Summary of Contents for Samsung DVD-N2000
- Page 2 recautions RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates “danger- ous voltage” inside the product that presents a risk of electric shock or personal injury. CAUTION: DVD PLAYERS USE AN INVISIBLE LASER BEAM WHICH CAN CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE PLAYER CORRECTLY AS INSTRUCTED.
-
Page 3: Handling Cautions
• This unit can be used only where the power supply is AC 120V, 60Hz. It cannot be used elsewhere. • This DVD player is designed and manufactured to respond to the Region Management Information. If the Region number of a DVD disc does not correspond to the Region number of this DVD player, the DVD player cannot play the disc. -
Page 4: Discs You Can Play
• Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected DVD discs. -
Page 5: Table Of Contents
Remote Control Setting Troubleshooting Guide Tour of the Remote Control ... 1 0 • DVD Function Buttons ... 11 • TV Function Buttons ... 11 • Samsung N2000 Joystick ... 12 • Connection to a TV ... 14 MediaMacro .. 16 ActionCapture... -
Page 6: Before You Start
efore You Start Accessories Remote Control S-Video Cable Install Batteries in the Remote 1 Open the battery cover on the back of the remote. 2 Insert two AA batteries. Make sure that the polarities (+ and -) are aligned correctly. 3 Replace the battery cover. -
Page 7: Description
2 3 4 HEAD Front Panel Controls 1 STANDBY/ON • When the unit is first plugged in, this indicator lights. 2 NUON PORTS • Allow you to plug in joystick or other peripherals. 3 HEADPHONES JACK • You can attach headphones here for private listening. 4 HEADPHONES VOLUME •... -
Page 8: Front Panel Display
ront Panel Display 3 5 6 Front Panel Indicators 1 Indicates Disc is turning 2 Disc playback 3 Disc type indicators 4 Still picture or audio pause 5 Lights when 3D surround is turned on. 6 Angle indicator. You can select multiple angles of a scene recorded by different cameras. -
Page 9: Rear Panel
CENTER OPTICAL COAXIAL DIGITAL AUDIO OUT 5.1CH SURROUND AUDIO OUT Rear Panel Jacks 1 DIGITAL AUDIO OUT JACK • Use either an optical or coaxial digital cable to connect to a compatible Dolby Digital receiver. Use to connect to an A/V Amplifier that contains a Dolby Digital decoder or DTS decoder. - Page 10 our of the Remote Contro l...
-
Page 11: Dvd Function Buttons
DVD Function Buttons 1 DVD POWER 2 NUMBER 3 OPEN/CLOSE 4 SETUP/SNAP SHOT • During normal play, pressing the SETUP button will bring up the DVD player's Setup menu. When the SETUP button is pressed in the "pause" mode (when the PAUSE but- ton has been pressed), a special image processing menu comes up on the screen. -
Page 12: Samsung N2000 Joystick
amsung N2000 Joystick Joystick Controls 1 D (Up/ Down/ Left/ Right) Button 2 Front Left Button 3 NUON Button 4 B Button 5 Front Right Button 6 Start Button 7 A Button 8 C (Up/ Down/ Left/ Right) Buttons... -
Page 13: Choosing A Connection
The following show examples of connections commonly used to connect the DVD player with a TV and other components. • Always turn off the DVD player, TV, and other components before you con- nect or disconnect any cables. • Refer to user’s manual of the components you are connecting for more infor- mation on those particular components. -
Page 14: Connection To A Tv
TV (Normal, Widescreen, Projection, etc..) AUDIO OUT Connection to a TV (For Video) • Method 1 DVD Player + TV with Video Input Jack • Method 2 DVD Player + TV with S-Video Input Jack • Method 3 DVD Player + TV with Component Video Jacks... -
Page 15: Using The Setup Menu
The Setup Menu lets you customize your DVD player by allowing you to select various lan- guage preferences, set up a parental control, even adjust the player to the type of television screen you have. Press the SETUP button on the remote. -
Page 16: Setting Up The Language Features
etting Up the Language Features Using the Audio Language SETUP MENU SETUP MENU 1 Disc Menu English 2 Audio English 3 Subtitle Aut o mat i c 4 Parental Unlocked 5 Audio Options 6 Display Options Audio Language English Francais Deutsch Nederlands Oesky... -
Page 17: Playing A Disc
Playback Press the OPEN/CLOSE button. The STANDBY indicator light goes out and the tray opens. Place a disc gently into the tray with the disc’s label facing up. Press the PLAY/PAUSE button to start playback. Press the STOP button to stop playback. RESUME function When you stop disc play, the player remembers where you stopped, so when you press PLAY again, it will pick up where you left off (unless the disc is removed, the STOP button... - Page 18 laying a Disc Stop Press the STOP button during playback. Remove Press the OPEN/CLOSE button. Pause Press the PLAY/PAUSE or STEP button on the remote during playback. - Screen stops, no sound. - To resume, press the PLAY/PAUSE button once again. Step Motion (Except CD) Press the STEP button on the remote during playback.
-
Page 19: Search & Skip
Press the FWD or REV SEARCH button on the remote or turn the SHUTTLE dial on the front of the DVD player during play back. • Press the REVERSE or FORWARD SEARCH button on the remote and press again to search at a faster speed(2X/4X/8X/16X/32X/normal speed, in order) on the DVD. -
Page 20: A-B Repeat & 3D Sound
The simulated surround effect (SPATIALIZER N-2-2) depends on the disc contents. If you connect the unit to your stereo system, you can enhance sound quality and produce a greater surround effect. This feature is useful when you are using the DVD player with a two channel stereo through the analog outputs. -
Page 21: Bookmark
The Bookmark function lets you select parts of a DVD or VCD so that you can quickly find the section at a later time. < - - - > Bookmark Press enter to mark To store a Bookmark Use the LEFT/RIGHT button to move to the desired book- mark. -
Page 22: Mediamacro Zoom & Pan
ediaMacro MediaMacro Zoom & Pan For DVDs, VCDs This function allows complete control over what part of the picture you want to see. You can select any portion of the screen and magnify that portion up to 20 times. Pressing the ZOOM button one time, brings up a square frame (Zoom 1 state as shown in the figure above left). -
Page 23: Actioncapture
ctionCapture ActionCapture Strobe This unique strobe function takes snapshots of a continuous motion, then displays these snapshots in order. This is a useful method of analyzing golf swings, a pianist's finger movements or even a pitcher's technique. The screen is divided into fixed 9 subscreens. Press the button. -
Page 24: Angleview Display & Screen Fit
Display & Screen Fit Using the ANGLE button The DVD-N2000 displays each angle in a portion of the screen, allowing you to select any angle at the touch of the ergonomic remote. Example) If there are 3 angles available Screen Fit Press the SCREEN FIT button on the remote or the front panel. -
Page 25: Selecting The Audio Language
You can select a desired language quickly and easily with the AUDIO button. Using the AUDIO Button Audio English Dolby Digital 5.1 Audio Stereo Using the MENU Button AUDIO SUBTITLE ENGLISH FRANCAIS (example) NOTE • This function depends on what languages are encoded on the disc and may not work with all DVDs. -
Page 26: Selecting The Subtitle Language
electing the Subtitle Language You can select a desired subtitle quickly and easily with the SUBTITLE button. Using the SUBTITLE Button Subtitle Subtitle Using the MENU Button AUDIO SUBTITLE ENGLISH FRANCAIS (example) NOTE • This function depends on what languages are encoded on the disc and may not work with all DVDs. -
Page 27: Spectrum Analyzer & Game
Press the PLAY/PAUSE button to start playback. - Samsung N2000 Joystick button Mapping for DVD, VCD, CDDA playback. Button map- ping for Nuon depends on the Nuon disc. Nuon button usage is different from disc to disc. - Unplugging and replugging a joystick when playing a game may cause program dys- function. -
Page 28: Using The Display Function
Display Menu The unique “SmartMatrix user interface” on Screen Display of the DVD-N2000 allows instant access to both the DVD features and the more advanced PC-like functions. And the picture is never out of view, as these advanced graphics can be displayed simultaneously with the DVD images. -
Page 29: Setting Up The Disc Language
If you set the disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie. Using the Disc Menu Language SETUP MENU SETUP MENU 1 Disc Menu English 2 Audio English 3 Subtitle Aut o mat i c 4 Parental Unlocked... -
Page 30: Setting Up The Parental Control
etting Up the Parental Contro l The Parental Control function works in conjunction with DVDs that have been assigned a rat- ing - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. -
Page 31: Setting Up The Audio Options
SPEAKER SETUP - CASE 1 -11 : Use the LEFT/RIGHT button to select the desired speaker setup. There are 11 different speaker settings to optimize the DVD player to your audio system. - Speaker Setup is only available in Bitstream mode. -
Page 32: Setting Up The Display Options
etting Up the Display Options SETUP MENU SETUP MENU 1 Disc Menu 2 Audio 3 Subtitle 4 Parental 5 Audio Options 6 Display Options TV Aspect Front Display < > Auto / Bright / Dim Black Level Press the SETUP button. Use the UP/DOWN button to select DISPLAY OPTIONS. -
Page 33: Remote Control Setting
TV. While holding the TV POWER button down, enter the code for your brand. - For Samsung A TVs While holding down the TV button, enter 0. If the TV turns off, setup is complete. Enter other codes of the same brand if the first code does not work. -
Page 34: Troubleshooting Guide
No audio. • Press power on from a cold start with no disc in the unit. Press Forgot password • Turn the player off and unplug it to reset the DVD player. Will not read disc or other error message. -
Page 35: Specifications
Audio *Frequency Response Output *S/N Ratio *Dynamic Range *Total Harmonic Distortion • Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • Weight and dimensions are approximate. AC 120 V, 60 Hz 21 W 7.5 lbs W 16.9 in x D 11.0 in x H 3.5 in... - Page 36 NUON Interactive Software, neither VM Labs nor any of VM Labs' licensees will be liable for any damage. This situation is not caused by a defect in the DVD player or NUON games; other fixed or repetitive images may cause similar damage to a pro-...
-
Page 37: Warranty
Transportation to and from the service center is the responsibility of the purchaser. SAMSUNG will repair or replace this product, at our option and at no charge with new or reconditioned parts, if found to be defective during the limited warranty period specified above. - Page 38 REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
-
Page 39: Limited Warranty To Original Purchaser
Warranty (for Canada users only) LIMITED WARRANTY TO ORIGINAL PURCHASER Samsung Electronics Canada Inc.(SECA), warrants that this product is free from defective material and workmanship. SECA further warrants that if this product falls to operate properly within the specified war- ranty period and the failure is due to improper workmanship or defective materials, SECA will repair or replace the product at its option.
