- Page 1 Owner’s Manual Guitar Ampli er Owner’s Manual Bedienungsanleitung Mode d'emploi Manuale dell'utente Manual del usuario Manual do proprietário Gebruikershandleiding...
- Page 2 The manual should be saved and kept on hand as a convenient reference. All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION Roland is a registered trademark of Roland Corporation in the United States and/or other countries Owner’s Manual...
-
Page 3: Using The Unit Safely
WARNING Immediately turn the power off, remove the power cord from the outlet, and request servic- ing by your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page when: • The power-supply cord or the plug has been damaged;... -
Page 4: Important Notes
• The product names mentioned in this document are trademarks or registered trademarks of their respective owners, and are not related to Roland Corporation. In this manual, these names are used because it is the most practical way of describing the sounds that are simulated... -
Page 5: Control Panel Descriptions
For more detailed information, refer to”Using the Tuner Function” (p. 11) JC CLEAN Channel This is a model of Roland’s famous JC-120 Jazz Chorus guitar amplifi er. The ultra-clean, ultra-fl at sound off ers a smooth feel. This amp is ideal for creating sounds in combination with a multi-eff ects device. -
Page 6: Lead Channel
* The product names mentioned in this document are trademarks or registered trademarks of their respective owners, and are not related to Roland Corporation. In this manual, these names are used because it is the most practical way of describing the sounds that are simulated using COSM technology. - Page 7 EQUALIZER 11. [BASS] Knob This adjusts the sound level of the low-frequency range. 12. [MIDDLE] Knob This adjusts the sound level of the middle-frequency range. 13. [TREBLE] Knob This adjusts the sound level of the high-frequency range. * When the LEAD channel Type switch is set to BLACK PANEL, DLX COMBO (CUBE-80XL only), or TWEED, setting [BASS] knob, [MIDDLE] knob and [TREBLE] knob all to 0 (zero) stops all sound.
-
Page 8: Power Squeezer (Cube-40Xl Only)
[REVERB] 19. [REVERB] Knob You can switch between use of two types of reverb by changing the position of the knob. You can adjust the intensity of the eff ect by varying the knob position. The indicator lights up when reverb is on and goes out when the eff ect is off . - Page 9 Rear Panel CUBE-40XL Recorder, etc. Headphones RING TAP/STOP DELAY/REC/PLAY/DUB CUBE-80XL External Speaker RING RING TAP/STOP REVERB DELAY/REC/PLAY/DUB Foot switches * To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices before making any connections.
-
Page 10: Recording Out/Phones
FOOT SW By connecting a foot switch (BOSS FS-5U or FS-6; sold separately), you’ll be able to use your foot to switch between channels, turn EFX, Reverb, and Delay on/off , and control the Looper function. The connection diagram at left is a connection example that shows how to use a momentary-type foot switch (FS-5U, FS-6). - Page 11 Using a Latch-type Foot Switch The CUBE-40XL/CUBE-80XL also support latch-type foot switches. If you’re using a latch-type foot switch, make the following settings. FOOT SW TYPE setting There are two types of foot switches. Type Operation Momentary type This type remains on (or off ) while depressed (BOSS FS-5U, etc) and switches off (or on) when released.
-
Page 12: Using The Tuner Function
Using the Tuner Function CUBE-40XL and CUBE-80XL are equipped with a tuner function. In addition to manual tuning, you can also use it as a chromatic tuner. * Use manual tuning when the strings are substantially out of tune (such as after changing strings). CUBE-40XL CUBE-80XL Manual Tuning... -
Page 13: Using The Solo Function
Using the SOLO Function You can save and call up the panel settings (those enclosed by the line in the fi gure) for sounds you create. On this unit, this function is called “SOLO. ” This is a convenient way to switch between a backing sound and a solo sound. - Page 14 Switching the SOLO Function and the LEAD and JC CLEAN Channels You can use the [SELECT] switch and the SOLO [ON/OFF] switch to switch between the following four sounds • Current JC CLEAN panel settings • The SOLO sound you created and saved for JC CLEAN • Current LEAD panel settings • The SOLO sound you created and saved for LEAD Channel...
-
Page 15: Using The Looper
Using the LOOPER This function lets you record a phrase you perform, and then play it back repeatedly. You can also overdub additional phrases onto the recording. On the CUBE-40XL and CUBE-80XL, this is called the Looper function. You can also operate the LOOPER function using optional foot switches. - Page 16 Using the LOOPER Function and Delay at the Same Time By taking advantage of the SOLO function, you can use the Looper function and the delay at the same time. Normally, you cannot use the delay when the [DELAY/LOOPER] knob is in the LOOPER position.
-
Page 17: Sample Settings
This is a transparent sound that uses spatial eff ects. Use the JC CLEAN amp, which is modeled on the Roland JC-120, and add chorus, long delay, and reverb. Using this setting with a guitar that has single-coil pickups makes for arpeggios and chord strumming with beautiful resonance. If you’re using a guitar with humbucker pickups on CUBE-80XL, turn the [BRIGHT] switch to ON to achieve a bright, open sound. - Page 18 Rockabilly Slap CUBE-40XL Delay time = approx. 90 ms (reference) [SELECT] switch=LEAD This is the slapback-echo sound used in rockabilly and country. The BLACK PANEL amp produces a clean sound that is bright and sweet, with a powerful midrange and high end supported by a thick bass. By making the low and high ends more prominent while keeping them balanced, and also suppressing the midrange if the situation calls for it, you can bring out the dazzling resonance of the guitar even more beautifully.
- Page 19 CUBE-40XL Block Diagram AUX IN SELECT JC CLEAN LEAD SOLO ACOUSTIC SIM BLACK PANEL INPUT BRIT COMBO TWEED CLASSIC STACK FLANGER/ METAL PHASER/ R-FIER HEAVY EXTREME OCTAVE SELECT JC CLEAN TUNER SOLO LEAD SOLO CUBE-80XL Block Diagram AUX IN SELECT JC CLEAN LEAD SOLO...
-
Page 20: Specifications
Specifications CUBE-40XL/CUBE-80XL: Guitar Amplifier CUBE-40XL Rated Power 40 W Output INPUT: -10 dBu/ 1 MΩ Nominal Input Level (@ 1 kHz) AUX IN: -10 dBu Speaker 25 cm (10 inches) [POWER] switch [SELECT] switch [TUNER] switch [POWER SQUEEZER] switch <JC CLEAN CH> [VOLUME] knob <LEAD CH>... - Page 22 Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below. PHILIPPINES AFRICA G.A. Yupangco & Co. Inc. 339 Gil J. Puyat Avenue Makati, Metro Manila 1200, EGYPT PHILIPPINES...
- Page 23 For China For EU Countries...
-
Page 24: Federal Communications Commission Radio Frequency Interference Statement
This product complies with the requirements of EMCD 2004/108/EC and LVD 2006/95/EC. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 25 MEMO...
-
Page 26: Important Safety Instructions
WARNING: CAUTION CAUTION IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING IMPORTANT: WARNING: IMPORTANT: For the U.K. For the U.K.
