ALT ThermOne 1840 Installation & Care Manual

Complete trim kit with cartridge and handle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Collection 1840
#18231
ThermOne
complete trim kit with cartridge
and handle
ThermOne
Garniture pour
avec cartouche et
poignée
Installation & Care Guide
Guide d'installation et d'entretien
Cartridge maximum temperature is factory set at 43˚C (109.4˚F). To adjust
maximum up to 49˚C (120.2˚F), please refer to installation instructions.
La température maximale de la cartouche est pré-réglée en usine à
43˚C (109.4˚F). Pour augmenter la température jusqu'à un maximum
de 49˚C (120.2˚F), veuillez consulter le guide d'installation.
last revision: 25/10/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThermOne 1840 and is the answer not in the manual?

Questions and answers

Related Manuals for ALT ThermOne 1840

Summary of Contents for ALT ThermOne 1840

  • Page 1 Collection 1840 #18231 ThermOne complete trim kit with cartridge and handle ThermOne Garniture pour avec cartouche et poignée Installation & Care Guide Guide d’installation et d’entretien Cartridge maximum temperature is factory set at 43˚C (109.4˚F). To adjust maximum up to 49˚C (120.2˚F), please refer to installation instructions. La température maximale de la cartouche est pré-réglée en usine à...
  • Page 2 Félicitations pour l’achat de purchase of your Alt product votre produit Alt By purchasing an Alt product, you are taking part in En achetant un produit Alt, vous prenez part au the global movement for better living. We take pride in mouvement global pour le mieux-vivre.
  • Page 3 TRIM KIT COMPONENTS COMPOSANTS DE LA GARNITURE SPECS AT LARGE / SCHÉMA DES PIÈCES ALT7-18-066-xx: 1840 handle / poignée 1840 ALT7-CTCB-0967-xx: Dome cap / Capuchon en dôme ALT7-60-848-xx: Trim plate + screw / Plaque +vis ALT7-50-418-00: Cartridge with spacer / Cartouche avec espaceur ALT7-00-418-00: Cartridge / Cartouche...
  • Page 4 BEFORE YOU START AVANT DE COMMENCER CAUTION: FOR BEST RESULTS, WE STRONGLY MISE EN GARDE: POUR OBTENIR UN RÉSULTAT RECOMMEND THE INSTALLATION OF THIS VALVE BE OPTIMAL, NOUS RECOMMANDONS FORTEMENT QUE DONE BY A LICENSED PLUMBER. L’INSTALLATION DE CETTE VALVE SOIT FAITE PAR UN PLOMBIER ACCRÉDITÉ.

  • Page 5: Installing The Cartridge

    INSTALLATION Installing the cartridge First, verify the 2 check-valves (1 & 2) are shut off. Unscrew the cartridge holder (3) and remove the protective plug (4) (Fig. 1). Make sure the "top" plastic spacer remains in place (5). Insert the cartridge (5) into the valve body as shown Fig.2.
  • Page 6 INSTALLATION Installing the trim kit Insert the decorative sleeve (1) onto the cartridge holder (Fig.3), then screw the dome cap (4) onto the valve body. Slide in trim (2) around the valve body and press it firmly against the wall. Make sure the trim is properly aligned with red marking (HOT water) on the left and blue marking (COLD water) on the right.

  • Page 7: Water Temperature Adjustment

    INSTALLATION Water temperature adjustment The cartridge maximum temperature is factory set at 43˚C (109.4˚F). To adjust maximum up to 48˚C (119˚F): It can be adjusted following these steps: Remove the decorative cap (1), the set screw (2), the handle (3) and the dome cap (4) (Fig.4). Pull out the temperature limiting ring (5) from the cartridge (6).

  • Page 8: Maintenance Entretien

    MAINTENANCE ENTRETIEN To Service The Cartridge If necessary, shut off the main water supply, then remove all the components from (1) to (5). Fig.5. Afterwards, shut off the 2 check valves (8) by turning them clockwise with a screwdriver. Unscrew the cartridge holder (6) and remove the cartridge (7) (Fig.
  • Page 9 CARE SOIN To clean your ALT faucet or accessory, wash with a Pour nettoyer et conserver l’apparence de vos wet nonabrasive soapy cloth. Then wipe dry with a robinets ou accesoires ALT, lavez-les avec un linge soft towel or cloth. We recommend this be done on mouillé...

  • Page 10: Warranty

    Any labor or shipping charges, or damages whatsoever incurred in whole or in part from installation, removal, re-installation, repair or replacement of any Alt product or part, as well as any incidental or consequential damages, expenses, losses, direct or indirect, arising from any cause whatsoever.

  • Page 11: Garantie

    GARANTIE Alt offre une garantie à vie contre les défauts de matériel et de main d’œuvre dans des conditions normales d’utilisation et d’entretien du produit, et ce tant que l’acheteur d’origine est propriétaire de sa maison. La garantie est applicable seulement si le produit est acheté chez un détaillant Alt dûment autorisé.

This manual is also suitable for:

Thermone 18231
