Roland DP-990R Specifications

Roland — the world's leading developer of digital pianos.
Roland has proudly led the development of digital pianos for over 30 years,
steadfastly pursuing the best in sound, touch, and myriad elements that provide a
truly "grand" piano experience. Roland's development philosophy, superior
technical expertise, and commitment to quality have secured the unwavering
confidence of both professional and amateur music lovers around the world.
Technology
History
Roland propelled the electronic piano market when it With a passion for sound and music, as well as unrivalled
launched the EP-30 in 1974. This historic instrument strength in R&D, Roland has developed many "world's first"
was the first electronic piano in the world with a technologies that have become global standards. The
touch-sensing function built central R&D base for the Roland Group is the Hamamatsu
into the keyboard. Musicians Laboratory complex, a state-of-
the-art facility that represents the
have come to rely on and
love Roland digital pianos for cutting edge of Roland's innovation.
their superior sound, touch, Here the core technologies for the
expression, and reliability. next generation are conceived,
created, and refined.
EP-30
Specifications
<Keyboard>
Keyboard 88 keys (PHA II with Escapement)
Touch Sensitivity Touch: 5 levels/Fixed Touch, Hammer Response: Off/1–10
Keyboard Mode Whole, Dual (volume balance adjustable), Split (split point adjustable), Twin piano
<Sound Generator>
Max. Polyphony 128 voices
Tones 306 tones (including 8 drum sets, SFX set)
GM2/GS/XG Lite
Temperament 8 types, selectable tonic
Stretched Tuning On/Off
Master Tuning
415.3–466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose Key Transpose: -6–+5 (in semitones)
Playback Transpose (with Audio CD/Audio File): -6–+5 (in semitones)
Effects
3D (4 Levels), Dynamics (3 types), Reverb (Off/1–10),
Key Off Resonance (only for piano tones, Off/1–10), String Resonance (only for piano tones,
Off/1–10), Damper Resonance (only for piano tones, Off/1–10)
<Recorder>
Tracks 3 tracks
Songs
Recorder Section: 1 song, Internal Memory: Max. 99 songs
Note Storage Approx. 30,000 notes
Control
Song Select, Play/Stop, Rec, Previous/Rewinding, Next/Fast-forwarding,
Track Mute (Mute Level adjustable), Tempo, Tempo Mute, All Song Play,
Count-in, Count-down, Song Volume, Center Cancel (only for audio playback)
Tempo Quarter note = 10 to 500
Resolution
120 ticks per quarter note
Metronome
Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8 , Volume: 0–10
Metronome Sound: 8 types
<Internal Memory> <Internal Memory>
Songs Max. 99 songs
Save Song Standard MIDI Files (Format 0)
*1 A list of the CD drives that have been tested and found to be compatible is available on the Roland website.
http://www.Roland.com/
Medium Cherry
DP-990-MC
Visit us online at www.Roland.com
Quality
The Miyakoda Factory in Hamamatsu, Japan, features Roland's
original cell-system manufacturing, a "one-person, one-instrument"
process where a highly skilled technician carefully and proudly
assembles each instrument from start to finish. The state-of-the-art
facility meets international standards* for
environmental management (ISO14001)
and quality assurance (ISO9001).
*Issued by the International Organization for
Standardization (ISO), ISO14001 and ISO9001 are
global standards for environmental management
"Cell" Production System
Hamamatsu R&D Center and quality in manufacturing. in Miyakoda Factory
<External Memory>
External Storage
USB Memory, Floppy Disk (when using an optional floppy disk drive)
Playable Software
Standard MIDI Files (Format 0/1), Roland Original Format (i-Format),
Audio File (WAV 44.1kHz / 16-bit Linear Format),
Audio CDs (CD-DA) (when using a commercially available CD drive*1)
<Other>
Internal Songs 65 songs + 7 Tone Demo Songs
Rated Power Output 12 W x 2
Speakers 12 cm x 2
Display
7 segments, 3 characters LED, Beat LED
Control Volume, Brilliance ( -10–10)
Pedal Damper (half-pedal recognition), Soft (half-pedal recognition, function assignable),
Sostenuto (function assignable)
Other Function Panel Lock, V-LINK
Connectors DC inlet, Pedal connector, Input jacks (L/Mono, R), Output jacks (L/Mono, R),
MIDI connectors (IN, OUT), Phones jack (Stereo) x 2, External Memory port (USB)
Power Supply DC 12 V
Power Consumption 48 W
Dimensions 1,398 (W) x 344 (D) x 781 (H) mm / 55-1/16 (W) x 13-9/16 (D) x 30-3/4 (H) inches (With lid closed)
1,398 (W) x 339 (D) x 974 (H) mm / 55-1/16 (W) x 13-3/8 (D) x 38-3/8 (H) inches (With lid open)
Weight 47 kg / 103 lbs 10 oz
Accessories Owner's manual, AC Adaptor, Power Cord (for connecting AC Adaptor), Headphones Hook
Options
USB Flash Memory Floppy Disk Drive Holder
(for External CD drive)
M-UF1G FD-01A DH-01
*The CD Drive not
included.
Compatible CD drive
information can be
found at
www.Roland.com.
All specifications and appearances are subject to change without notice.
All trademarks used in this catalog are the property of their respective companies.
iPod is a registered trademark of Apple, Inc.
Printed in Japan Dec. '07 RAM-4299 C-4 GR-UPR-P
DP-990
