Global Fire Equipment VALKYRIE AS Manual

Mechanical Specification

Enclosure Construction Material
White or Red ABS
Weight
Sounder/ Beacon - 254 g*
Including packaging - 304 g
*including mounting base
Order Code
VALKYRIE AS-WHITE
Valkyrie Addressable Wall Sounder/Beacon-White
VALKYRIE ASB-WHITE
VALKYRIE AS-RED
VALKYRIE ASB-RED
GFE-ISO-BASE
GFE-ISO-BASE-RED

Technical Specifications

Supply Voltage
Loop Current - Quiescent
Loop Current -Alarm Low. Freq.
Loop Current -Alarm High. Freq.
Loop Current -Alarm Beacon
Sounder Output - Continuous
Sounder Output - Low Freq.
Sounder Output - High Freq.
Max. Cable Size
Max. Humidity
Operating Temperature
Enclosure - Material
Protection Category
Dimensions
Weight
110.0
100.5
All dimensions in mm
Valkyrie Addressable Wall Sounder-White
Valkyrie Addressable Wall Sounder-Red
Valkyrie Addressable Wall Sounder/Beacon-Red
Detector Base with Loop Isolator
Detector Base with Loop Isolator-Red
17V to 30 V DC
0.5 mA
4.1 mA (Max.) - 2.6 mA (Min.)
7.5 mA (Max.) - 3 mA (Min.)
1.4 mA
102 dB @ 1 m (Max.) - 97 dB @ 1 m (Min.)
103 dB @ 1 m (Max.) - 98 dB @ 1 m (Min.)
110 dB @ 1 m (Max.) - 100 dB @ 1 m (Min.)
2
2.5 mm
95% RH Non-Condensing
0 C to 40 C
º º
Red/ White ABS
IP44
110.0 mm (Dia) x 85.1 mm (H)
254 g - including mounting base
Valkyrie A
Addressable Wall Sounder - Beacon
The VALKYRIE A is a wall mounted
addressable sounder with low power
consumption available in either Red
or White housings. Up to 32
individually addressed sounders can
be installed per loop occupying an
address in the range 94 to 125. The
address is set using switches 1 to 5
of the 8 way DIL switch.
F
our different tones are available
and selected using DIL switches 6
and 7.
When individual address reporting is
not required, VALKYRIE A can be
configured as a Shadow sounder. In
this case sounders do not occupy an
address in the loop thus freeing up
addresses for more detection
devices.
Shadow sounders do not report back
to the control panel so
presence on the loop is
monitored. Shadow sounders draw
current from the loop (maximum 7.5
mA in alarm for sounder/ beacon
version @ High frequency settings)
and must be included in loop load
calculations.
Instruction Manual V2.0- 12/2010

Features

High Quality
Complies with EN-54 pt.3
their
Low current consumption
not
4.1 mA for combined Sounder/Beacon
110 dB maximum sounder output at 1 m
Synchronization for fast activation
Compatible with all GFE addressable panels
