Summary of Contents for Sakar Wrist Cam Watch
- Page 2 Please read this manual carefully first in order to get the most out of your Discovery Kids Wrist Cam Watch. Your Wrist Cam Watch can be used as a low-resolution digital camera and as a web cam (to chat over the Internet). This camera is equipped with a 16Mb built-in ROM, therefore you are able to use it to take up to 152 low-resolution photos (under QCIF mode and high compression).
-
Page 3: Table Of Contents
Table of Contents About Your Wrist Cam Watch...4 Computer System Requirements...5 Installing or Replacing the Batteries ...5 Getting Started...7 Wrist Watch Cam Modes...7 To Turn Off the Camera...8 To Set the Time...9 Using Your Camera...10 Taking Photos ...10 Deleting Photos ...12 Your Photo Options ...13... -
Page 4: About Your Wrist Cam Watch
About Your Wrist Cam Watch The following items are included with your Discovery Kids Wrist Cam Watch. • Digital Camera/Watch • USB Connector Cable • CD-ROM Software • User Manual... -
Page 5: Computer System Requirements
Computer System Requirements • Windows 2000/XP • Pentium-based PC (or equivalent) • 80 MB hard disk free space and 32 MB or more RAM • Available USB Interface • CD-ROM Drive • Color display (24 bit or higher recommended) Installing or Replacing the Batteries You will need a small Phillips head screwdriver—the type found in a jeweler’s or eyeglass kit. - Page 6 Insert 2 "AAA" batteries. Make sure the "+" and "-" ends are inserted correctly, as indicated in the battery compartment. Close each battery cover and tighten each screw. Replace the wrist band. Note: When the battery power is low you will hear a beeping sound when you press the shutter button.
-
Page 7: Getting Started
(HI/LO) for 3 seconds and then show the remaining number of photos you may take. Wrist Watch Cam Modes The CAMERA MODE select button lets you select the functions of the digital camera. Press the CAMERA MODE select button repeatedly to scroll though and select a particular mode. -
Page 8: To Turn Off The Camera
12:00 Clock mode Turn camera off Self timer Continuous shoot mode Delete All Delete last photo Hi - CIF mode (100k pixels resolution) Lo - QCIF mode (25K pixels resolution) 50/60 50Hz or 60Hz fluorescent lighting frequency High compression ratio (higher compression means you may store more photos) Low compression ratio Note: When scrolling through the CAMERA MODE, if you do not press any... -
Page 9: To Set The Time
To Set the Time The Wrist Cam Watch has a 12 hour time display. Press the MODE button to choose your setting. Press it the following number of times according to which display you want to set: a. Two times to enter the month b. -
Page 10: Using Your Camera
When taking pictures, aiming the lens as shown here will allow the lens to record your images right side up. When you wear the Watch Cam on your hand, pay attention to the LENS IMAGE direction when taking your photos. To achieve the best clarity, make sure that the distance between the camera and the subject is 5'. - Page 11 When the digital camera is at full capacity, the LCD display will show "0" photos left to take. You will hear the camera "beep" twice. You will not be able to take any more photos. Before you can take any more photos you will need to follow the instructions to download your photos or delete them.
-
Page 12: Deleting Photos
continuous shooting mode and do not release the Shutter Button until you want to stop shooting. The camera will beep once for each photo taken till the Shutter button released or the memory is full. Under the continuous shooting mode, the photos are taken in CIF & QCIF modes and saved as a video format. -
Page 13: Your Photo Options
Single Photo Press the Camera mode select button to select the " " icon shown on the LCD display. As you scroll through the icons this will be the second trash can that appears. You will recognize it because it has one handle on the lid. -
Page 14: Resolution
Resolution The resolution status will always show on the LCD display in small characters to the right of the time display. "HI" means CIF mode 352 x 288 Pixels, "LO" means QCIF mode 176 x 144 pixels. The HI mode will allow you to take 19 photos and the LO mode will allow you to take 76 photos. -
Page 15: Installing The Software
should set the fluorescent lamp frequency to that in your region. Selecting 60Hz Press the CAMERA MODE selection button to check the current frequency selection. If the LCD display shows 60 it means the present frequency is set for 50Hz. Press the Shutter button to change the frequency to 60 Hz. Selecting 50Hz If the LCD shows 50 it means the present is set for 60Hz. - Page 16 On the "Spy Shot Photo Manager" screen, click the "Next" button. Please review the license terms and click the "Agree" button to continue. Let the "Spy Shot Photo Manager" installer create the folder where the program will be installed, and then click "Install".
- Page 17 Click "Finish" to let the "Spy Shot Photo Manager" installer finish the installation program. This will automatically launch the Install shield for the camera driver. Click "Next" to continue.
- Page 18 Once the program has finished installing you will have to restart your computer. When you receive this message your have successfully installed the "Spy Shot Photo Manager" software, the "PhoTags WebCam Express" and the Camera driver.
-
Page 19: Downloading Photos
Downloading Photos Before downloading your pictures make sure you have installed the software from the CD. Download your photos as often as possible. Photos may be lost when the batteries run low. Use the "Spy Shot Photo Manager" program to import photos from your camera. - Page 20 Click on the "Get Photos" button on the Main Menu. The "Get photos from Spy Shot camera" window will appear. with the correct name of your camera device selected in the “Active devices” list in the “Express” mode. Click the “Next” button to proceed. NOTE: for Win XP users- the “JL 2005A Camera”...
- Page 21 The photos you have just imported will appear in the "Select Photos" mode’s main window.
-
Page 22: Recording Video Clips
Recording Video Clips You can use your Wrist Cam Watch to capture short movies called AVI files. The length of time you can record an AVI while the camera is connected to your computer will vary, depending on how much hard drive space you will use to save the file. -
Page 23: Using Your Camera As A Web Cam
Using Your Camera as a Web Cam You can use your Wrist Cam Watch as a webcam to chat with friends and family, sending live video feeds straight to them. In order to use this function you must make sure that you have YAHOO MESSENGER Ver 5.5 or later. - Page 24 Start Yahoo Messenger. Select the "tools" listing on the top of the toolbar. Go to the drop down menu and select the listing for "start my webcam". You will see a window appear with the video that you currently shooting. Now people who have your Yahoo login name will be able to se your video.
-
Page 25: Troubleshooting
Troubleshooting Question: I have taken photos, but my computer says "No photos in camera." What do I do? Answer: First, ensure that you have taken photos with your camera. Press the shutter button a few times to take some sample photos and try again. If you still get a no photos error, this indicates that the software was not installed correctly or you may not meet the minimum system requirements. - Page 26 hardware and then Device Manager. If the camera is installed correctly, there will be a category listed for "Imaging Devices" and clicking on the "+" next to it should reveal your camera. If not, you will likely see "Digital Still Camera" under "Other Devices"...
-
Page 27: Technical Specifications
Can’t find what you are looking for? Fill out an online ticket and one of our technical support team members will answer your questions. Or call 877-397-8200 to access our technical support information on the phone. For question on warranty information please email warranty@sakar.com. Technical Specifications Product Type: Digital Camera... -
Page 28: Warranty
A detailed written description of the problem. Your return address and daytime telephone number. A check or money order for USD $7.95 payable to Sakar International to cover shipping, handling and insurance. (Other fees may apply for shipments outside the US, please email, write or call for exact shipping charges.) - Page 29 FCC Notice This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modipcations to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 30 © 2006 Discovery Communications, Inc. All rights reserved. Windows and the Windows Logo are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective companies. Sakar International INC 195 Carter Drive Edison, NJ 08817 For technical support, please call 877-397-8200...
