This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
®
RHINO
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
OPERATOR'S MANUAL
© 2011 Alamo Group Inc.
148

ROTARY MOWER

Part No. 00781398C
$0.00

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 148 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RHINO 148

Summary of Contents for RHINO 148

  • Page 1: Rotary Mower

    Published 02/11 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. C01- Cover ®...
  • Page 2 To the Owner/Operator/Dealer This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the implement at all times. A Manual canister is provided on the implement where this manual can be properly stored. If you lose or damage this manual a free replacement manual can be obtained from an authorized Rhino dealer or by down loading the manual from the Rhino website www.servis-rhino.com BEFORE YOU START! READ, UNDERSTAND, and FOLLOW the information provided in this manual, the AEM...
  • Page 3 In order to reduce accidents and enhance the safe operation of mowers, Alamo Group Ag Division, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
  • Page 4 Alamo Group Ag. Division will provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual Requester Name:_________________________________Phone:___________________________ Requester Address: ___________________________________________ City:_____________________________________...
  • Page 5 DEALER to CUSTOMER Pre-Delivery / Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable. Dealer should also inform the Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible) and of Purchaser’s responsibility to train his/her operators in safe operation procedures.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS SAFETY SECTION ... 1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES ... 1-2 OPERATOR SAFETY ... 1-3 CONNECTION OR DISCONNECTING IMPLEMENT SAFETY ... 1-4 CRUSHING HAZARDS ... 1-5 THROWN OBJECT HAZARDS ... 1-6 RUN OVER HAZARDS ... 1-8 PTO ENTANGLEMENT HAZARDS ... 1-9 MOWER BLADE CONTACT HAZARDS ...
  • Page 8 Dismounting the Tractor ... 4-7 STARTING THE TRACTOR ... 4-8 CONNECTING THE MOWER TO THE TRACTOR ... 4-9 Connecting Mower - Lift Type (Quick Hitch) ... 4-10 Safety Tow Chain ... 4-11 SETTING THE MOWER ... 4-11 Setting Mower Height- Lift Type - (Standard or Quick Hitch) ... 4-12 Setting Deck Pitch ...

  • Page 9: Safety Section

    SAFETY SECTION Safety Section 1-1...

  • Page 10: General Safety Instructions And Practices

    NOTE: If you want a translation of this safety section in one of the following Languages, please contact: Translations at 1502 E. Walnut Street Seguin, TX 78155; Fax: (830) 372-9529; Safety Section Translations are available in Spanish, Portuguese, French, German, Russian. 148 02/11 © 2011 Alamo Group Inc. SAFETY...

  • Page 11: Operator Safety

    DO NOT EXCEED IMPLEMENT RATED PTO SPEED • AVOID exceeding rated PTO speeds that may result in broken drivelines or blade failures. SAFETY SIGNS: • REPLACE missing, damaged or unreadable safety signs immediately. 148 02/11 © 2011 Alamo Group Inc. SAFETY PN OS01 Safety Section 1-3...

  • Page 12: Connection Or Disconnecting Implement Safety

    Excessive vibration, thrown objects, blade and implement failures by doubling operating speed. • Increased working length exposing unshielded driveline areas and entanglement hazards. DO NOT connect the Mower to a tractor with the PTO directly connected to the Tractor transmission. 148 02/11 © 2011 Alamo Group Inc. SAFETY Safety Section 1-4...

  • Page 13: Crushing Hazards

    USE tongue jack to control implement tongue movement. • USE tongue JACK to lift heavy implement tongues. • AVOID overloading jack to prevent jack failure and injury. 148 02/11 © 2011 Alamo Group Inc. SAFETY PN CH02 Safety Section 1-5...

  • Page 14: Thrown Object Hazards

    3. INSPECT AREA thoroughly before mowing to REMOVE potential THROWN OBJECT HAZARDS, 4. NEVER ALLOW BLADES to CONTACT SOLID OBJECTS like wire, rocks, post, curbs, guardrails, or ground while mowing. PN TO02 148 02/11 © 2011 Alamo Group Inc. SAFETY Safety Section 1-6...
  • Page 15 1. STOP PTO and tractor ENGINE. 2. INSPECT mower for vibration source 3. REPLACE any damage parts and bent or damaged BLADES. 148 02/11 © 2011 Alamo Group Inc. SAFETY when two or more mowers are operating in mowing area.

  • Page 16: Run Over Hazards

    ONLY mount or dismount when tractor and moving parts are stopped. • STOP ENGINE AND PTO, engage parking brake, lower implement, allow all moving parts to stop and remove key before dismounting from tractor. 148 02/11 © 2011 Alamo Group Inc. SAFETY PN RO01...

  • Page 17: Pto Entanglement Hazards

    DO NOT USE PTO ADAPTER. Using a PTO adapter can cause excessive vibration, thrown objects, blade and implement failures by doubling operating speed. Increased working length exposing unshielded driveline areas. 148 02/11 © 2011 Alamo Group Inc. SAFETY Safety Section 1-9...

  • Page 18: Mower Blade Contact Hazards

    STOP rotating BLADES disengage PTO and wait for blade to stop rotating before raising mower deck or wings • STOP LOOK and LISTEN before approaching the mower to make sure all rotating motion has stopped. 148 02/11 © 2011 Alamo Group Inc. SAFETY...

  • Page 19: High Pressure Oilleak Hazards

    KEEP hands and body AWAY from pin holes and nozzles ejecting hydraulic fluid. • Hydraulic fluid may cause gangrene if not surgically removed immediately by a doctor familiar with this form of injury. PN HP01 148 02/11 © 2011 Alamo Group Inc. SAFETY Safety Section 1-11...

  • Page 20: Electrical & Fire Hazards

    ADJUST SLIP CLUTCHES to avoid excessive slippage and clutch plate heating. • CLEAR any grass clippings or debris buildup around mower drivelines, slip clutches, and gearboxes. • SHUT OFF ENGINE while refueling. 148 02/11 © 2011 Alamo Group Inc. SAFETY PN EF02 Safety Section 1-12...

  • Page 21: Transporting Hazards

    USE low speeds and gradual steering on curves, hills, rough or uneven surfaces and on wet roads • TURN ON tractor FLASHING WARNING LIGHTS. • ALLOW clearance for implement swing while turning. 148 02/11 © 2011 Alamo Group Inc. SAFETY PN TH02 Safety Section 1-13...

  • Page 22: Hazards With Maintenance Of Implement

    California to cause cancer, birth defects or other reproductive harm. • Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the state of California to cause cancer, birth defects or other reproductive harm. 148 02/11 © 2011 Alamo Group Inc. SAFETY CONDITION...

  • Page 23: Parts Information

    Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void warranties, and present a safety hazard. Use genuine Rhino mower parts for economy and safety. 148 02/11 © 2011 Alamo Group Inc. SAFETY...

  • Page 24: Decal Location

    (Some shipping and handling charges may apply). Contact your Rhino dealer to order replacement decals. 148 02/11 Safety Section 1-16 © 2011 Alamo Group Inc.
  • Page 25 02959924 D454 D614 D395 D590 * Furnished by Tractor Manufacturer ** Furnished by Driveline Manufacturer Decal Sheets Liability Sheet - 00781352 Logo Sheet - 00781317 148 02/11 © 2011 Alamo Group Inc. SAFETY TYPE DANGER DANGER WARNING DANGER IMPORTANT LOGO...

  • Page 26: Decal Description

    SAFETY Decal Description 148 02/11 Safety Section 1-18 © 2011 Alamo Group Inc.
  • Page 27 SAFETY 148 02/11 Safety Section 1-19 © 2011 Alamo Group Inc.
  • Page 28 SAFETY 148 02/11 Safety Section 1-20 © 2011 Alamo Group Inc.
  • Page 29 SAFETY 148 02/11 Safety Section 1-21 © 2011 Alamo Group Inc.
  • Page 30 SAFETY 148 02/11 Safety Section 1-22 © 2011 Alamo Group Inc.
  • Page 31 SAFETY 148 02/11 Safety Section 1-23 © 2011 Alamo Group Inc.
  • Page 32 SAFETY 148 02/11 Safety Section 1-24 © 2011 Alamo Group Inc.

  • Page 33: Federal Laws And Regulations

    Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) 148 02/11 © 2011 Alamo Group Inc. SAFETY...
  • Page 36 We wish to acknowledge the contributions of the members of AEM’s Industrial/Agricultural Mower Manufacturers Council Copyright, 2010, by the Association of Equipment Manufacturers. All rights reserved. This work may not be reproduced or disseminated in whole or in part by any means This safety manual is intended to point out some of the basic safety situations that may be encountered during the normal operation and maintenance of your machine...

  • Page 37: Safety Alerts

    Symbol This Safety Alert Symbol means: “ATTENTION! STAY ALERT! YOUR SAFETY IS INVOLVED!” The Safety Alert Symbol identifi es important safety messages on equipment, safety signs, in manuals or elsewhere. When you see this symbol, be alert to the possibility of death or personal injury. Follow instructions in the safety message.

  • Page 38: The Industrial/Agricultural Mower

    The Industrial/Agricultural Mower Industrial/Agricultural Mower Types Mowers are used for pasture clipping, crop residue shredding, heavy brush cutting, waterways, right-of- ways, roadside or highway mowing. Also, these mowers are used for cutting grass and other growth in public areas such as parks and cemeteries. Folding Wing Rotary The Industrial/Agricultural Mower Agricultural Disc Mower Types...

  • Page 39: Follow A Safety Program

    Follow A Safety Program Protect Yourself Wear personal protective clothing and Personal Protective Equipment (PPE) issued to you or called for by job conditions. You must ALWAYS wear safety glasses with side shields. You may also need: — Hard hat —...
  • Page 40 Follow A Safety Program Avoid Injury From Raised Equipment Avoid possible crushing injury from falling mower or other raised equipment. Avoid Crushing – Securely Support Before working near or under raised mower or equipment parts: — Securely support or block up raised mower or equipment parts according to the operator’s manual.
  • Page 41 Follow A Safety Program Be Alert! Know where to get assistance. Know how to use a fi rst aid kit and fi re extinguisher/fi re suppression system. Be Aware! Take advantage of training programs offered. Be Careful! Human error is caused by many factors: carelessness, fatigue, overload, preoccupation, unfamiliarity of operator with the machine, drugs, and alcohol to name a few.
  • Page 42 Follow A Safety Program Some Rules You Must Work By (continued) — Only qualifi ed and authorized individuals may operate this equipment. — Never allow children to play on, ride on or operate the equipment. Children are not qualifi ed to operate this equipment.

  • Page 43: Prepare For Safe Operation

    Prepare For Safe Operation Check The Mower And Tractor Equipment Before beginning your work day inspect the machine and have all systems in good operational condition. WARNING! Prevent possible crushing injury from falling equipment. Hydraulic system or part failure could cause unsupported equipment to fall.
  • Page 44 Prepare For Safe Operation Know The Work Area Before you operate the mower thoroughly inspect the work area. Walk around the area and inspect the surfaces you will travel on when using the mower. Locate and avoid: — Deep mud —...
  • Page 45 Prepare For Safe Operation Tractor And Mower Controls Safety Test Start the tractor following the specifi c procedures in the manufacturer’s operator’s manual. These procedures normally include: — Fasten and adjust seat belt on your ROPS-equipped tractor. — Check parking brake for engagement. —...
  • Page 46 Prepare For Safe Operation Hitching Mower To Tractor Three-point hitch-mounted mowers: — Refer to mower and tractor manufacturers’ manuals. — Place tractor’s hydraulic power lift (rockshaft) selector lever in down position to avoid unexpected movement. — Explain the hitching procedures to those operators who cannot read.

  • Page 47: Start Safely

    Make The Right Start Mow only in daylight or good artifi cial light conditions. Avoid serious injury or death from mower-thrown objects or blade contact: — Keep chain shields, fl exible or solid defl ector shields or discharge chutes in place and in good repair. —...
  • Page 48 Mower-Thrown Objects (continued) Disc Mowers — When using a disc mower it is important to know the area to be mowed. If the operator has mowed the fi eld before and is familiar with all obstacles that may be present, it is suffi cient to watch ahead of the mower path for any additional objects that may have entered the fi eld.
  • Page 49 Under Mount Mower Safety Practices When mowing with an under mount mower: — Keep removable discharge chute in place and over discharge opening. — Never stand on a mower housing when the tractor engine is operating. — Distribute grass clippings with discharge chute facing mowed area.
  • Page 50 Wing And Side Mount Mowers Safety Practices Raised wing positions reduce shielding protection and increases the thrown object and blade contact hazard risks. Avoid possible serious injury or death by thrown objects or blade contact from raising and lowering wings during mowing operations: —...
  • Page 51 Uneven Terrain Mowing Safety Practices (continued) — Use extreme care to maintain control over the equipment when operating in these conditions. — Increase tractor stability by adding wheel weights, ballast and increasing wheel spacing to maximum. Refer to operator’s manual for recommendations. —...

  • Page 52: Park Safely

    Parking Safety Practices — Use designated or out-of-traffi c areas. — Use fi rm level ground locations. — Set parking brake. — Lower raised equipment to ground. Shut down the mower and tractor using proper equipment shut down practice before dismounting tractor.

  • Page 53: Perform Maintenance Safely

    Dismounting Properly — Never dismount from moving equipment. — Never jump from any machines. — Dismount carefully. — Check for slippery steps. — Keep feet and hands away from controls. — Use handholds and steps during dismount. — Face machine and use three-point contact (2 hands and 1 foot or 2 feet and 1 hand).
  • Page 54 Perform Maintenance Safely Prepare Yourself Wear personal protective clothing and Personal Protective Equipment (PPE) issued to you or called for by job conditions. You must ALWAYS wear safety glasses with side shields. You may also need: — Hard hat — Safety shoes —...
  • Page 55 Perform Maintenance Safely Prepare The Machine Stored energy sources (electrical, mechanical, hydraulic, pneumatic, chemical, thermal, etc.) must be controlled or reduced to a practical minimum before performing any maintenance, repair or service procedures. Safety practices to prevent potential injuries from energy-releasing sources: —...
  • Page 56 Perform Maintenance Safely Perform Maintenance Safely Use Proper Ventilation If it is necessary to run an engine in an enclosed area, remove the exhaust fumes from the area with an exhaust pipe extension. If you do not have an exhaust pipe extension, make sure you open the doors and get outside air into the area.
  • Page 57 Perform Maintenance Safely Hydraulic System Hazards The hydraulic system is under pressure whenever the engine is operating and may hold pressure even after the engine is shut off. Cycle all hydraulic controls including the auxiliary hydraulic control after the engine is shut down.
  • Page 58 Perform Maintenance Safely Avoid Explosion WARNING! Avoid possible serious injury from explosion. Lead-acid batteries produce extremely explosive gases especially when being charged. Keep arcs, sparks, fl ames and lighted tobacco away. — Do not smoke near batteries. — Keep arcs, sparks and open fl ames away from batteries.
  • Page 59 Perform Maintenance Safely Tire And Wheel Maintenance (continued) WARNING! The types of wheels and tires usually found on this equipment require special care when servicing to prevent death or serious injury. Do not infl ate the tires above the recommended pressure.

  • Page 60: Final Word To The User

    Perform Maintenance Safely Mower Blade Maintenance (continued) — How are mower blades made? Mower blades are made of high strength alloy spring steel. They are hot-forged and shaped to meet the manufacturer’s individual specifi cations, then heat treated and tempered to a high strength, ductile state to reduce the possibility of breaking while mowing.

  • Page 62: Reconocimiento

    Contenido Reconocimiento Deseamos reconocer las contribuciones de los miembros del Consejo de Fabricantes de Cortadoras de Césped Industriales/para Agricultura para la preparación de este Manual de seguridad. Copyright, 2010, por la Asociación de Fabricantes de Equipos (Association of Equipment Manufacturers). Todos los derechos reservados. Queda prohibida la reproducción o difusión parcial o total de este trabajo por cualquier medio sin consentimiento previo por escrito de la Asociación de Fabricantes de Equipos.

  • Page 63: Alertas De Seguridad

    Alertas de seguridad Símbolo Este símbolo de alerta de seguridad signifi ca: “¡ATENCIÓN! ¡MANTÉNGASE ALERTA! ¡SU SEGURIDAD ESTÁ EN RIESGO!” El símbolo de alerta de seguridad identifi ca mensajes de seguridad importantes sobre el equipo, sobre letreros de seguridad, en manuales u otros lugares. Cuando vea este símbolo, manténgase alerta ante la posibilidad de muerte o lesiones personales.

  • Page 64: Cortadora De Césped Industrial/Para Agricultura

    Cortadora de césped industrial/para agricultura Tipos de cortadora de césped industrial/para agricultura Las cortadoras de césped se usan para recortar pasturas, desmenuzar residuos de cultivos, cortar arbustos, realizar desbroce pesado, cortar la hierba en vías de agua, derechos de paso, costados de caminos o autopistas. Además, estas cortadoras se usan para cortar la hierba y otras plantas en zonas públicas como parques y cementerios.

  • Page 65: Cumplimiento Del Programa De Seguridad

    Cumplimiento del programa de seguridad Protéjase a sí mismo Use la ropa de protección personal y los equipos de protección personal (PPE) que se le proporcionen o que requieran las condiciones del trabajo. SIEMPRE debe usar gafas de seguridad con escudos laterales. Puede necesitar también: —...
  • Page 66 Cumplimiento del programa de seguridad Evite las lesiones provocadas por equipos elevados Evite posibles lesiones de aplastamiento por caídas de la cortadora u otros equipos elevados. Evite ser aplastado – con seguridad la Antes de trabajar cerca o debajo de partes levadas de la cortadora o de los equipos: —...
  • Page 67 Cumplimiento del programa de seguridad ¡Manténgase alerta! Sepa dónde obtener asistencia. Sepa cómo usar un equipo de primeros auxilios y un extintor de incendios/ sistema de supresión de fuego. ¡Manténgase informado! Aproveche los programas de capacitación que se ofrecen. ¡Tenga cuidado! El error humano es causado por muchos factores: descuido, fatiga, sobrecarga, preocupación, desconocimiento de la máquina por parte del operador, fármacos y alcohol,...
  • Page 68 Cumplimiento del programa de seguridad Algunas reglas que debe cumplir al trabajar (continuación) — Únicamente personas cualifi cadas y autorizadas pueden manejar estos equipos. — Nunca permita que los niños jueguen en los equipos, viajen en ellos o los hagan funcionar. Los niños no están cualifi cados para manejar estos equipos.

  • Page 69: Preparación Para Una Operación Segura

    Preparación para una operación segura Revise los equipos de la cortadora de césped y el tractor Antes de comenzar la jornada de trabajo, inspeccione la máquina y asegúrese de que todos los sistemas estén en buenas condiciones operacionales. ¡ADVERTENCIA! Evite posibles lesiones por aplastamiento producidas por equipos que caen.
  • Page 70 Preparación para una operación segura Familiarícese con la zona de trabajo Antes de hacer funcionar la cortadora de césped, inspeccione cuidadosamente la zona de trabajo. Recorra a pie alrededor de la zona e inspeccione las superfi cies sobre las cuales se desplazará cuando utilice la cortadora. alrededor del lugar Localice y evite: —...
  • Page 71 Preparación para una operación segura Prueba de seguridad de los controles del tractor y de la cortadora de césped Arranque el tractor siguiendo los procedimientos específi cos del manual del operador del fabricante. Estos procedimientos normalmente incluyen: — Colóquese y ajústese el cinturón de seguridad en el tractor equipado con ROPS.
  • Page 72 Preparación para una operación segura Enganche de la cortadora de césped al tractor Cortadoras montadas en enganche de tres puntos: — Consulte los manuales de los fabricantes de la cortadora y del tractor. — Coloque la palanca selectora de elevación de potencia hidráulica del tractor en la posición descendida para evitar movimientos imprevistos.

  • Page 73: Arranque Con Seguridad

    Arranque con seguridad Cómo realizar un arranque correcto Corte la hierba únicamente con luz diurna o en condiciones de buena luz artifi cial. Evite lesiones graves o muerte producidas por objetos arrojados por la cortadora o por el contacto con las hojas: —...
  • Page 74 Operación con seguridad Objetos arrojados por la cortadora de césped (continuación) Cortadoras de disco — Cuando se usa una cortadora de disco, es importante conocer la zona donde se va a cortar. Si el operador ha realizado cortes en el terreno antes y está...
  • Page 75 Operación con seguridad Prácticas de seguridad para la cortadora de césped de montaje inferior Cuando se traslada con una cortadora de césped de montaje inferior: — Mantenga la rampa de descarga extraíble en su lugar y por encima de la abertura de descarga. —...
  • Page 76 Operación con seguridad Prácticas de seguridad para cortadoras de césped con laterales y montaje lateral Las posiciones elevadas de los laterales reducen la protección de los escudos y aumentan los riesgos de objetos arrojados y contacto con las hojas. Evite la posibilidad de lesiones graves o muerte por objetos arrojados o contacto con las hojas causados por la elevación y el descenso de los laterales durante las operaciones de corte:...
  • Page 77 Operación con seguridad Prácticas de seguridad para trabajos de corte en terrenos desparejos (continuación) — Use extremo cuidado para mantener el control de los equipos cuando trabaja en estas condiciones. — Aumente la estabilidad del tractor agregando pesos o lastre en las ruedas y aumentando al máximo la separación entre las ruedas.

  • Page 78: Estacionamiento Seguro

    Estacionamiento seguro Prácticas de seguridad para el estacionamiento — Use las zonas designadas o alejadas del tránsito. — Use lugares con suelo fi rme y nivelado. — Aplique el freno de estacionamiento. — Descienda el equipo de la cortadora de césped hasta el suelo.

  • Page 79: Realización De Mantenimiento Con Seguridad

    Apagado con seguridad Descenso correcto — Nunca descienda de equipos en movimiento. — Nunca baje de una máquina saltando. — Descienda con cuidado. — Verifi que que no haya peldaños resbaladizos. — Mantenga los pies y las manos lejos de los controles. —...
  • Page 80 Realización de mantenimiento con seguridad Preparación personal Use la ropa de protección personal y los equipos de protección personal (PPE) que se le proporcionen o que requieran las condiciones del trabajo. SIEMPRE debe usar gafas de seguridad con escudos laterales. Puede necesitar también: —...
  • Page 81 Realización de mantenimiento con seguridad Preparación de la máquina Deben controlarse o reducirse las fuentes de energía almacenada (eléctricas, mecánicas, hidráulicas, neumáticas, químicas, térmicas, etc.) al mínimo practicable antes de realizar cualquier procedimiento de mantenimiento, reparación o servicio. Prácticas de seguridad para prevenir posibles lesiones por fuentes que liberan energía: —...
  • Page 82 Realización de mantenimiento con seguridad Use ventilación adecuada Si es necesario hacer funcionar un motor en una zona cerrada, elimine del área las emanaciones de escape con una extensión del caño de escape. Si no tiene esa extensión, asegúrese de abrir las puertas y dejar entrar aire del exterior.
  • Page 83 Realización de mantenimiento con seguridad Riesgos del sistema hidráulico El sistema hidráulico se encuentra bajo presión siempre que el motor está funcionando; puede conservar presión incluso después de apagar el motor. Haga funcionar todos los controles hidráulicos incluyendo el control hidráulico auxiliar después de que el motor esté...
  • Page 84 Realización de mantenimiento con seguridad Evite explosiones ¡ADVERTENCIA! Evite posibles lesiones graves por explosiones. Las baterías de plomo-ácido producen gases sumamente explosivos, especialmente durante la carga. Mantenga alejados los arcos, las chispas, las llamas y el tabaco encendido. — No fume cerca de las baterías. —...
  • Page 85 Realización de mantenimiento con seguridad Mantenimiento de neumáticos y ruedas (continuación) ¡ADVERTENCIA! Los tipos de ruedas y neumáticos que generalmente se encuentran en estos equipos requieren cuidados especiales al realizar servicios para evitar lesiones graves o la muerte. No infl e los neumáticos por encima de la presión recomendada.

  • Page 86: Palabras Fi Nales Para El Usuario

    Realización de mantenimiento con seguridad Mantenimiento de las hojas de la cortadora (continuación) — ¿Cómo están hechas las hojas de la cortadora de césped? Están hechas acero para resortes de aleación de alta resistencia. Se forjan en caliente y se les da forma para cumplir con las especifi caciones individuales del fabricante;...

  • Page 87: Introduction Section

    INTRODUCTION SECTION Introduction Section 2-1...
  • Page 88 Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR INJURY. Identifies special instructions or procedures that, if not strictly observed, could result in damage to, or destruction of the machine, attachments or the environment. 148 02/11 © 2011 Alamo Group Inc. INTRODUCTION Introduction Section 2-2...

  • Page 89: Equipment Specifications

    The Rhino 148 Rotary Mower is designed for medium duty applications such as weed, grass, corn stalks, and light brush to 1-1/2” diameter. These mowers are single spindle with two free-swinging blades. Free swinging blades reduce the shock of impact when a stationary object is hit. Additional protection is provided by a slip clutch on the gearbox input shaft.

  • Page 90: Key Operation Points

    B. Shield Bearings are wearing parts and are not warrantable. C. Slip-Clutch Disks are wearing parts and are not warrantable. Evidence of “burning up” Slip Clutch Plates due to improper adjustment will void warranty on Slip Clutch Parts. 148 02/11 © 2011 Alamo Group Inc. INTRODUCTION...

  • Page 91: Rhino Limited Warranty

    ATTENTION: Purchaser should fill in the blanks below for his reference when buying repair parts and/or for proper machine identification when applying for warranty. Rhino Implement Model________________________________ Serial Number________________________ Date Purchased______________________________________ Dealer_______________________________ ATTENTION: READ YOUR OPERATOR'S MANUAL 148 02/11 © 2011 Alamo Group Inc. INTRODUCTION ® RHINO 1020 S Sangamon Ave.

  • Page 93: Assembly Section

    ASSEMBLY SECTION Assembly Section 3-1...

  • Page 94: Dealer Setup Instructions

    (torque to 33 ft. labs.) Attach cotter pin (#5) through top shield (#1) from outside in. Attach shield (#1) to top bracket (#2) and secure with flatwasher (#3 not shown) and nut (#4). Figure AsmP-R-0016. 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY Assembly Section 3-2...

  • Page 95: Shear Bolt Driveline Installation

    (7). Secure with 3/ 4” locknut (9). 4. Assemble driveline support flat (15) and retain using 1/2’ x 1-1/2” bolt (10) and locknut (9). 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY Assembly Section 3-3...

  • Page 96: Tail Wheel Installation (Standard Or Quick Hitch)

    Cat. I kit requires a 3/4” diameter bolt. Install top end of check chains in brackets (2). Cutting height is then set by placing proper chain link in keyhole slot. Cutting height is easily adjustable hooking chain higher or lower in the keyhole brackets (2). 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY...

  • Page 97: A-Frame Installation (Quick Hitch)

    4. Insert 1/2” x 2 bolt (10) through flex links (7), rear braces (5) and bushing (28) inserted in rear braces. 5. Insert 1/2” x 2 bolt (10) through rear holes in flex link (7) with bushing (28) between and above rear braces. Figure Asm-R-0317 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY...

  • Page 98: Front And Rear Deflectors (Standard Equipment)

    Attach the Front Deflector to the Mower with 1/2” x 1-1/2” Bolts, Flatwashers, and Locknuts. Rear Deflector Attach Deflectors to deck using 1/2” x 1-1/4” Bolts and Locknuts (6). 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY Assembly Section 3-6 Assy01-...

  • Page 99: Offset Adapter Hitch (Extra Equipment)

    Raise the mower to check clearance between the Driveline and Mower Deck. Set the lift stop on the tractor to ascertain that the Driveline does not strike the deck. 148 02/11 © 2011 Alamo Group Inc. ASSEMBLY Assembly Section 3-7...

  • Page 101: Operation Section

    OPERATION SECTION Operation Section 4-1...
  • Page 102 RHINO 148 ROTARY MOWER OPERATION INSTRUCTIONS Rhino 148 rotary mowers are manufactured with quality material by skilled workers. These mowers are designed to cut grass, weeds, small brush and other vegetative material up to 1-1/2” diameter in areas such as pastures, industrial areas, and roadsides.

  • Page 103: Operator Requirements

    Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 104: Tractor Requirements

    Maintain all manufacturer equipped safety shields and guards. Always replace shields and guards that were removed for access to connect, service, or repair the tractor or implement. with the PTO master shield missing or in the raised position. OPS-U- 0004 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 105: Tractor Horsepower

    The tractor 3-point hitch must be rated to lift at least 410 lbs. The 148 mower is designed to be mounted on a tractor with a CAT I 3-point hitch or CAT I Quick Hitch. Refer to the tractor operator’s manual for the category of the tractor being used.

  • Page 106: Power Take Off (Pto)

    Refer to the tractor Operator’s Manual or consult an authorized dealer for instructions to change tractor tire spacing. OPS-R- 0062 148 02/11 © 2011 Alamo Group Inc. OPERATION Operation Section 4-6 (S3PT-16)

  • Page 107: Getting On And Off The Tractor

    Use hand rails and steps when exiting the tractor. Be careful of your step and use extra caution when mud, ice, snow or other matter has accumulated on the steps or hand rails. Use all handrails and steps for support and never rush or jump off the tractor. OPS-U- 0009 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 108: Starting The Tractor

    Start tractor only when properly seated in the Tractor seat. Starting a tractor in gear can result in injury or death. Read the Tractor operators manual for proper starting instructions. 148 02/11 © 2011 Alamo Group Inc. OPERATION (SG-9)

  • Page 109: Connecting The Mower To The Tractor

    Note: Offset Adaptor Hitches are available to position the mower to the left or right. Mowers with Offset Adaptor hitches connect to the 3-Point hitch the same way as the mower A-frame. See Offset Adaptor Hitch in the Assembly Section for details to equip the mower with this feature. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 110: Connecting Mower - Lift Type (Quick Hitch)

    3-point hitch pins. IMPORTANT: Make certain the implement’s top 3- point hitch pin is captured by the Quick-Hitch top 3- point hook. If not consult your Quick Hitch manual for required adjustment. 148 02/11 © 2011 Alamo Group Inc. OPERATION mounting than...

  • Page 111: Safety Tow Chain

    Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death. 148 02/11 © 2011 Alamo Group Inc. OPERATION (SG-14)

  • Page 112: Setting Mower Height- Lift Type - (Standard Or Quick Hitch)

    3-Point lift maintaining a set height or when a constant pre-adjusted cut height is required. See Check Chains in the Assembly Section for this accessory. 148 02/11 © 2011 Alamo Group Inc. OPERATION Shortening or Operation Section 4-12...

  • Page 113: Setting Deck Pitch

    Adjust the leveling rods the same amount and maintain equal tension in the rods. Improper adjustment may cause rods to snap or bend. Retighten the jamnuts after the deck pitch has been set. OPS-U-0041 148 02/11 Operation Section 4-13 © 2011 Alamo Group Inc.

  • Page 114: Driveline Attachment

    At its shortest length, there must be at least a 1” clearance between each profile end and opposite profile universal joint. At its farthest operating extension, a minimum profile engagement of 10” must be maintained. 148 02/11 © 2011 Alamo Group Inc. OPERATION...
  • Page 115 NOTE: If the driveline cannot be shortened and still maintain the required profile engagement, the operator must be made aware of terrain conditions and avoid situations which pose a potential problem to avoid damaging the driveline. OPS-R- 0005 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 116: Pre-Operation Inspection And Service

    Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order. 148 02/11 © 2011 Alamo Group Inc. OPERATION (S3PT-11)

  • Page 117: Tractor Pre-Operation Inspection/Service

    Ensure the manual canister is secured to the equipment with the operator’s manual inside. • Ensure all safety signs are in place and legible. Replace missing, damaged, and illegible decals. OPS-U- 0011 148 02/11 © 2011 Alamo Group Inc. OPERATION The following Operation Section 4-17...
  • Page 118 148 02/11 © 2011 Alamo Group Inc. OPERATION Missing, broken, or...
  • Page 119 Replace damaged, worn and missing blades as complete sets to maintain rotary balance during operation. • Ensure blade pan nut is tightened with the cotter pin inserted and spread. OPS-R-0041 148 02/11 © 2011 Alamo Group Inc. OPERATION Operation Section 4-19...

  • Page 120: Cutting Component Inspection

    OPERATION 8.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: 148 02/11 Operation Section 4-20 © 2011 Alamo Group Inc.
  • Page 121 Failure to replace abnormally worn blades may lead to catastrophic failure of the blades and ejection of the broken part with tremendous force which may cause serious bodily injury or death. OPS-U-0032 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 122: Blade Bolt Inspection

    Failure to replace abnormally worn blade bolts may lead to catastrophic failure of the blades and ejection of the broken part which may cause serious bodily injury or death. Always replace Blade Bolts with new bolts whenever replacing the Blades. OPS-U-0037 148 02/11 © 2011 Alamo Group Inc. OPERATION...
  • Page 123 The engine coolant fluid level is full The radiator is free of debris The air filter is in good condition Operator’s Signature: DO NOT OPERATE an UNSAFE TRACTOR or MOWER 148 02/11 © 2011 Alamo Group Inc. OPERATION Make ____________________ ________________...
  • Page 124 Blades are not chipped, cracked or bent Blade bolts are tight Wheel lug nuts are tight Transport locks are in good condition Operator’s Signature: DO NOT OPERATE an UNSAFE TRACTOR or MOWER 148 02/11 © 2011 Alamo Group Inc. OPERATION Make ____________________ ________________ Shift...

  • Page 125: Driving The Tractor And Implement

    When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 126: Starting The Tractor

    When operating in traffic, always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 127: Raising The Mower

    Use extreme caution when operating on steep slopes. Keep the tractor in a low gear when going downhill. DO NOT coast or free-wheel downhill. OPS-R-0019 148 02/11 © 2011 Alamo Group Inc. OPERATION When OPS-R-0042...

  • Page 128: Crossing Ditches And Steep Inclines

    When crossing such terrain, the implement should be fully lowered for a lower center of gravity and added stability. OPS-R-0021 148 02/11 © 2011 Alamo Group Inc. OPERATION Operation Section 4-28...

  • Page 129: Operating The Tractor And Implement

    Stop mowing immediately if blades strike a foreign object. Repair all damage and make certain rotor or blade carrier is balanced before resuming mowing. 148 02/11 © 2011 Alamo Group Inc. OPERATION Inspect the area before (SGM-05)

  • Page 130: Foreign Debris Hazards

    If a bystander comes within 300 feet of the tractor while the mower is being operated, stop the tractor at once, idle the engine and disengage the PTO. Do not engage the PTO again until all bystanders are well past the 300 foot distance. OPS-R-0024 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 131: Engaging The Power Take Off (Pto)

    Do not put hands or feet under mower decks. Blade Contact can result in serious injury or even death. Stay away until all motion has stopped and the decks are securely blocked up. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 132: Pto Rpm And Ground Speed

    When mowing in reverse, operate the tractor and mower at a reduced ground speed to ensure tractor and mower control is maintained. OPS-R-0026 148 02/11 © 2011 Alamo Group Inc. OPERATION...
  • Page 133 -Never allow clippings or debris to collect near drivelines, slip clutches, and gearboxes. Periodically shut down the Tractor and Mower and clean clippings and collected debris from the mower deck. (SGM-12) 148 02/11 © 2011 Alamo Group Inc. OPERATION (SGM-1)
  • Page 134 In such conditions, raise the cutting height to 12” or more on the first pass OPS-R-0043 148 02/11 © 2011 Alamo Group Inc. OPERATION Never raise the Operation Section 4-34...
  • Page 135 Stay alert and watch for trees, low hanging limbs, power lines, and other overhead obstacles and solid ground objects while you are operating. to avoid hitting these items OPS-R-0028_A 148 02/11 © 2011 Alamo Group Inc. OPERATION If possible, Use care...

  • Page 136: Right Of Way (Highway) Mowing

    Mower sections or wings are adjusted to be close and parallel to ground without exposing blades. • MOWING AREA has been inspected and foreign materials and debris have been removed. • PASSERSBY are inside enclosed vehicle. 148 02/11 © 2011 Alamo Group Inc. OPERATION OPS-U-0040 Operation Section 4-36...

  • Page 137: Shutting Down The Implement

    Use extreme care to keep feet and hands from under the mower and clear of any pinch points caused by the tractor hitch arms and mower pins. OPS-R-0030_A 148 02/11 Operation Section 4-37 © 2011 Alamo Group Inc.
  • Page 138 Use the Tongue Jack for lifting the Implement only. Overloading the Tongue Jack can cause failure with possible serious bodily injury or even death. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 139: Mower Storage

    By using good judgement and following safe transport procedures, the possibility of accidents while moving between locations can be substantially minimized. OPS-U- 0017 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 140: Tire And Wheels

    Transport speed for laminated tires should not exceed 15 MPH. Excessive speed can cause damage to the machine and tire sections. Sectional tires must be installed such that the rubber segments lay with the ground. OPS-R-0035_A 148 02/11 © 2011 Alamo Group Inc. OPERATION NOTE:...

  • Page 141: Transporting On Public Roadways

    Consult an authorized tractor dealer for lighting kits and modifications available to upgrade the lighting on older tractor models. OPS-U- 0021 148 02/11 © 2011 Alamo Group Inc. OPERATION Remember that roadways are primarily designed for (SG-6)

  • Page 142: Hauling The Tractor And Implement

    If during transport a hard braking, sharp turning or swerving action was performed, stop at the next safe location to inspect the security of the load. 148 02/11 © 2011 Alamo Group Inc. OPERATION...

  • Page 143: Troubleshooting Guide

    Distribution Excessive ground speed Conditions too wet. Blade Bolts Working Loose Bolts not tightened. Bolt hole elongated or oversized. Locknut worn out. 148 02/11 © 2011 Alamo Group Inc. OPERATION Remedy Reduce ground speed. Replace blades. (Refer to “Maintenance” section).
  • Page 144 Not using proper pin. PTO engaged at high engine RPM Cutting in rocky conditions Blade carrier RPM too high. Blades not properly heat treated. 148 02/11 © 2011 Alamo Group Inc. OPERATION Check lubricant level. Run in or change Gears.

  • Page 145: Maintenance Section

    MAINTENANCE SECTION Maintenance Section 5-1 © 2011 Alamo Group...

  • Page 146: Hazards With Maintenance Of Implement

    California to cause cancer, birth defects or other reproductive harm. • Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the state of California to cause cancer, birth defects or other reproductive harm. 148 02/11 © 2011 Alamo Group MAINTENANCE CONDITION...

  • Page 147: Parts Information

    Use Multi-Purpose Gear Oil P/N 00786250 when required in Gearbox. Use N.L.G.I #2 grease for all locations designated with grease gun. Be sure to clean the fitting thoroughly before using grease gun. Failure to maintain proper lubrication will result in damage to U-joints, gearbox, and/or driveshaft. Figure Mnt-R-0333 148 02/11 © 2011 Alamo Group MAINTENANCE...
  • Page 148 MAINTENANCE 148 02/11 Maintenance Section 5-4 © 2011 Alamo Group...

  • Page 149: Gearbox Lubrication

    Nylon Nuts back in through the aligned slots and turn until it is perpendicular to the slots. Add the other two Nylon Nuts. Make certain that the Driveline Integral Shields are free to telescope and rotate around the driveline without binding. 148 02/11 © 2011 Alamo Group MAINTENANCE Grease...

  • Page 150: Shear Pin Yoke Lubrication

    Failure to lube may cause yoke to gall and spin weld to shaft. Applying a small amount of grease to shear pins will greatly prolong life of yoke. 148 02/11 Maintenance Section 5-6 © 2011 Alamo Group...

  • Page 151: Blade Servicing

    NOTE: Replace Blades in pairs after no more than 1/2” notch wear. 148 02/11 © 2011 Alamo Group MAINTENANCE...

  • Page 152: Blade Sharpening

    Use a suitable 2 jaw gear puller to pull carrier off tapered gearbox shaft. If gear puller is not available use long bar inserted through blade bolt access hole with end against rotor bar. Strike opposite end of bar with sledge hammer. Rotate blade carrier 180 degrees and repeat process. 148 02/11 © 2011 Alamo Group MAINTENANCE...

  • Page 153: Blade Carrier Inspection

    148 02/11 © 2011 Alamo Group MAINTENANCE...

  • Page 154: Blade Removal

    See Figure MntP-R-0057. Always replace nut when replacing blade bolt. When installing blades be sure and check blade bolt pivot diameter for wear. Replace bolt if worn more than 1/ 4 inch at any point. Tighten lock nut to 450 ft. lbs. 148 02/11 © 2011 Alamo Group MAINTENANCE...

  • Page 155: Blade Bolt Inspection

    Failure to replace abnormally worn blade bolts may lead to catastrophic failure of the blades and ejection of the broken part which may cause serious bodily injury or death. Always replace Blade Bolts with new bolts whenever replacing the Blades. OPS-U-0037 148 02/11 © 2011 Alamo Group MAINTENANCE...

  • Page 156: Slip Clutch

    148 02/11 © 2011 Alamo Group MAINTENANCE Missing, broken, or...

  • Page 157: Storage

    NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are used. This applies to both UNF fine and UNC coarse threads. 148 02/11 © 2011 Alamo Group MAINTENANCE...
  • Page 158 MAINTENANCE 148 02/11 Maintenance Section 5-14 © 2011 Alamo Group...
  • Page 159 372-9529 contacto ponerse seguridad seccion 1-18 pagina RHINO partes seguridad. peligro puede auténticas partes Partes RHINO. especificaciones línea componentes rodillos, portadores para seleccionado 1-14 Seguridad Sección (830) Fax: 78155; Seguin, Street favor español completamente referirse porfavor español DISTRIBUIDOR CONTACTE seguridad. economía (SPRM-1 presentar...
  • Page 160 reproductivos. HM01 California estado plomo, componentes reproductivos. daños otros nacimiento agentes emiten contienen vehículo elementos gastado. antideslizantes. caja cubiertas acero, protectores cadena, SEGURIDAD: rígidas. superficies suelde nuevas. cuchillas movimiento. desgaste. filtraciones, sueltos ajustes rotas, DESCRIBEN MANTENIMIENTO componentes fallas vibraciones equipos. componentes químicos.
  • Page 161 TH02 curvas. uniformes, poco irregulares superficies cortadora. vuelco. puede determinar para curvas TERRENO CARRETERAS hora millas PARA IMPLEMENTO TRACTOR central. SEGURIDAD: CADENA cortadora. para clara visión tener para implemento implemento, cabina tractor, operación adecuada para advertencia adecuadas. condiciones funcionamiento segura. forma dirección mantener...
  • Page 162 cortadora, conducción calentamiento excesivo deslizamiento objetos contacto entre cortadora quemadas bastidor vegetación: cortadora servicio reparación subterráneos. municipales. servicios cables todos distancia tipo. otro subterráneos, eléctricos alimentación SERVICIOS: LÍNEAS ELÉCTRICO CONTACTO 1-11 Seguridad Sección combustible. EF02 cambios. líneas alrededor acumulado residuo evitar para DESLIZANTES...
  • Page 163 médico inmediato hidráulico. fluido eyección boquillas HIDRÁULICOS: SISTEMAS VISIBLES. verifique distribuidor sistema. trabajar antes AJUSTADAS ESTADO BUEN combustible. FILTRACIONES PENETRACIÓN PRESIÓN ALTA HIDRÁULICO MB01 cortadora acercarse antes SONIDOS alas cortadora detenido. líneas giratorias, cuchillas CUERPO GRAVES LESIONES EVITAR PARA CORTADORA 1-10 Seguridad Sección...
  • Page 164 trabajo longitud aumento cuchillas fallas objetos, coincide implemento semanal. conducción. línea caer hacer PTO. romper soporte solidificará. deslizará cambios caja operaciones: mantenimiento. reparación tareas faltan. colocados cubiertas conducción IMPLEMENTO: OPERAR PTO. cortadora acercarse antes SONIDOS detenido. líneas giratorias, cuchillas MUERTE: ELEMENTOS OTROS CONDUCCIÓN...
  • Page 165 detengan espere implemento, detenidos. equipos. para SEGURIDAD CINTURONES ATROPELLO TRACTOR CAÍDA Seguridad Sección tractor. bajarse antes RO01 descienda mano, freno coloque estén móviles partes éste implemento. tractor tractor. asiento sentado tractor operar seguridad tractor. asiento vertical. posición trabado (ROPS) ANTIVUELCO SISTEMA MUERTE GRAVES...
  • Page 166 dañadas TO02-X vibración EXCESIVA: transporte. posición cortadora adelante. CUCHILLAS. dañado. está gran arrojados pueden objetos pesados, objetos contacto transporte. fijas. obstrucciones sólidos, objetos CUCHILLAS cuchillas exponer suelo mismo operando cortadoras vegetación. sean elementos Seguridad Sección dobladas CUCHILLAS dañada fuente detectar para tractor.
  • Page 167 como SÓLIDOS OBJETOS CONTACTO OBJETOS riesgo posible ELIMINAR cuchillas antideslizantes zapatas pro- posibilidad reducir Para arrojados. cortadora. donde verde cinturón cortes parques dañados. están éstos faldones bandas, acero, protectores entre cortadora, operar funcionamiento gran plataforma desprendidos área. extraños OBJETOSQUE POSIBILIDAD DETECTAR residuos.
  • Page 168 equipo. alejarse alrededores. EQUIPO: equipo. alejarse debajo cuerpo pies manos, poner elevados. componentes implementos componentes debajo palanca inesperado movimiento aplastamiento. accidentes tractor tracción barra ajustada ajustado. seguridad cinturón equipos. operaciones para SEGURIDAD IMPLEMENTO: APLASTAMIENTO, TRACTOR, Seguridad Sección CH02 operador. lesión gato pesados.
  • Page 169 CD02 tractor. transmisión enredo riesgo implica conducción opera- velocidad duplicación consecuencia tractor: coincide PTO. romper solidificará. deslizará implemento. cambios caja para implemento tractor FUERZA(PTO) sobre libremente operación: lengüeta movimiento controlar llave. saque mano freno TRACTOR APLASTAMIENTO IMPLEMENTO Seguridad Sección conectada directamente línea desprotegidas...
  • Page 170 OS01 fallas conducción línea roturas PROTECTORAS PRENDAS obstrucciones desniveles, pozos, empinadas, altura densidad césped, tipo obstrucciones desniveles, pozos, (100 metros más nítida visibilidad DESCANSE. PAUSA HAGA sentidos. sobre medicación alcohol. drogas equipo. lesión. causar giratorias contraer evitar polvorientas equipo reparar operar guantes Mensajes...
  • Page 171 ruso. alemán, francés, GS01 372- (830) Fax: 78155; Seguin, idiomas, siguientes alguno evitar para común graves lesiones Manual este Seguridad. eficiente más reparación operación accesorios maquinaria, destrucción observarse que, específicos OCASIONAR PODRÍA evitada, OCASIONAR PODRÍA evitada, OCASIONARÁ evitada, seguras. prácticas puede USTED Sólo...
  • Page 172 Seguridad Sección SEGURIDAD SECCIÓN...
  • Page 174 Cortadora Seguridad (entregado Cortadora ADMA Conducción Línea (instalada) seguridad operación) (instalación necesario) (instalado (instalado) tractor (entregado) (colocados) seguridad ajuste) (limitador conducción instalación) SEGURIDAD ajustadas bien montaje altura) (ajuste máx.) giro radio (verificar C.V. elevación operación (verificar centro) nivel (ajustar montaje pre-operación (ajustar) iguales)
  • Page 175 distribuidor:________________ distribuidor:________________ serie:_______________________ solicitante:______________________________Teléfono:_________________ formato – AEM/FEMA formato – AEM/FEMA Cortadoras Video suministrar AEMVideo@alamo-group.com Dirección distribuidor:_________________ compra:______________________Vendedor Número cortadora:___________________ postal:____________________________ Estado:__________________________________ Ciudad:__________________________________ solicitante:_________________________________ Cortadora Operador Cortadora Cortadoras Operador para Cortadoras Operador para para Seguridad dispuesto cortadora electrónico correo 372-9529 (830) 78155 Seguin, Street...
  • Page 176 implicado estará esté, practicas implemento eso, después anualmente pieza código Operador. asistir puede Operador Manual comprender cortadora), VHS. versión solicite 78155, encuentra formulario AEMVideo@alamo- electrónico Group Alamo acerca pregunta alguna comprende nueva. cortadora video, mire video: copia entregado haya importante. aprendizaje advertencia mensajes...
  • Page 177 compra: adquirido. RHINO seguridad. maximizar esentar garantía anular especificaciones. estas cumplen según prueban fabrican ganchos hojas, corte, ejes cuchillas, utilizan Rhino cortadoras Partes. correctamente implemento riba trase frontal, cabalmente comprender para desempeño satisfacción comprendido haya manual. este totalidad comprendido antes manual este seguridad...
  • Page 178 $0.00 C01-Cover equipo. operar Instrucciones SIGA máquina esta segura operación 00781398C nº. Parte GIRATORIA CORTADORA/TRITURADORA Inc. Group Alamo ©2011 antes manual este contenidas ENTIENDA, LEA, siempre. unidad esencial parte OPERADOR MANUAL parts@servis-rhino.com 800-446-5158 60936 Ave. Sangamon Operación Seguridad mantener debe Operador Manual Este...

Table of Contents

Save PDF
