- Page 1 LINE ARRAY SYSTEM HICAST-4L / HICAST-24L / HICAST-210S / HICAST-212S USER MANUAL...
- Page 2 WARNING! VAROITUS! Do not open cover. No user-serviceable parts inside. Refer servicing to qualified service personnel Älä avaa kantta. Ei sisällä käyttäjä-huollettavia osia. Huollot saa suorittaa vain pätevä huoltomies. Do not place the product in a location near a heat source such as a radiator, or in an area subject to Älä...
- Page 3 ADVARSEL! OPOZORILO! Ikke åpne dekselet. Inneholder ingen deler som kan brukes. Overlat reperasjon til kvalifisert Ne odpirajte pokrova. V notranjosti ni nobenih delov, ki jih uporabnik lahko sam popravlja. Popravilo servicepersonell. prepustite usposobljenemu osobju Ikke plasser produktet i nærheten av varmekilder som f.eks. en radiator, eller i områder som er utsatt for Ne postavljajte izdelka na lokacijo v bližini vira toplote, kot je radiator, ali na območje, ki je izpostavljeno direkte sollys, mye støv, mekanisk vibrasjon eller støt.
- Page 4 INTRODUCTION Thank you for purchasing the SubZero HiCAST Line Array System. To get the most out of your product, please read this manual carefully. SUBWOOFER • Powerful 10/12” twin cone subwoofer perfect for small to mid sized venues and outdoor performances.
- Page 5 FUNCTIONS - SUBWOOFER ARRAY LEVEL LEVEL FLAT LIVE 1 LIVE 2 DJ 1 DJ 2 PRESET INPUT STEREO MONO LINK OUT CAUTION RISK OF ELECTRIC SHOCK DISCONNECT INPUT POWER SERIAL NO.: BEFORE OPENING. Ta=40°C WARNING: THIS APPLIANCE MUST BE EARTHED INPUT POWER: 110-120/220-240VAC, 50/60Hz FUSE: T8A, 115V/230V POWER CONSUMPTION: 1000W...
- Page 6 FUNCTIONS - SUBWOOFER 1. SATELLITE LEVEL 8. DSP PRESET Adjust this knob for independent control over The DSP knob allows you to choose from one the satellite speakers. of five presets ( see DSP information sheet on page 8). 2. SUBWOOFER LEVEL Adjust this knob for independent control over •...
- Page 7 FUNCTIONS - ARRAY SPEAKER 3. PARALLEL OUT 1. SERIES OUT Provides output for a parallel connection via ¼” Adjust this switch to determine whether the TS Jack. signal is provided from one speaker to the next in either series or parallel (see set up guide on 4.
-
Page 8: Dsp Settings
(DSP) PRESETS The HiCAST Line Array System includes built-in presets, so you get the optimum sound for your venue. The advanced Digital Signal Processing (DSP) gives you clarity to suit Live sound and DJ sets to ensure you sound great straight out of the box! Each of the five presets have been carefully fine-tuned by professional audio engineers and are easily selected at the touch of a button. -
Page 9: Speaker Setup
2 SPEAKER SET-UP STAGE / HEAD HEIGHT HEIGHT FROM FLOOR: 1 -2 METRES AUDIENCE COVERAGE: SINGLE SPEAKER: 50 - 100 PEOPLE TWIN SPEAKER: 200 - 300 PEOPLE FROM SUB 10˚ INPUT 5˚ 0˚ PARALLEL SERIES 10˚ INPUT 5˚ 0˚ PARALLEL SERIES ON STAGE / OVER HEAD HEIGHT HEIGHT FROM FLOOR: 2 - 3 METRES... - Page 10 4 SPEAKER SET-UP STAGE / HEAD HEIGHT FROM SUB HEIGHT FROM FLOOR: 1 -2 METRES AUDIENCE COVERAGE: 200 - 300 PEOPLE INPUT PARALLEL SERIES 10˚ INPUT 5˚ 0˚ PARALLEL SERIES 10˚ 5˚ 0˚ INPUT PARALLEL 10˚ SERIES 5˚ 0˚ INPUT 10˚...
- Page 11 8 SPEAKER SET-UP FLOWN/ABOVE HEAD HEIGHT HEIGHT FROM FLOOR: 3+ METRES AUDIENCE COVERAGE: 500+ PEOPLE FROM SUB INPUT PARALLEL 10˚ SERIES 5˚ 0˚ INPUT 10˚ PARALLEL 5˚ 0˚ SERIES 10˚ INPUT 5˚ 0˚ PARALLEL SERIES 10˚ 5˚ 0˚ INPUT PARALLEL 10˚...
- Page 12 SPEAKER SET UP 1. Insert the front pillar into the slots at the bottom of the speaker. This allows you to connect the speaker to the stand adapter. Please ensure that both holes are aligned before doing so. 2. Achieve the speaker angle you desire by aligning the holes to your intended placement and then inserting the 10˚...
-
Page 13: Speaker Connections
SPEAKER CONNECTIONS ONE SPEAKER ARRAY TWO SPEAKER ARRAY FOUR SPEAKER ARRAY (PER SIDE) (PER SIDE) (PER SIDE) FROM SUB FROM SUB FROM SUB INPUT INPUT INPUT PARALLEL PARALLEL PARALLEL SERIES SERIES SERIES INPUT INPUT PARALLEL PARALLEL SERIES SERIES INPUT PARALLEL SERIES INPUT PARALLEL... -
Page 14: Specifications
SPECIFICATIONS Single Speaker Twin Speaker Type ....4’’ 2-way passive system Type ....Dual: 4’’ 2-way passive system Frequency response Frequency response... - Page 15 10” Subwoofer 12” Subwoofer Type ....Dual 10’’ bass reflex Type ....Dual 12’’ bass reflex subwoofer, 1.1 function subwoofer, 2.1 function Frequency response...
- Page 16 KETTLESTRING LANE | YORK | YO30 4XF | UNITED KINGDOM METALLVÄGEN 45A | 195 72 ROSERSBERG | STOCKHOLM | SVERIGE LAHNSTRAßE 27 | 45478 MÜLHEIM AN DER RUHR | DEUTSCHLAND If you have any more questions about this product, please do not hesitate to contact the Gear4music Customer Service Team on: +44 (0) 330 365 4444 or info@gear4music.com...
