- Page 1 HATO 600.. HT 1000 HT 1200 OPERATING MANUAL FOR GARAGE DRIVES...
-
Page 2: Table Of Contents
MAINTENANCE, USE ................................17 Declaration of conformity ATTENTION!!! The Hato HT 600/1000/1200 complies with the requirements of the following regulations: It complies with the Please read the manual carefully before installation conditions of the machinery directive 2006/42/WE Annex II, section B, as and use. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FAILURE TO OBSERVE THE FOLLOWING SAFETY PRECAUTIONS COULD RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR DAMAGE TO YOUR PROPERTY. 1. PLEASE READ CAREFULLY AND COMPLY WITH ALL SAFETY AND INSTALLATION RECOMMENDATIONS. 2. The drive has been designed and manufactured in accordance with local regulations. The installer must be familiar with local regulations required to install the drive. -
Page 4: Technical Specification
TECHNICAL SPECIFICATION HT 600 HT1000 HT1200 Supply voltage 230V AC +/-10% 50̴ - 60Hz Motor 24V DC Strength 600N 1000N 1200N Operating temperature -20°C +50°C Permissible humidity ≤90% Remote control operating frequency 433,92 Mhz Lighting Backlight time 3 minutes Remote control range... -
Page 6: Assembly
ASSEMBLY Tighten 4 screws 1008d x4 1019d Place the splines on the engine pin Hand-tighten the motor mounts 1012d with four nuts 1007d x4 Important! Tighten the nuts before starting the drive for the first time... - Page 7 Fastening the rail Attaching the handle to the wall for lifting the gate 1025d x1 1015d x1 For overhead gates it is recommended to fasten the handle through with screws 1006d x2 1007d x2...
- Page 8 1025d x1 1005d x2 1007d x2 !!! The rail should be mounted horizontally, above the guide line (min. 30mm) !!! Mounting the rail reinforcement (optional) 1018d...
- Page 9 Installation of the maximum opening limiter 1021d x1 1022d x1 1005d x1 Connect the flat bar L 1013d with desengagement 1017d with metal lock 1001d i 1002d If the length of the L 1013d flat bar is too short, it can be extended with a 1014d flat bar. An example on the next page.
- Page 10 Example of door connection with drive disengagement: Option 1 - when the distance between the upper edge of the closed gate and the guide does not exceed 25 cm. Option 2 - when the distance between the upper edge of the closed gate and the guide exceeds 25 cm.
- Page 11 Fastening a flat bar to the gate handle with a steel sleeve and a cotter pin Sleeve - 1001d x1 Cotter - 1002d x1 PREPARATION 1. Bracket No. 1020d should be screwed to the engine, it is used to fix the engine to the ceiling. This bracket is not included in the kit.
-
Page 12: Diagram (Optional Accessories)
DIAGRAM (optional accessories) DIAGRAM OF CONNECTING ADDITIONAL ACCESSORIES NC service door switch NO button Fuse socket (bell) Battery (backup power supply) Universal radio Photocell Photocell receiver transmitter... - Page 13 Control of all functions via the Control Panel The remote control has four buttons (channels). Depending on the functions included in the operator, the remote control can operate from one to four different garage doors. With the gate and ventilation interlocks disabled - 4 gates.
-
Page 14: Remote Controls' Programming
CLEARING MEMORY OF REMOTE CONTROLS Clearing the remote control’s memory should be performed when installing the drive. This ensures that the code of any remote control other than the one owned by the owner is not stored in the drive's memory. -
Page 15: Adjusting The Closing Force
function. We turn on the ventilation function and only now log the buttons of all remote controls for opening / closing. ADJUSTING THE CLOSING FORCE When setting the closing force, pay attention to whether the drive closes the gate freely, and at the same time check whether the chamber seal has retained its geometry. -
Page 16: Gate Lock Function
Press and hold “P”, until “P1” displays. Press “▲”(three times), until “P4” displays. By pressing “P” again, you will see current settings. By pressing “▲” you add 1 minute, by pressing “▼” you subtract 1 minute. Maximum time is “b9”, minimum “b0”. Press “P”... -
Page 17: Ventilation Function
VENTILATION FUNCTION If there is a need for garage ventilation, then this function can be turned on. It consists in the fact that with the remote control button (other than the button for opening / closing the gate) the gate is opened to the programmed height n x 8cm (n=1÷6) . - Page 18 Connect the power supply of adequate power, the power cord must be equipped with an earthing system. Only use the remote control when the gate is in sight. Do not go under a working gate. Remote controls should be kept out of the reach of children. Make sure the door is protected against fire, moisture or strong electromagnetic fields.
- Page 19 3. Faulty photocells 3. Send the photocells to the service together with a description of the fault and the purchase document 4. Insufficient drive force 4. Set the correct drive force in accordance with the instructions and standards. When closing, the gate stops suddenly 1.
- Page 20 HATO TRADE SP. Z O.O. ul. Tunelowa 57 40-676 Katowice POLAND tel. 032-785-25-42 www.hato.pl Magazyn i sprzedaż; ul. Żeromskiego 1 41-205 Sosnowiec...
