VLX 1870S Quick Manual

1870S Walk Behind Scrubber Quick Guide
This Guide is intended for quick consultation only and does not replace the Use and Maintenance Operator Manual.
Read the Use and Maintenance Operator Manual completely and understand the machine before operating.
Operator video available online at VLXclean.com. For technical support, call 800-861-7352.
PREPARATION/OPERATION
1. Fill the solution tank.
2. Lower the machine head by pressing the
pedal down and to the left.
3. Lower the squeegee using the lever.
©Tennant Company. Specifications subject to change without notice.
1870S Wall Chart 10/18
4. Press the brush button to enable brush
rotation and turn the suction motor on.
5. Press the suction motor button to disable
suction if you want to prewash the floor.
6. Press the "H2O" button for at least 2
seconds to enable solution flow. Press the
button repeatedly to vary the quantity delivered.
7. Press and hold the drive lever.
8. Choose the direction of movement by
moving the direction selector, turn the
potentiometer to set the work speed.
9. Dry sweep before cleaning.
10. Begin cleaning.
When you have finished cleaning, proceed
as follows:
Turn the brush motor off.
Turn the suction motor off.
Raise the machine head.
Raise the squeegee.
If necessary, charge the batteries.
1
