HATO 300 SILENT 1000N
HATO 300 SILENT 1200N
OPERATING MANUAL FOR GARAGE DRIVES
1000N
1200N
1
HATO 300 Silent

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 SILENT 1000N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HATO 300 SILENT 1000N

Summary of Contents for HATO 300 SILENT 1000N

  • Page 1 HATO 300 Silent OPERATING MANUAL FOR GARAGE DRIVES HATO 300 SILENT 1000N 1000N HATO 300 SILENT 1200N 1200N...

  • Page 2: Table Of Contents

    Maintenance ................................22 Technical Specifications ………………………………………………………………………………..……...………..23 List of components ……………………………………………………………………………………………………………24 Problems and solutions ………………………………………………………………………………………………………25 ATTENTION !!! Declaration of conformity The HATO 300 SILENT drive meets the requirements of the following regulations: Please read manual carefully before Complies with the conditions of the Machinery Directive 2006/42 / EC Annex II installation and use.
  • Page 3 IMPORTANTS SAFETY INSTRUCTIONS FAILURE TO OBSERVE THE FOLLOWING SAFETY PRECAUTIONS COULD RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR DAMAGE TO YOUR PROPERTY. 1. PLEASE READ CAREFULLY AND COMPLY WITH ALL SAFETY AND INSTALLATION RECOMMENDATIONS. 2. The drive has been designed and manufactured in accordance with local regulations. The installer must be familiar with local regulations required to install the drive.

  • Page 4: Product Description And Specification

    PRODUCT DESCRIPTION AND SPECIFICATION 1. Regulation of the clamping force The contact pressure can be adjusted: Display "1" minimum force. "5" indicates maximum force. 2. Speed control "8" shown on the display means 80% of the driving speed. "A" is displayed for full speed (160 mm / s or 200 mm / s).

  • Page 5: Preparation

    position. 17. Manualne otwieranie awaryjne In the event of loss of power or failure, the drive has a manual gate opening system by decoupling the gate and the rail. 18. Transmitter (REMOTE) The remote control works in rolling code technology (7.38 x 1019 combinations), frequency 433.92 MHz, 4 channels are designed to provide control of up to 4 different doors with one transmitter.

  • Page 6: Assembly (Rail And Handles)

    Fig. 1 ASSEMBLY Wall mount and door bracket (Fig. 2 ) Wall mount - Close the garage door and measure the width of the garage door at the top and mark the center. Install a 3cm-15cm wall mount above the door on the inside wall.
  • Page 7 Place the steel track and drive centrally on the garage floor with the cardboard underneath. Lift the front of the guide up to the door support. Insert the pivot pin and secure it with the supplied split pin. STEP 3 (Fig. 3, Fig.4) Raise and support the motor head (ladder) so that it is centered and level.
  • Page 8 1. Pull the threaded rod together with the toothed belt to the end position of the rail. Fig.8 1. As in Fig.9, install the nut and spring. 2. Tighten the nut, setting the correct belt tension Fig.10 Fig.10 Fig.9 Attention! For a split rail, use the support in the center of the rail. Battery backup kit (optional) Option 1 - top mounting STEP 1 (Fig.

  • Page 9: Control Panel Operation Manual

    Option 2 – side mounting STEP 1 (Fig. 13) Assemble the battery and battery bracket as shown in the picture, fix with the supplied screws. STEP 2 (Fig. 14) Attach the battery to the drive, see Figure 14. Fig. 13 Fig.

  • Page 10: Programming Instructions

    PROGRAMMING INSTRUCTIONS Remote control programming manual. Pressing the SET button shortly in the standby state clears the errors and enters the normal standby state. 1. Briefly press the CODE button: • (In setting mode) Exit the current operation and return to the standby interface. •...

  • Page 11: Programming

    PROGRAMMING ADJUSTMENT OF THE END POSITIONS a) Press and hold SET button to enter the function, the display shows "1", then release the button b) Briefly press the SET button. The door drive is now in end position programming mode. Then "n" will appear with a dot flashing on the screen c) Press and hold the UP button until the door reaches the open position you want, you will see "n"...
  • Page 12 2. SETTING THE DRIVE FORCE ATTENTION! The adjustment of the force of reaction to an obstacle is set automatically during programming. Usually, no customization is necessary. a) Press and hold the SET button, the display shows "1", then press the UP button, the display shows "2", when the button is released.
  • Page 13 3. SETTING THE TRAVEL SPEED NOTE: If you change the speed, it will override the previous limit switch settings. It is necessary to readjust the end positions. a) Press and hold the SET button until the display shows "1", then press the UP button until the display shows "3.
  • Page 14 5. SETTING THE AUTOMATIC CLOSURE CONDITIONS a) Press and hold SET button until display shows "1", then press UP button until display shows "5. b) Press the SET button. The device is now in the auto-closing condition setting mode. The display will show the number "1" with a dot blinking. c) Press UP / DOWN button once to set auto close mode.
  • Page 15 6. SETTING THE LAMP OFF TIME a) Press and hold the SET button until the display shows "1", then press the UP button until the display shows "6". b) Press the SET button again. The fixture is now in LAMP delay time adjustment mode.
  • Page 16 8. ADJUSTING THE HEIGHT OF THE PARTIAL OPENING OF THE GATE a) Press and hold the SET button until the display shows "1", then press the 7. GATE RETURN HEIGHT SETTINGS UP button until the display shows "8", a) Press and hold the SET button until the display shows "1", then press b) Press the SET button again.
  • Page 17 9. SETTING FUNCTION OF TRANSMITTER BUTTONS a) Press and hold the SET button until the display shows "1", then press the UP button until the display shows "9". b) Press the SET button again. The device is now in the button recognition function setting mode.
  • Page 18 A. SETTING THE AMOUNT OF CODES MEMORY a) Press and hold the SET button until the display shows "1", then press the UP button until the display shows "A". b) Press the SET button again, the device is now in the remotes memory setting mode.
  • Page 19 C. SETTING THE SERVICE DOOR FUNCTIONS a) Press and hold the SET button until the display shows "1", then press the UP button until the display shows "C". b) Press the SET button again. The device is now in the service door switch type selection mode.
  • Page 20 E. MAINTENANCE ALARM - CYCLE COUNT a) Press and hold SET button until display shows "1", then press UP button until display shows "E" b) Press the SET button again. The equipment is now in maintenance alarm adjustment mode. The display will show "0" with a flashing dot. c) Press the UP / DOWN button to select the appropriate number of cycles after which the alarm will occur.

  • Page 21: Connecting Additional Accessories

    CONNECTING ADDITIONAL ACCESSORIES ADDITIONAL ACCESSORIES 1. Possibility to connect the O / S / C interface (Fig. 15) An additional O / S / C button can be installed to open and close the door. We connect e.g. an external radio module to the same terminals PB (signal) / GND (ground) - bell type button (normally open contacts NO).
  • Page 22 There is a suitable interface for this function which provides beacon voltage in the range of 24v-35v. Connect a DC 24v-28v warning lamp, current ≤100mA. 3. Service door protection (Fig. 15) This function prevents the gate from being opened when the service door is open, preventing damage to the door. The service door contact type (NO or NC) is programmable.

  • Page 23: Manual Opening

    Fig.16 Connection of photocells MANUAL OPENING The drive rail is equipped with a clutch with a rope, thanks to which we can disconnect the drive from the rail and manually lift the gate. Pull the rope to disengage (Fig. 17). To reconnect the drive with the rail, start the drive or manually move the door until the spanner engages (connecting the trolley to the chain).

  • Page 24: Technical Specifications

    Make sure that safety devices are working effectively (photocells, etc.) 1. Electronics boards do not require any special maintenance. 2. In case of a maintenance alarm, the LEDs blink 10 times fast, it means the garage door is out of balance, maintenance / service is recommended.

  • Page 25: List Of Components

    LIST OF COMPONENTS Description Description Fixing the gear wheel L.E.D cover Mounting bracket U Control panel cover 1 Strengthening handle Control panel cover 2 Steel rail C Main cover PROBLEMS AND SOLUTIONS Mounting bracket L.E.D Lamp Gear PCB-1 Gear wheel bracket PCB-2 Problem Cause...
  • Page 26 power board 4. Check that the power cord is connected 5. Check whether the low voltage side of transformer is 26V AC, if there is 26V AC, replace PCB. If not, replace transformer While programming The route is set at less than 30 cm or more than Re-set the end positions the display shows Display shows...
  • Page 27 3. Get rid of the distractions 3. Local disturbances No more remote controls can be added The new remote control is not compatible with Use only original HATO remotes for drives the drive The display shows Maximum number of remotes assigned to the...
  • Page 28 ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………………………………… DISTRIBUTOR...
  • Page 29 HATO TRADE SP. Z O.O. ul. Tunelowa 57 40-676 Katowice POLAND tel. 032-785-25-42 www.hato.pl Magazyn i sprzedaż; ul. Żeromskiego 1 41-205 Sosnowiec...
