Yamato MG600H Instruction Manual

● Thank you for purchasing Yamato's Mug Mixer.
● In order to ensure correct operation of the mixer, be sure to read this manual and the guarantee card
carefully.
After reading, keep the manual together with the guarantee card in custody so that you can refer to it any
time.
1. Cautions for Handling
(1) This product is not of an explosion-proof structure and must not be used in the inflammable
atmosphere.
(2) Be sure to establish the earth of the product.
(3) The stirring table of the product is a hot plate. Pay due attention not to suffer burn.
(4) The product is based on the safety design to protect the internal mechanism, so that the heater circuit
is not activated unless stirring is made. To heat the hot plate, be sure to turn the STIR knob to ON,
then turn the HEAT knob to ON.
(5) The hot plate has the ceramic coating that may be damaged when rubbed with a hard object.
(6) When raising the rotation speed, raise it gradually. With sudden increase of the rotation speed, the
stirrer can not follow the speed, resulting in failure to turn.
(7) Note that, when the temperature rises, the sample may have the viscosity lowered and splash.
2. Operation Method
(1) Set all of six frequency select switches on the main body backside to the frequency of power supply to
be applied.
(2) Install the product in a stable place, confirm that the POWER switch is OFF, the HEAT knob is OFF,
and the STIR knob is OFF, and connect the power cord to AC 100V. Be sure to connect the earth
wire.
(3) Place the stirrer in the container and place the container in the middle of the stirrer table to be used.
(4) Turn ON the POWER switch and turn the STIR knob of the same number as the stirrer table to be used
to the ON position. Stirring begins. Turning the know further clockwise causes increase in the
stirring speed.
(5) Turn the HEAT knob of the same number as the stirrer table to be used to the ON position. The
heater is energized and the red pilot lamp goes ON. Turning the knob further clockwise causes the
set temperature of the hot plate to rise further. When adjusting the temperature, turn the knob
properly to the desired position while measuring the sample with the thermometer. Since the set
temperature may deviate depending on the shape of sample container and the sample liquid amount,
reset the knob each time while measuring the sample with the thermometer.
(6) Stirring and hot plate heating can be made for maximum six samples simultaneously.
temperature for each sample individually.
(7) The motor rotation speed may decelerate depending on the temperature of hot plate. Adjust the
rotation speed to the desired value while checking the stirring condition.
Mug Mixer, Type MG600H
Instruction Manual
First Edition
Yamato Scientific Co., Ltd.
Commodity code: 231206
Set the
