BGS technic 8471 Instruction Manual

TECHNICAL DATA
Chuck size: 10 mm (3/8")
Free speed: 2090
Max. working speed:
Air consumption: 99 l/min
Working pressure: 6.2 bar (90 psi)
Max. pressure: 8.6 bar (125 psi)
Air inlet: 1/4"
Total length: 195 mm
Sound pressure level
Sound power level
Vibration level (ahd): 0.8 m/s²
Vibration level (K): 0.1 m/s²
Weight: 0.9 kg
INTENDED USE
This air tool is used to make holes, to drill out studs and to make holes bigger.
ATTENTION
Read the operating instructions and all safety instructions contained therein carefully before using the
product. Use the product correctly, with care and only according to the intended purpose. Non-
compliance of the safety instructions may lead to damage, personal injury and to termination of the
warranty. Keep these instructions in a safe and dry location for future reference. Enclose the
operating instructions when handing over the product to third parties.
SAFETY INFORMATIONS
When using pneumatic tools, fundamental precautionary measures must always be ensured in order
to reduce the risk of personal injury and property damage.
• Keep children and unauthorised persons away from the work area.
• Do not let any children play with the tool or its packaging.
• Make sure that the work area is sufficiently illuminated.
• Keep the work area clean, organised, dry and free from other materials.
• Do allow untrained persons work with this tool set.
• Ensure that the trigger is located in the OFF position when being connected to the compressed
air system.
• Do not carry out any modifications on the tool.
• Use only accessories that are dimensioned for use with compressed air tools, e.g. with impact
wrenches, for manual use do not use conventional sockets, use only power sockets.
• Disconnect the tool from the compressed air supply before installing accessories, when carrying
out maintenance work or the device is not being used.
• Maintain the tool with care. Check hoses and compressed air connections at regular intervals.
• Do not use the tool if it is damaged. Have the tool repaired by specialist personnel.
• When installing regulators, filters and other accessories, observe the manufacturer
specifications of the compressed air system.
• Store the tool in a dry and safe location out of the reach of children.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Air Angle Drill
rpm
1800 rpm
(LpA): 83 dB(A)
(LwA): 94 dB(A)
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 8471
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
