Page 1 • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the CASIO Website at http://world.casio.com/. K867PCM1DKX...
Page 2: Introduction
INTRODUCTION INTRODUCTION Unpacking Check to make sure that all of the items shown below are included with your camera. If something is missing, contact your dealer as soon as possible. Camera * The shape of the AC power cord plug varies according to country or geographic area.
Page 3: Table Of Contents
INTRODUCTION Contents INTRODUCTION Unpacking ... 2 Features ... 9 Precautions ... 12 General Precautions Data Error Precautions Operating conditions Condensation Lens Other QUICK START GUIDE First, charge the batteries! ... 22 To configure display language and clock settings ... 23 To record an image ...
Page 4 INTRODUCTION BASIC IMAGE RECORDING Recording an Image ... 53 Specifying the Recording Mode Aiming the Camera Recording an Image Recording Precautions About Auto Focus About the REC Mode Monitor Screen Using the Optical Viewfinder ... 59 Using Zoom ... 60 Optical Zoom Digital Zoom Using the Flash ...
Page 5 INTRODUCTION Specifying Power On Default Settings Resetting the Camera PLAYBACK Basic Playback Operation ... 110 Zooming the Display Image ... 111 Resizing an Image ... 112 Cropping an Image ... 113 Playing a Movie ... 115 Displaying the 9-image View ... 116 Selecting a Specific Image in the 9-image View Displaying the Calendar Screen ...
Page 6 INTRODUCTION Using World Time ... 140 To display the World Time screen To configure World Time settings To configure summer time (DST) settings Changing the Display Language ... 142 Changing the USB Port Protocol ... 143 Configuring [ ] (REC) and [ ] (PLAY) Power On/Off Functions ...
Page 7 INTRODUCTION USING THE CAMERA WITH A COMPUTER Using the Album Feature ... 177 Creating an album Selecting an Album Layout Configuring Detailed Album Settings Viewing Album Files Saving an Album To delete an album Installing the Software from the CD-ROM ... 185 About the bundled CD-ROM Computer System Requirements Installing Software from the CD-ROM in Windows .
Page 8 • CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or claims by third parties which may arise through the use of the QV-R61. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or losses suffered by you or any third party due to the use of Photo Loader and/or Photohands.
Page 9: Features
INTRODUCTION I Copyright Restrictions Except for the purpose of your own personal enjoyment, unauthorized copying of snapshot files and movie files violates copyright laws and international contracts. Distribution to third parties of such files over the Internet without permission of the copyright holder, whether for profit or for free, violates copyright laws and international contracts.
Page 10 INTRODUCTION • Business Shot (page 93) Business Shot automatically corrects rectangular shapes when recording the image of a business card, document, whiteboard, or similar subjects from an angle. • Coupling Shot and Pre-shot (pages 89, 91) Coupling Shot lets you combine two subjects into a single image, while Pre-shot lets you add a subject to a previously recorded background image.
Page 11 INTRODUCTION • DCF Data Storage (page 174) DCF (Design rule for Camera File system) data storage protocol provides image compatibility between the digital camera and printers. • Digital Print Order Format (DPOF) (page 153) Images can be printed easily in the sequence you want using a DPOF compatible printer.
Page 12: Precautions
INTRODUCTION Precautions General Precautions Be sure to observe the following important precautions whenever using the QV-R61. All references in this manual to “camera” refer to the CASIO QV-R61 Digital Camera. I Test for proper operation before using the camera! • Before using the camera to record important images,...
Page 13 2. If you are using the AC adaptor to power the camera, unplug it from the wall outlet. If you are using battery power, remove the batteries from the camera, taking care to protect yourself against burn injury. 3. Contact your dealer or nearest CASIO authorized service center.
Page 14 If you are using battery power, remove the batteries from the camera. 3. Contact your dealer or nearest CASIO authorized service center. I Dropping and Rough Treatment • Continued use of the camera after it is damaged by dropping or other rough treatment creates the risk of fire and electric shock.
Page 15 INTRODUCTION I Locations To Be Avoided • Never leave the camera in any of the following types of locations. Doing so creates the risk of fire and electric shock. — Areas subject to large amounts of humidity or dust — Food preparation areas or other locations where oil smoke is present —...
Page 16: Alkaline Batteries
• The term “battery” in this manual refers to the rechargeable nickel-metal hydride batteries. • The term “charger unit” in the following precautions refers to the CASIO BC-5H Charger Unit. • Failure to observe any of the following precautions while using batteries creates the risk of overheating, fire, and explosion.
Page 17: Charger Unit
INTRODUCTION • If the batteries do not achieve full charge after the normal charging time has passed, stop charging. Continued charging creates the risk of overheating, fire, and explosion. • Battery fluid can damage your eyes. Should battery fluid get into your eyes accidentally, immediately rinse them with clean tap water and then consult a physician.
Page 18 — Do not twist or pull on the power cord. — Should the power cord or plug ever become damaged, contact your dealer or nearest CASIO authorized service center. • Use the AC adaptor where it will not be splashed with water.
Page 19: Data Error Precautions
Data Error Precautions • Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in file memory. — Removing the batteries or memory card from the...
Page 20: Operating Conditions
INTRODUCTION Operating conditions • This camera is designed for use in temperatures ranging from 0°C to 40°C (32°F to 104°F). • Do not use or keep the camera in the following areas. — In areas subject to direct sunlight — In areas subject to high humidity or dust —...
Page 21: Lens
INTRODUCTION Lens • Never apply too much force when cleaning the surface of the lens. Doing so can scratch the lens surface and cause malfunction. • Fingerprints, dust, or any other soiling of the lens can interfere with proper image recording. Never touch the lens with your fingers.
Page 22: Quick Start Guide
QUICK START GUIDE QUICK START GUIDE First, charge the batteries! Charge the rechargeable nickel-metal hydride batteries (HR-3U) that come with the camera (page 34). • It takes about four hours to achieve a full charge. Load the batteries into the camera. (page 39).
Page 23: To Configure Display Language And Clock Settings
QUICK START GUIDE To configure display language and clock settings • Be sure to configure the following settings before using the camera to record images. (See page 50 for details.) 2, 3, 4, 5, 6, 7, 8, 9 Press the power button to turn on the camera.
Page 24: To Record An Image
QUICK START GUIDE To record an image (See page 53 for details.) Green operation lamp Snapshot mode icon Focus frame Press [ ] (REC). Press [MENU]. Use [ ] and [ ] to select the “REC” tab. Use [ ] and [ ] to select “REC Mode”, and then press [ ].
Page 25: To View A Recorded Image
QUICK START GUIDE To view a recorded image (See page 110 for details.) Press [ ] (PLAY). Use [ ] and [ ] to scroll through the images. To delete an image 2, 3, 4, 5 Press [ ] (PLAY). Press [ ] ( Use [ ] and [ ] to display the image you want to delete.
Page 26: Contents
The following table defines the terminology used in this manual. This term as used in this Means this: manual: “camera” The CASIO QV-R61 Digital Camera “file memory” The location where the camera is currently storing images you record (page 55) “batteries”...
Page 27: General Guide
GETTING READY General Guide The following illustrations show the names of each component, button, and switch on the camera. I Front Shutter button Power button Flash Viewfinder Terminal cover Self-timer lamp Lens [USB] port I Back 9 : A Viewfinder Operation lamp ] (PLAY mode) ] (REC mode)
Page 28 GETTING READY I Bottom Battery compartment cover Tripod screw hole • Use this hole when attaching to a tripod. Memory card slot Battery compartment...
Page 29: Monitor Screen Contents
GETTING READY Monitor Screen Contents The monitor screen uses various indicators and icons to keep you informed of the camera’s status. • Note that the example screens in this chapter are for illustrative purposes only. They do not exactly match the screen contents actually produced on the camera.
Page 30 GETTING READY Image size (page 70) Date and time (page 137) 2816 × 2112 pixels EV value (page 79) 2816 × 1872 (3:2)pixels 2048 × 1536 pixels Battery capacity (page 40) 1600 × 1200 pixels 1280 × 960 pixels Histogram (page 97) 640 ×...
Page 31: Play Mode
GETTING READY PLAY mode 12 3 PLAY mode file type Snapshot Movie Image protection indicator (page 127) Folder number/File number (page 126) Example : When a file named CIMG0023.JPG is stored in a folder named 100CASIO 100-0023 Folder name File name Image size (page 70) 2816 ×...
Page 32: Changing The Contents Of The Monitor Screen
GETTING READY Changing the Contents of the Monitor Screen Each press of [DISP] changes the contents of the monitor screen as shown below. I REC mode Indicators on (page 29) Histogram on (page 29) Indicators off Monitor screen off I PLAY mode Indicators on (page 31) Histogram/Details on (page 97) Indicators off...
Page 33: Indicator Lamps
GETTING READY Indicator Lamps You can find out the operational status of the camera at a glance by checking the color of the indicator lamps, and whether a lamp is lit or flashing. For details, see “Indicator Lamp Reference” on page 196. Self-timer lamp Red operation lamp Attaching the Strap...
Page 34: Power Requirements
GETTING READY Power Requirements Your camera features a two-way power supply that lets you use either AA-size batteries or household AC current. A set of AA-size rechargeable nickel-metal hydride batteries is supplied with the camera. The other items listed below are available separately.
Page 35 GETTING READY I To charge the batteries Positioning the positive and negative terminals of each battery as shown in the illustration, attach the batteries to the charger unit. Plug the charger unit into a household power outlet. • This will cause the [CHARGE] lamp to light. •...
Page 36 GETTING READY The [CHARGE] lamp will go out when charging is complete. After charging is complete, unplug the charger unit from the power outlet, and remove the batteries from it. • Always unplug the charger unit from the power outlet and remove the batteries whenever you are not using it for charging.
Page 37 GETTING READY • Though the actual service life of the batteries depends on the environment under which they are used, you can expect to be able to recharge them about 500 times before they need replacement. • Charging the batteries may cause interference with TV and radio reception.
Page 38: Battery Precautions
GETTING READY I Battery Precautions Precautions During Use • Charge the batteries in a location where the temperature is in the range of 10°C to 35°C (50°F to 95°F). Charging outside this temperature range can cause charging to take longer than normal or even cause charging to fail.
Page 39: To Load Batteries
GETTING READY To load batteries Turn off the camera. Slide the battery compartment cover on the bottom of the camera in the direction indicated by the arrow and then swing it open. Load batteries as shown in the illustration. While pressing down at the point indicated by the arrow in the illustration, slide the...
Page 40: Low Battery Indicator
GETTING READY I Low Battery Indicator The following shows how the battery capacity indicator on the monitor screen changes as battery power is used. The indicator means that remaining battery power is low. Note that you will not be able to record images while the battery indicator is .
Page 41 GETTING READY *1 Number of Shots (CIPA Standard) • Temperature: 23°C (73°F) • Monitor Screen: On • Zoom operation between full wide to full telephoto every 30 seconds, during which two images are recorded, one image with flash; power turned off and back on every time 10 images are recorded.
Page 42: Battery Handling Precautions
GETTING READY I Alkaline Battery Life The actual life of alkaline batteries is affected by a variety of factors, including the battery manufacturer, the amount of time the batteries spend in storage before you use them, temperature while you are recording, and photographic conditions.
Page 43: Using Ac Power
GETTING READY Using AC Power You need to purchase the optionally available AC adaptor (AD-C30) in order to be able to power the camera using AC power. Connect the AC power cord to the AC adaptor. Open the camera’s terminal cover and connect the AC adaptor to the port marked [DC IN 3V].
Page 44 GETTING READY I Using AC Adaptor In Another Geographic Area • The AC adaptor can be used with any power source rated from 100V to 240V AC. If you plan to use the AC adaptor in another country, it is up to you to purchase the applicable AC power cord that matches the configuration of power receptacles in that country.
Page 45: Turning The Camera On And Off
GETTING READY Turning the Camera On and Off I To turn on the camera Press the power button, [ ] (REC), or [ will cause the green operation lamp to light momentarily, and then power will turn on. The mode the camera enters depends on which button you pressed to turn it on.
Page 46: Configuring Power Saving Settings
GETTING READY I To turn off the camera Press the power button to turn off the camera. NOTE • You can setup the camera so it does not turn on when you press [ ] (REC) or [ turn off when you press [ ] (REC) or [ For details, see “Configuring [ (PLAY) Power On/Off Functions”...
Page 47: Using The On-Screen Menus
GETTING READY G See “Using the On-screen Menus” below for information about how to use menus. To configure this feature: Select this setting: Sleep Sleep Auto Power Off Auto Power Off Use [ ] and [ ] to change the currently selected setting, and then press [SET].
Page 48 GETTING READY Press [MENU]. Selection cursor (indicates the currently selected item) [MENU] [SET] [ ][ ][ ][ ] Settings G Menu Screen Operations When you want to do this: Do this: Move between tabs Press [ ] and [ ]. Move from the tab to the Press [ ].
Page 49 GETTING READY Press [ ] or [ ] to select the tab you want, and then press [SET] to move the selection cursor from the tab to the settings. Use [ ] and [ ] to select the feature whose setting you want to configure, and then press [ ].
Page 50: Configuring Display Language And Clock Settings
GETTING READY Configuring Display Language and Clock Settings Be sure to configure the following settings before using the camera to record images. • Display language • Home city • Date style • Date and time Note that the current date and time settings are used by the camera to generate the date and time that are stored along with image data, etc.
Page 51: Configuring Display Language And Clock Settings
GETTING READY To configure display language and clock settings Press the power button, [ (PLAY) to turn on the camera. Use [ ], [ ], [ ], and [ ] to select the language you want, and then press [SET]. : Japanese English : English...
Page 52 GETTING READY Use [ ] and [ ] to select the date format setting you want, and then press [SET]. Example: December 24, 2004 To display the date like this: Select this format: 04/12/24 YY/MM/DD 24/12/04 DD/MM/YY 12/24/04 MM/DD/YY Set the current date and the time.
Page 53: Basic Image Recording
This section describes the basic procedure for recording an image. Recording an Image Specifying the Recording Mode Your CASIO digital camera has three recording modes, each of which is described below. Before recording an image, use the procedure below to select the applicable recording mode.
Page 54: Aiming The Camera
BASIC IMAGE RECORDING Aiming the Camera Use both hands to hold the camera still when shooting an image. Holding the camera with one hand increases the chance of movement, which can blur your images. • Horizontal • Vertical IMPORTANT! • Make sure your fingers and the strap do not block the flash or lens.
Page 55: Recording An Image
BASIC IMAGE RECORDING Recording an Image Your camera automatically adjusts shutter speed in accordance with the brightness of the subject. Images you record are stored in the camera’s built-in memory, or to a memory card if you have one loaded in the camera. •...
Page 56 BASIC IMAGE RECORDING Compose the image on the monitor screen so the main subject is within the focus frame. • The focusing range of the camera depends on focus mode you are using (page 72). • You can compose images using either the monitor screen or the optical viewfinder (page 59).
Page 57: Recording Precautions
BASIC IMAGE RECORDING After making sure that the image is focused properly, press the shutter button the rest of the way down to record. • The number of images that can be stored in memory depends on the resolution setting you are using (pages 70, 71, 206).
Page 58: About Auto Focus
BASIC IMAGE RECORDING • When recording a dimly lit subject while “Auto” is selected for the ISO sensitivity setting (page 100), the camera increases sensitivity and uses a slower shutter speed. Because of this, you need to guard against camera movement if you have flash turned off (page 63).
Page 59: About The Rec Mode Monitor Screen
BASIC IMAGE RECORDING About the REC Mode Monitor Screen • The image shown on the monitor screen in the REC mode is a simplified image for composing purposes. The actual image is recorded in accordance with the image quality setting currently selected on your camera. The image saved in file memory has much better resolution and detail than the REC mode monitor screen image.
Page 60: Using Zoom
BASIC IMAGE RECORDING • The monitor screen turns on automatically whenever you select the Macro mode or Manual Focus mode. Always use the monitor screen to compose images in these modes. Using Zoom Your camera is equipped with two types of zoom: optical zoom and digital zoom.
Page 61 BASIC IMAGE RECORDING Zoom out Record the image. NOTE • The optical zoom factor also affects the lens aperture. • Use of a tripod is recommended to protect against hand movement when using the telephoto setting (zoom in). • Optical zoom is disabled during movie recording, but Zoom in digital zoom is enabled.
Page 62: Digital Zoom
BASIC IMAGE RECORDING Digital Zoom Digital zoom is activated after you reach the maximum optical zoom factor (3X). It enlarges the part of the image at the center of the image screen. The range of the digital zoom factor is shown below. Digital Zoom Factor Range: 3X to 12X (in combination with optical zoom)
Page 63: Using The Flash
BASIC IMAGE RECORDING IMPORTANT! • Digital zoom is disabled whenever the monitor screen is turned off (page 32). • When you perform a digital zoom operation, the camera manipulates the image data to enlarge the center of the image. Unlike optical zoom, an image enlarged with digital zoom appears coarser than the original.
Page 64 BASIC IMAGE RECORDING To do this: Have the flash fire automatically when required (Auto Flash) Turn off the flash (Flash Off) Always fire the flash (Flash On) Fire a pre-flash followed by image recording with flash, reducing the chance of red-eye in the image (Red- eye reduction) In this case, the flash fires automatically when required...
Page 65: Flash Unit Status
BASIC IMAGE RECORDING Flash Unit Status You can find out the current flash unit status by pressing the shutter button half way and checking the monitor screen and red operation lamp. indicator is also Red operation lamp * shown on the monitor screen when the flash unit is ready to fire.
Page 66: Using Flash Assist
BASIC IMAGE RECORDING Using Flash Assist Recording a subject that is outside the flash range can cause the subject to appear dark in the resulting image, because not enough of the flash reaches the subject. When this happens, you can use flash assist to correct the brightness of the recorded subject, so it appears as if the flash illumination was sufficient.
Page 67: Flash Precautions
BASIC IMAGE RECORDING Flash Flash Precautions • Take care that your fingers do not block the flash when you hold the camera. Covering the flash with your finger can greatly reduce its effectiveness. • You may not be able to achieve the desired results using a flash if the subject is too close or too far away.
Page 68: Using The Self-Timer
BASIC IMAGE RECORDING Using the Self-timer The self-timer lets you select either a 2-second or 10- second delay of the shutter release after you press the shutter button. A Triple Self-timer feature lets you perform three consecutive self-timer operations to record three images.
Page 69 BASIC IMAGE RECORDING Self-timer lamp Record the image. • When you press the shutter button, the self- timer lamp flashes as the countdown progresses, and then the shutter releases after the self-timer reaches the end of its countdown. • You can interrupt an ongoing self-timer countdown by pressing the shutter button while the self-timer lamp is flashing.
Page 70: Specifying Image Size
BASIC IMAGE RECORDING Specifying Image Size “Image size” is the size of the image, expressed as the number of vertical and horizontal pixels. A “pixel” is one of the many tiny dots that make up the image. More pixels provide finer detail when an image is printed, but a higher pixel count also causes the image’s file size of to be larger.
Page 71: Specifying Image Quality
BASIC IMAGE RECORDING Specifying Image Quality Compressing an image before storage can cause a deterioration of its quality. The more an image is compressed, the greater the loss of quality. The image quality setting specifies the compression ratio to be used when an image is stored in memory.
Page 72: Other Recording Functions
OTHER RECORDING FUNCTIONS OTHER RECORDING FUNCTIONS This section describes other powerful features and functions that are available for recording. Selecting the Focus Mode You can select one of four different focus modes: Auto Focus, Macro, Infinity, and Manual. In the REC mode, press [ ] •...
Page 73: Using Auto Focus
OTHER RECORDING FUNCTIONS Using Auto Focus As its name suggests, Auto Focus focuses the image automatically. The automatic focus operation starts when you press the shutter button down half way. The following is the Auto Focus range. Range: Approximately 60cm to ∞ (23.6˝ to ∞) Keep pressing [ ] ( ) until there is no focus mode indicator on the display.
Page 74: Specifying The Auto Focus Area
OTHER RECORDING FUNCTIONS I Specifying the Auto Focus Area You can use the following procedure to change the Auto Focus area used in the Auto Focus mode and the Macro mode. Note that the configuration of the focus frame changes in accordance with the Auto Focus area you select.
Page 75: Using The Macro Mode
OTHER RECORDING FUNCTIONS Using the Macro Mode The Macro mode lets you focus on close up subjects automatically. The automatic focus operation starts when you press the shutter button down half way. The following are the approximate focus ranges in the Macro mode. Ranges: 10cm to 70cm (3.9˝...
Page 76: Using The Infinity Mode
OTHER RECORDING FUNCTIONS Using the Infinity Mode Use this mode when recording scenery and other faraway images. Keep pressing [ ] ( ) until the focus mode indicator shows “ ”. Record the image. Using Manual Focus With the Manual Focus mode, you can adjust the focus of an image manually.
Page 77 OTHER RECORDING FUNCTIONS While watching the image on the monitor screen, use [ ] and [ ] to focus. Manual focus position To do this: Do this: Focus in on the subject Press [ ]. Focus out on the subject Press [ ].
Page 78: Using Focus Lock
OTHER RECORDING FUNCTIONS Using Focus Lock Focus lock is a technique you can use to focus on a subject that is not located within the focus frame when you record an image. You can use focus lock in the Auto Focus mode and the Macro mode ( Main subject Using the monitor...
Page 79: Exposure Compensation (Ev Shift)
OTHER RECORDING FUNCTIONS Exposure Compensation (EV Shift) Exposure compensation lets you change the exposure setting (EV value) manually to adjust for the lighting of your subject. This feature helps to achieve better results when recording a backlit subject, a strongly lit subject indoors, or a subject that is against a dark background.
Page 80: Adjusting White Balance
OTHER RECORDING FUNCTIONS • To cancel EV Shift, adjust the value until it becomes 0.0. Record the image. IMPORTANT! • When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation.
Page 81 OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the setting you want, and then press [SET]. When shooting under these conditions: Normal conditions Outdoor daylight on a clear day Outdoor daylight on an overcast or rainy day, in the shade of a tree, etc. In the shade of a building or any other area where the color temperature is high...
Page 82: Configuring The White Balance Setting Manually
OTHER RECORDING FUNCTIONS Configuring the White Balance Setting Manually Certain complex light sources or other environmental conditions can make it impossible to obtain good results when “Auto” or one of the fixed light source settings is selected for white balance. Manual white balance lets you configure the camera for a particular light source and other conditions.
Page 83: Using The High-Speed Continuous Shutter Mode
OTHER RECORDING FUNCTIONS NOTE • After you adjust white balance manually, the setting remains in effect until you change it or until you turn off the camera. Using the High-speed Continuous Shutter Mode You can configure the camera to record only a single snapshot each time the shutter button is pressed, or to keep recording as long as the shutter button remains depressed.
Page 84: Using The Bestshot Mode
OTHER RECORDING FUNCTIONS IMPORTANT! • Nothing is displayed on the monitor screen while recording is in progress. • Recording pauses and the message “Busy... Please wait...” appears on the monitor screen after three images are recorded. • The flash is disabled while the high-speed continuous shutter mode is turned on.
Page 85 OTHER RECORDING FUNCTIONS Scene Number Scene Name Retro Twilight Business card and documents (page 93) White board, etc. (page 93) Register User Scene (page 87) . Enter the REC Mode, and select “ BESTSHOT” as the recording mode (page 53). •...
Page 86 OTHER RECORDING FUNCTIONS IMPORTANT! • BESTSHOT scenes were not recorded using this camera. They are provided as samples only. • Images recorded using a BESTSHOT scene may not produce the results you expected due to shooting conditions and other factors. •...
Page 87: Creating Your Own Bestshot Setup
OTHER RECORDING FUNCTIONS Creating Your Own BESTSHOT Setup You can use the procedure below to save the setup of an image you recorded for later recall when you need it again. Recalling a setup you save automatically sets up the camera accordingly.
Page 88: To Delete A Bestshot User Setup
OTHER RECORDING FUNCTIONS IMPORTANT! • Setups that you register as BESTSHOT sample scenes are located after the built-in sample scenes. • Note that formatting the built-in memory (page 145) deletes all BESTSHOT user setups. NOTE • The following are the settings that are included in a BESTSHOT user setup: focus mode, EV shift value, filter, metering mode, white balance mode, flash intensity, flash assist, sharpness, saturation,...
Page 89: Combining Shots Of Two People Into A Single Image (Coupling Shot)
OTHER RECORDING FUNCTIONS Combining Shots of Two People into a Single Image (Coupling Shot) The Coupling Shot mode lets you record images of two people and combine them into a single image. This makes it possible for you to include yourself in group images, even when there is no one else around to record the image for you.
Page 90 OTHER RECORDING FUNCTIONS Press the shutter button to record the left side of the image. • The focus, exposure, white balance, zoom, and flash settings are fixed for this type of image. Next, align the focus frame with the subject you want in the right side of the image, taking care to align the actual...
Page 91: Recording A Subject Onto An Existing Background Image (Pre-Shot)
OTHER RECORDING FUNCTIONS Recording a Subject onto an Existing Background Image (Pre-shot) Pre-shot helps you get the background you want, even if you need to ask someone else to record the image for you. Basically, Pre-shot is a two-step process. 1.
Page 92 OTHER RECORDING FUNCTIONS Enter the REC Mode, and select “ BESTSHOT” as the recording mode (page 53). Use [ ] and [ ] to select “Pre-shot”, and then press [SET]. Compose the background you want on the monitor screen, and then press the shutter button to temporarily record it as a reference image.
Page 93: Recording Images Of Business Cards And Documents (Business Shot)
OTHER RECORDING FUNCTIONS Recording Images of Business Cards and Documents (Business Shot) Recording a business card, document, white board, or similarly shaped object from an angle can cause the subject to appear misshaped in the resulting image. Business Shot automatically corrects the shape of rectangular objects to make them appear like the camera was positioned directly in front of them.
Page 94: To Use Business Shot
OTHER RECORDING FUNCTIONS IMPORTANT! • Before recording, compose the image so outline of the item you want to record fits entirely within the monitor screen. The camera will not be able to detect the shape of the subject correctly unless it is enclosed entirely within the monitor screen.
Page 95: Using The Movie Mode
OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the candidate you want to correct. Use [ ] and [ ] to select “Correct”, and then press [SET]. • Selecting “Cancel” in place of “Correct” stores the original image as-is, without correcting it.
Page 96 OTHER RECORDING FUNCTIONS Remaining recording time Enter the REC Mode, and select “ Movie” as the recording mode (page 53). • This enters the Movie Mode and causes “ ” to appear on the monitor screen. • You can use the key customization feature (page 106) to configure the camera to enter the Movie Mode whenever you press [ ] or [ ] while in the REC mode.
Page 97: Using The Histogram
OTHER RECORDING FUNCTIONS Using the Histogram You can use [DISP] to display a histogram on the monitor screen. The histogram lets you check exposure conditions as you record images (page 32). You can also display the histogram of a recorded image in the PLAY mode. Histogram •...
Page 98 OTHER RECORDING FUNCTIONS • When the histogram is too far to the left, it means that there are too many dark pixels. This type of histogram results when the overall image is dark. A histogram that is too far to the left may result in “black out”...
Page 99: Rec Mode Camera Settings
OTHER RECORDING FUNCTIONS IMPORTANT! • Note that the above histograms are shown for illustrative purposes only. You may not be able to achieve exactly the same shapes for particular subjects. • A centered histogram does not necessarily guarantee optimum exposure. The recorded image may be over-exposed or under-exposed, even though its histogram is centered.
Page 100: Specifying Iso Sensitivity
OTHER RECORDING FUNCTIONS Specifying ISO Sensitivity You can change the ISO sensitivity setting for better images in places where lighting is dim or when you are using faster shutter speeds. • ISO sensitivity is expressed in terms of values that originally indicated the sensitivity to light for photographic film.
Page 101: Selecting The Metering Mode
OTHER RECORDING FUNCTIONS Selecting the Metering Mode Use the following procedure to specify multi-pattern metering, spot metering, or center-weighted metering as the metering mode. In the REC mode, press [MENU]. Select the “REC” tab, select “Metering”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 102: Using The Filter Function
OTHER RECORDING FUNCTIONS IMPORTANT! • When “Multi” is selected as the metering mode, certain procedures cause the metering mode setting to change automatically as described below. • Changing the exposure compensation setting (page 79) to a value other than 0.0 changes the metering mode setting to “Center Weighted.”...
Page 103: Specifying Outline Sharpness
OTHER RECORDING FUNCTIONS Specifying Outline Sharpness Use the following procedure to control the sharpness of image outlines. In the REC mode, press [MENU]. Select the “REC” tab, select “Sharpness”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 104: Specifying Contrast
OTHER RECORDING FUNCTIONS Specifying Contrast Use this procedure to adjust the relative difference between the light areas and dark areas of the image you are recording. In the REC mode, press [MENU]. Select the “REC” tab, select “Contrast”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 105: Turning Image Review On And Off
OTHER RECORDING FUNCTIONS Turning Image Review On and Off Image review displays the images you record on the monitor screen as soon as you record them. Use the following procedure to turn image review on and off. In the REC mode, press [MENU]. Select the “REC”...
Page 106: Assigning Functions To The [ ] And [ ] Keys
OTHER RECORDING FUNCTIONS IMPORTANT! • Selecting one of the following settings causes the icon and its Icon Help text to appear momentarily on the monitor screen. The icon and text disappear after a short while. — Flash mode (Auto) icon (page 63) —...
Page 107: Specifying Power On Default Settings
OTHER RECORDING FUNCTIONS When you want to assign this function to [ ] and [ ] keys: Recording mode • [ ] and [ ] cycle through recording modes: Snapshot, BESTSHOT, Movie (page 53). EV shift • [ ] decreases compensation, [ ] increases compensation (page 79).
Page 108 OTHER RECORDING FUNCTIONS Function REC Mode Flash Focus White Balance Setting when AF Area camera is Metering turned off Self-timer Flash Intensity Digital Zoom Last Auto Focus position that was in MF Position effect before you switched to manual focus Zoom Position* * Only the optical zoom position is remembered.
Page 109: Resetting The Camera
OTHER RECORDING FUNCTIONS IMPORTANT! • If you change the BESTSHOT mode sample scene selection or if you turn off the camera while it is in the BESTSHOT mode, the camera’s setup (except for “REC mode” and “Zoom Position”) will be configured according to the BESTSHOT sample scene settings when you turn it back on again.
Page 110: Playback
The actual display image appears a short while after the preview image. This does not apply to images copied from another digital camera.
Page 111: Zooming The Display Image
PLAYBACK Zooming the Display Image Perform the following procedure to zoom the image currently on the monitor screen up to four times its normal size. In the PLAY mode, use [ ] and [ ] to display the image you want. Slide the zoom controller towards to enlarge the image.
Page 112: Resizing An Image
PLAYBACK Resizing an Image You can use the following procedure to change an image to one of the three sizes. 1600 × 1200-pixel UXGA size 1280 × 960-pixel SXGA size 640 × 480-pixel VGA size • VGA is the optimum image size for attachment to e-mail messages or incorporation into Web pages.
Page 113: Cropping An Image
PLAYBACK IMPORTANT! • Resizing an image creates a new file that contains the image in the size you select. The file with the original image also remains in memory. • Images smaller than 640 × 480 pixels cannot be resized. •...
Page 114 PLAYBACK Use the zoom controller to make the cropping boundary larger or smaller. • The size of the cropping boundary depends on the size of the image on the display. Use [ ], [ ], [ ], and [ ] to move the cropping boundary up, down, left, or right until the area of the image you want to extract is within the boundary.
Page 115: Playing A Movie
PLAYBACK Playing a Movie Use the following procedure to play back a movie that was recorded in the Movie mode. In the PLAY mode, press [ ] and [ ] to scroll through images until the movie you want to play is displayed.
Page 116: Displaying The 9-Image View
PLAYBACK Displaying the 9-image View The following procedure displays nine images on the monitor screen at the same time. In the PLAY mode, slide the zoom controller towards ( ) briefly, and then release it. • This displays the 9-image screen with the image that was on the monitor screen in step 2 in the center, with a selection boundary around it.
Page 117: Selecting A Specific Image In The 9-Image View
PLAYBACK Selecting a Specific Image in the 9- image View Display the 9-image view. Use [ ], [ ], [ ], and [ ] to move the selection boundary up, down, left, or right until it is located at the image you want to view.
Page 118: Playing A Slideshow
PLAYBACK • Pressing [ ] while the date selection cursor is located anywhere in the top line of the calendar causes the previous month to appear. • Pressing [ ] while the date selection cursor is located anywhere in the bottom line of the calendar causes the next month to appear.
Page 119 • When the slideshow comes to a movie file, it plays the movie once and advances to the next file. • Images copied from another digital camera or a computer may take longer time to appear than the slideshow interval time you specify.
Page 120: To Specify The Slideshow Images
PLAYBACK To specify the slideshow images Use [ ] and [ ] to select “Images”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET]. To do this: Include all files in file memory in the slideshow Display a single file Include all files in the FAVORITE...
Page 121: To Specify The Slideshow Time
PLAYBACK To specify the slideshow time Use [ ] and [ ] to select “Time”. Use [ ] and [ ] to specify the time setting you want, and then press [SET]. • You can specify a time in the range of 1 to 60 minutes.
Page 122: Rotating The Display Image
• You cannot rotate an image that is protected. To rotate such an image, first unprotect it. • You may not be able to rotate a digital image that was recorded with another type of digital camera. • You cannot rotate movie images.
Page 123: Using Image Roulette
PLAYBACK Using Image Roulette Image Roulette cycles images like a slot machine on the display, before stopping at one of them. When you start an Image Roulette operation, images scroll randomly on the screen. At first, images scroll at high speed. Then the scrolling gradually slows down until a single image is stopped on the screen.
Page 124: Deleting Files
DELETING FILES DELETING FILES You can delete a single file, or you can delete all files currently in memory. IMPORTANT! • Note that file deletion cannot be undone. Once you delete a file, it is gone. Make sure you really do not need a file anymore before you delete it.
Page 125: Deleting All Files
DELETING FILES IMPORTANT! • If a file cannot be deleted for some reason, the message “This function is not supported for this file.” appears when you try to delete it. Deleting All Files In the PLAY mode, press [ ] ( Use [ ] and [ ] to select “All File Delete”, and then press [SET].
Page 126: File Management
FILE MANAGEMENT FILE MANAGEMENT The file management capabilities of the camera make it easy to keep track of images. You can protect files against deletion and store the files you want in the camera’s built-in memory. Folders Your camera automatically creates folders in its built-in flash memory or on the memory card.
Page 127: Protecting Files
FILE MANAGEMENT Protecting Files Once you protect a file it cannot be deleted (page 124). You can protect files individually or you can protect all files in memory with a single operation. To protect a single file In the PLAY mode, press [MENU]. Select the “PLAY”...
Page 128: To Protect All Files In Memory
FILE MANAGEMENT To protect all files in memory In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Protect”, and then press [ ]. Use [ ] and [ ] to select “All Files : On”, and then press [SET]. •...
Page 129 FILE MANAGEMENT Use [ ] and [ ] to select “Save”, and then press [SET]. • This displays the names of the files in built-in memory or on the loaded memory card. Use [ ] and [ ] to select the file you want to copy to the FAVORITE folder.
Page 130: To Display A File In The Favorite Folder
FILE MANAGEMENT To display a file in the FAVORITE folder In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Favorites”, and then press [ ]. Use [ ] and [ ] to select “Show”, and then press [SET]. •...
Page 131: To Delete A File From The Favorite Folder
FILE MANAGEMENT To delete a file from the FAVORITE folder In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Favorites”, and then press [ ]. Use [ ] and [ ] to select “Show”, and then press [SET]. Press [ ] ( Use [ ] and [ ] to select the file you want to delete from the FAVORITE folder.
Page 132: Other Settings
OTHER SETTINGS OTHER SETTINGS Specifying the File Name Serial Number Generation Method Use the following procedure to specify the method for generating the serial number used for file names (page 126). In the REC mode or the PLAY mode, press [MENU].
Page 133: Specifying An Image For The Startup Screen
OTHER SETTINGS Specifying an Image for the Startup Screen You can specify an image you recorded as the startup screen image, which causes it to appear on the monitor screen for about two seconds whenever you press the power button or [ ] (REC) to turn on the camera.
Page 134: Configuring Power Down Image Settings
OTHER SETTINGS Configuring Power Down Image Settings With the power down image feature, you can configure the camera so a specific image stored in camera image memory appears whenever you turn off power. You can specify a snapshot or a movie as the power down image. I To configure power down image settings Use the USB cable to connect the camera to your computer (page 162).
Page 135 OTHER SETTINGS IMPORTANT! • Only a snapshot (JPEG) or movie (AVI) file can be used as the power down image. • Note that the power down image feature works only with images recorded with this camera. The power down image feature may not operate properly when another type of image is specified as the power down image.
Page 136: Using The Alarm
OTHER SETTINGS Using the Alarm You can configure up to three alarms that cause the camera to beep and display a specified image at the time you specify. • You can configure up to three alarms, named “Alarm 1”, “Alarm 2”, and “Alarm 3”. To set an alarm In the PLAY mode, press [MENU].
Page 137: Stopping The Alarm
OTHER SETTINGS Stopping the Alarm When an alarm time is reached while the camera is turned off, the alarm will sound for about one minute (or until you stop it), and then the camera will turn on. To stop the alarm after it starts to sound, press any button.
Page 138: To Select Your Home Time Zone
OTHER SETTINGS To select your Home Time zone In the REC mode or the PLAY mode, press [MENU]. Select the “Set Up” tab, select “World Time”, and then press [ ]. • This displays the current World Time zone. Use [ ] and [ ] to select “Home”, and then press [ ].
Page 139: To Set The Current Time And Date
OTHER SETTINGS To set the current time and date In the REC mode or the PLAY mode, press [MENU]. Select the “Set Up” tab, select “Adjust”, and then press [ ]. Set the current date and the time. To do this: Do this: Change the setting at the current Press [ ] or [ ].
Page 140: To Display The World Time Screen
OTHER SETTINGS Using World Time You can use the World Time screen to view a time zone that is different from the home time zone when you go on a trip, etc. World Time can display the time in one of 162 cities in 32 time zones.
Page 141: To Configure Summer Time (Dst) Settings
OTHER SETTINGS Use [ ] and [ ] to select the city you want, and then press [SET]. • This displays the current time in the city you select. When the setting is the way you want, press [SET] to apply it and exit the setting screen. To configure summer time (DST) settings Summer time is used in some geographical areas to...
Page 142: Changing The Display Language
OTHER SETTINGS Use [ ] and [ ] to select the summer time (DST) setting you want. To do this: Advance the current time setting by one hour Display the current time as-is After the setting is the way you want, press [SET].
Page 143: Changing The Usb Port Protocol
OTHER SETTINGS Changing the USB Port Protocol You can use the procedure below to change the communication protocol of the camera’s USB port when connecting to a computer, printer, or other external device. Select the protocol that suits the device to which you are connecting.
Page 144 OTHER SETTINGS Configuring [ ] (REC) and [ Power On/Off Functions You can use the following procedures to configure [ (REC) and [ ] (PLAY) so power turns on or off whenever they are pressed. In the REC mode or the PLAY mode, press [MENU].
Page 145: Formatting Built-In Memory
OTHER SETTINGS Formatting Built-in Memory Formatting built-in memory deletes any data stored in it. IMPORTANT! • Note that data deleted by a format operation cannot be recovered. Check to make sure you do not need any of the data in memory before you format it. •...
Page 146: Using A Memory Card
USING A MEMORY CARD USING A MEMORY CARD You can expand the storage capabilities of your camera by using a commercially available memory card (SD memory card or MultiMediaCard). You can also copy files from built-in flash memory to a memory card and from a memory card to flash memory.
Page 147: To Insert A Memory Card Into The Camera
USING A MEMORY CARD Using a Memory Card IMPORTANT! • Make sure you turn off the camera before inserting or removing a memory card. • Be sure to orient the card correctly when inserting it. Never try to force a memory card into the slot when you feel resistance.
Page 148: To Remove A Memory Card From The Camera
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the batteries, and contact your dealer or nearest CASIO authorized service center. • Never remove a card from the camera while the operation lamp is flashing. Doing so can cause the file save operation to fail, and even damage the memory card.
Page 149: Memory Card Precautions
USING A MEMORY CARD Load the memory card into the camera. Turn on the camera. Next, enter the REC mode or PLAY mode, and press [MENU]. Select the “Set Up” tab, select “Format”, and then press [ ]. Use [ ] and [ ] to select “Format”, and then press [SET].
Page 150: Copying Files
USING A MEMORY CARD Copying Files Use the procedures below to copy files between built-in memory and a memory card. IMPORTANT! • Only snapshot and movie files recorded with this camera can be copied. Other files cannot be copied. • Files in the FAVORITE folder cannot be copied. To copy all the files in built-in memory to a memory card Load the memory card into the camera.
Page 151: To Copy A Specific File From A Memory Card To Built-In Memory
USING A MEMORY CARD To copy a specific file from a memory card to built-in memory Perform steps 1 through 3 of the procedure under “To copy all the files in built-in memory to a memory card”. Use [ ] and [ ] to select “Card and then press [SET].
Page 152: Printing Images
PRINTING IMAGES PRINTING IMAGES A digital camera provides you with a variety of different ways to print the images it records. The three main printing methods are described below. Use the method that best suits your needs. I Professional Print Service The camera’s DPOF feature lets you specify which images...
Page 153: Dpof
The letters “DPOF” stand for “Digital Print Order Format”, which is a format for recording on a memory card or other medium which digital camera images should be printed and how many copies of the image should be printed. Then you can print on a...
Page 154: To Configure Print Settings For A Single Image
PRINTING IMAGES To configure print settings for a single image In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “DPOF”, and then press [ ]. Use [ ] and [ ] to select “Select images”, and then press [ ]. Use [ ] and [ ] to display the image you want.
Page 155: To Configure Print Settings For All Images
PRINTING IMAGES To configure print settings for all images In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “DPOF”, and then press [ ]. Use [ ] and [ ] to select “All images”, and then press [ ]. Use [ ] and [ ] to specify the number of copies.
Page 156: Using Pictbridge Or Usb Direct-Print
PRINTING IMAGES Using PictBridge or USB DIRECT-PRINT You can connect the camera directly to a printer that supports PictBridge or USB DIRECT-PRINT, and perform image selection and printing using the camera monitor screen and controls. DPOF support (page 153) also lets you specify which images you want to print and how many copies of each should be printed.
Page 157 PRINTING IMAGES Connect the optionally available AC adaptor to the camera. • If you are using batteries to power the camera, check to make sure that the batteries are fully charged. • Note that the camera does not draw any power over the USB cable.
Page 158 PRINTING IMAGES 10 . Use [ ] and [ ] to select the paper size you want to use for printing, and then press [SET]. • The following are the print sizes that are available. 3.5˝ × 5˝ 5˝ × 7˝ 4˝...
Page 159: To Print A Group Of Images
PRINTING IMAGES To print a group of images Use the DPOF procedure on page 153 to specify the images in file memory that you want to print. Perform steps 1 through 10 of the procedure under “To print a single image” on page 156. On the print menu, use [ ] and [ ] to select “DPOF”, and then press [SET].
Page 160: Printing Precautions
PRINTING IMAGES Printing Precautions • See the documentation that comes with your printer for information about print quality and paper settings. • Contact your printer manufacturer for information about models that support PictBridge and USB DIRECT-PRINT, upgrades, etc. • Never disconnect the USB cable, or perform any camera operation while printing is in progress.
Page 161: Exif Print
PRINTING IMAGES Exif Print Exif Print is an internationally supported, open standard file format that makes it possible to capture and display vibrant digital images with accurate colors. With Exif 2.2, files include a wide range of shooting condition information that can be interpreted by an Exif Print printer to produce better- looking prints.
Page 162: Using The Camera With A Windows Computer
VIEWING IMAGES ON A COMPUTER VIEWING IMAGES ON A COMPUTER After using the USB cable to establish a USB connection between the camera and your computer, you can use your computer to view images in file memory and copy images to your computer’s hard disk or other storage media.
Page 163 VIEWING IMAGES ON A COMPUTER IMPORTANT! • Low battery power can cause the camera to power down suddenly during data communication. Use of the special AC adaptor is recommended to power the camera during data communication. • If you want to transfer files from the camera’s built-in memory to a computer, make sure there is no memory card loaded in the camera before you connect the USB cable.
Page 164 VIEWING IMAGES ON A COMPUTER Click [USB driver] and then [Install]. • This starts installation. • The following steps show installation under the English version of Windows. On the screen that appears after installation is complete, select the “Yes, I want to restart my computer now.”...
Page 165 VIEWING IMAGES ON A COMPUTER Turn on the camera, and then press [MENU]. • It makes no difference whether the camera is in the REC mode or PLAY mode. Select the “Set Up” tab, select “USB”, and then press [ ]. Use [ ] and [ ] to select “Mass Storage (USB DIRECT-PRINT)”, and then press [SET].
Page 166 VIEWING IMAGES ON A COMPUTER Turn on the camera. • This will cause the “New Hardware...” dialog box to appear on the computer screen as the computer automatically detects the camera’s file memory. After you install the USB driver, “New Hardware...” dialog box will no longer appear when you perform the above steps to establish a USB connection.
Page 167 VIEWING IMAGES ON A COMPUTER I Windows 98, 2000, Me 1. In the camera’s file memory (Removable Disk), right- click the “Dcim” folder. 2. On the shortcut menu that appears, click [Copy]. 3. Double click [My Documents] to open it. 4.
Page 168: Usb Connection Precautions
VIEWING IMAGES ON A COMPUTER USB Connection Precautions • Do not leave the same image displayed on your computer screen for a long time. Doing so can cause the image to “burn in” on the screen. • Never disconnect the USB cable, or perform any camera operation while data communication is in progress.
Page 169 VIEWING IMAGES ON A COMPUTER IMPORTANT! • Low battery power can cause the camera to power down suddenly during data communication. Use the optional AC adaptor is recommended to power the camera during data communication with a computer. • If you want to transfer files from the camera’s built-in memory to a computer, make sure there is no memory card loaded in the camera before you connect the USB cable.
Page 170 VIEWING IMAGES ON A COMPUTER Turn on the camera, and then press [MENU]. • It makes no difference whether the camera is in the REC mode or PLAY mode. Select the “Set Up” tab, select “USB”, and then press [ ]. Use [ ] and [ ] to select “Mass Storage (USB DIRECT-PRINT)”, and then press [SET].
Page 171 VIEWING IMAGES ON A COMPUTER Turn on the camera. • Your Macintosh will see the camera’s file memory as a drive. • The appearance of the drive icon depends on the Mac OS version you are using. • After installing the USB driver, your Macintosh will see the camera’s file memory as a drive whenever you establish a USB connection between them.
Page 172: Operations You Can Perform From Your Computer
VIEWING IMAGES ON A COMPUTER USB Connection Precautions • Do not leave the same image displayed on your computer screen for a long time. Doing so can cause the image to “burn in” on the screen. • Never disconnect the USB cable, or perform any camera operation while data communication is in progress.
Page 173: Using A Memory Card To Transfer Images To A Computer
VIEWING IMAGES ON A COMPUTER Using a Memory Card to Transfer Images to a Computer The procedures in this section describe how to transfer images from the camera to your computer using a memory card. Using a Computer with a Built-in SD Memory Card Slot Insert the SD memory card directly into the slot.
Page 174: Memory Data
VIEWING IMAGES ON A COMPUTER Memory Data Images recorded with this camera and other data are stored in memory using DCF (Design rule for Camera File system) protocol. DCF protocol is designed to make it easier to exchange image and other data between digital cameras and other devices.
Page 175: Image Files Supported By The Camera
VIEWING IMAGES ON A COMPUTER I Folder and File Contents • DCIM folder Folder that stores all of the digital camera files • Storage folder Folder for storing files created by the digital camera • Image file File that contains an image recorded with the digital camera (File Name Extension: JPG) •...
Page 176: Built-In Memory And Memory Card Precautions
VIEWING IMAGES ON A COMPUTER Built-in Memory and Memory Card Precautions • Note that the folder named “DCIM” is the parent (top) folder of all the files in memory. When transferring memory contents to a hard disk, CD-R, MO disk, or other external storage, treat all the contents inside a DCIM folder as a set and always keep them together.
Page 177: Using The Camera With A Computer
USING THE CAMERA WITH A COMPUTER USING THE CAMERA WITH A COMPUTER The album feature of the camera creates files that make it possible for you to view images on your computer in a photo album layout. You can also use the applications contained on the CD-ROM that comes bundled with the camera to automate image transfer and to retouch images.
Page 178 USING THE CAMERA WITH A COMPUTER Select the “PLAY” tab, select “Create Album”, and then press [ ]. Use [ ] and [ ] to select “Create”, and then press [SET]. • This starts creation of the album, and causes the message “Busy...Please wait...”...
Page 179: Selecting An Album Layout
USING THE CAMERA WITH A COMPUTER Selecting an Album Layout You can select from among 10 different display layouts for an album. In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Create Album”, and then press [ ]. Use [ ] and [ ] to select “Layout”.
Page 180: Background Color
USING THE CAMERA WITH A COMPUTER I Background Color You can specify white, black, or gray as the color of the album background using the procedure under “Configuring Detailed Album Settings”. I Album Type There are two album types: “Normal” and “Index/Info”. “Normal”...
Page 181 USING THE CAMERA WITH A COMPUTER I Auto Album Creation On/Off This setting controls whether an album is created automatically whenever you turn off the camera. To do this: Select this option: Turn on auto album creation Turn off auto album creation •...
Page 182: Viewing Album Files
USING THE CAMERA WITH A COMPUTER Viewing Album Files You can view and print album files using your computer’s Web browser application. Use your computer to access the data in built- in memory or on the memory card, or access a memory card with your computer (pages 162, 173).
Page 183 USING THE CAMERA WITH A COMPUTER Index Info • The following describes the information that appears on the Info Screen. This Info Screen item: File Size Resolution Quality Recording mode Light metering Shutter speed Aperture stop Exposure comp Focusing mode Flash mode AF area Sharpness...
Page 184: Saving An Album
USING THE CAMERA WITH A COMPUTER NOTE • When printing an album page, you should set up your Web browser as described below. — Select the browser frame where the images are located. — Set margins to the lowest possible values. —...
Page 185: To Delete An Album
• This deletes the album and returns to the PLAY mode screen. Installing the Software from the CD-ROM Your digital camera comes bundled with useful applications for using it in combination with a computer. Install the applications you need on your computer.
Page 186 • See the user documentation file (PDF) on the bundled “CASIO Digital Camera Software” CD-ROM for details about using Photo Loader. Photohands (for Windows) Photohands includes retouching tools for adjusting image color, contrast, and brightness, for resizing images, and for changing image orientation.
Page 187: Computer System Requirements
USING THE CAMERA WITH A COMPUTER Computer System Requirements Computer system requirements depend on each of the applications, as described below. Windows USB Driver* Photo Loader /2000/Me/ XP/2000/Me/98 Memory – At least 16MB – At least 7MB In the case of Windows 2000, you need to install a data file that enables use of the operating system’s standard USB driver.
Page 188: Installing Software From The Cd-Rom In Windows
“readme” file on the CD-ROM (CASIO Digital Camera Software) that comes bundled with the camera. • The software on the CD-ROM (CASIO Digital Camera Software) that comes bundled with the camera does not support operation under Mac OS X (10.0).
Page 189: Getting Started
USING THE CAMERA WITH A COMPUTER Getting Started Start up your computer and insert the CD-ROM into its CD- ROM drive. This will automatically launch the menu application, which displays a menu screen on your computer. • The menu application may not start up automatically on some computers.
Page 190: Installing An Application
USING THE CAMERA WITH A COMPUTER Installing an Application Click the “Install” button for the application you want to install. Follow the instructions that appear on your computer screen. IMPORTANT! • Be sure to follow the instructions carefully and completely. If you make a mistake when installing Photo Loader, you may not be able to browse your existing library information and HTML files that are created automatically by Photo Loader.
Page 191: User Registration
USING THE CAMERA WITH A COMPUTER User Registration You can perform user registration over the Internet. To do so, of course, you need to be able to connect to the Internet with your computer. Click the “Register” button. • This starts up your Web browser and accesses the user registration website.
Page 192: Viewing User Documentation (Pdf Files)
Systems website. I To view the camera user’s guide On the CD-ROM, open the “Manual” folder. Open the “Digital Camera” folder, and then open the folder for the language whose user’s guide you want to view. Open the file named “camera_xx.pdf”.
Page 193 On the CD-ROM, open the “Manual” folder. Open the “Photo Loader” folder and then open the “English” folder. Open “PhotoLoader_english”. I To register as a camera user Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/...
Page 194: Menu Reference
APPENDIX APPENDIX Menu Reference The following shows lists of menus that appear in the REC mode and PLAY mode, and their settings. • The settings that are underlined in the following table are initial defaults. I REC mode G REC tab menu REC Mode Snapshot / BESTSHOT /...
Page 195 APPENDIX G Set Up tab menu Beep On / Off Startup On (Selectable image) / Off File No. Continue / Reset World Time Home / World Home time setup (city, DST, etc.) World Time setup (city, DST, etc.) Date Style YY/MM/DD / DD/MM/YY / MM/DD/YY Adjust Time setting...
Page 196: Indicator Lamp Reference
APPENDIX G Set Up tab menu Beep On / Off Startup On (Selectable image) / Off File No. Continue / Reset World Time Home / World Home time setup (city, DST, etc.) World Time setup (city, DST, etc.) Date Style YY/MM/DD / DD/MM/YY / MM/DD/YY Adjust Time setting...
Page 197: Rec Mode
APPENDIX REC mode Self-timer Operation Lamp Lamp Green Operational (Power on, recording enabled) Pattern 3 Flash is charging. Flash charging is complete. Auto Focus operation was successful. Pattern 3 Cannot Auto Focus. Monitor screen is off. Pattern 2 Storing image Storing movie data / processing Pattern 1 image data...
Page 198: Charger Unit
APPENDIX PLAY mode Self-timer Operation Lamp Lamp Green Operational (Power on, recording enabled) One of the following operations is being performed: delete, DPOF, Pattern 3 image protect, copy, album creation, format, power down Memory card problem / Memory Pattern 2 card is unformatted.
Page 199: Troubleshooting Guide
APPENDIX Troubleshooting Guide Symptom Power does not turn on. 1) The batteries are not oriented correctly. 2) The batteries are dead. 3) You are using the wrong type of AC adaptor. Camera suddenly powers 1) Auto Power Off activated (page 46). down.
Page 200 APPENDIX Symptom Auto Focus does not focus 1) The lens is dirty. properly 2) The subject is not located in the center of the focus frame when you compose the image. 3) The subject you are shooting is a type that is not compatible with Auto Focus operation (page 73).
Page 201 Position the camera so sunlight does not shine directly into the lens. Use a different card. This camera cannot display non-DCF images recorded onto a memory card using another digital camera. Remove the batteries from the camera, reinsert them, and then try again. Action ) for close-ups.
Page 202 APPENDIX Symptom Monitor screen is off. 1) USB communication is in progress. 2) The monitor screen is turned off (in the REC mode). Cannot transfer files over a 1) USB cable is not connected securely. USB connection. 2) USB driver is not installed. 3) Camera is turned off.
Page 203: If You Have Problems Installing The Usb Driver
You may not be able to install the USB driver properly if you use the USB cable to connect the camera to a computer running Windows 98 before installing the USB driver from the bundled CD-ROM (CASIO Digital Camera Software), or if you have another type of driver installed.
Page 204: Display Messages
APPENDIX Display Messages Alarm setting This message appears after you change the alarm complete. setting. Battery is low. The batteries are dead. Cannot correct Keystone correction cannot be performed for some image! reason. The image will be stored as-is, without correction (page 93).
Page 205 SYSTEM ERROR Your camera system is corrupted. Contact your retailer or a CASIO service center. The card is locked. The LOCK switch of the SD memory card is locked. You cannot store images to or delete images from a memory card that is locked.
Page 206: Specifications
APPENDIX Specifications Product ... Digital Camera Model ... QV-R61 I Camera Functions Image Files Format Snapshots ... JPEG (Exif Ver.2.2); DCF (Design rule for Camera File system) 1.0 standard; DPOF compliant Movies ... AVI (Motion JPEG) Recording Media ... 9.7 MB built-in flash memory...
Page 207 APPENDIX Delete ... Single-file, all files (with protection) Effective Pixels ... 6.00 million Imaging Element ... 1/1.8-inch square pixel color CCD (Total pixels: 6.37 million) Lens/Focal Distance ... Seven lenses in six groups, including an aspherical lens F2.8 (W) to 4.9 (T); f= 8 (W) to 24mm (T) (equivalent to approximately 39 (W) to 117 (T) for 35mm film) Zoom ...
Page 208 APPENDIX Monitor Screen ... 2.0-inch TFT color LCD 84,960 pixels (354 × 240) Viewfinder ... Monitor screen and optical viewfinder Timekeeping Functions ... Built-in digital quartz clock Date and Time ... Recorded with image data Auto Calendar ... To 2049 World Time ...
Page 209 APPENDIX *1 Number of Shots (CIPA Standard) • Temperature: 23°C (73°F) • Monitor screen: On • Zoom operation between full wide to full telephoto every 30 seconds, during which two images are recorded, one image with flash; power turned off and back on every time 10 images are recorded. *2 Continuous Recording Conditions •...
Page 210 APPENDIX Power Supply • Use only the special HR-3U rechargeable nickel-metal hydride batteries to power this camera. Use of any other type of battery is not supported. • This camera does not have separate batteries for the clock. The date and time settings of the camera are cleared whenever power is totally cut off (from both the batteries and AC adaptor).

Casio QV-R61 User Manual

Introduction

Quick Start Guide

Contents

Getting Ready

Basic Image Recording

Other Recording Functions

Playback

Deleting Files

File Management

Other Settings

Using a Memory Card

Printing Images

162 Viewing Images on a Computer

Using the Camera with a Computer

Appendix

Quick Links

Related Manuals for Casio QV-R61

Summary of Contents for Casio QV-R61
