics unit as shown in Fig. 12 below. Fig. 1 Fig. 12...
-
Page 21: Storage
STORAGE The equipment should be stored in dry, clean conditions away from direct sunlight, sources of heat, petrol and solvent vapors. Store the equipment within the temperature range 41°F to 104°F and the humidity range 0-90%. TECHNICAL SPECIFICATION Weight 2.2 lbs nominal Head Size Range 54- 61cm Humidity... -
Page 22: Decontamination & Return Procedure
DECONTAMINATION & RETURN PROCEDURE IMPORTANT NOTICE: Gentex Corporation requires the customer seeking to return for service or repair, whether warranty or non-warranty, to call our customer service department and obtain a Return Authorization (RA) number. We will not accept any unit for service or repair without the customer obtaining an RA number. -
Page 23: Customer Support
CUSTOMER SUPPORT Gentex Corporation 324 Main Street Simson, PA, USA 18407 Tel: (570) 282-3550 or (800) 251-7377 email: sales@helmetsystems.com www.gentexcorp.com... - Page 24 PureLite XStream User Manual REV. 20181016 Copyright © 2018 Gentex Corporation. PureFlo is a trademark of Gentex Corporation or its affiliates.
