RHINO 00781400C Operator's Manual

Rotary mower
Table of Contents
  • Español

    • Introducción
    • Reconocimiento
    • Alertas de Seguridad
    • Palabras para el Usuario/Operador
    • Cortadora de Césped Industrial/Para Agricultura
    • Cumplimiento del Programa de Seguridad
    • Preparación para una Operación Segura
    • Arranque con Seguridad
    • Operación con Seguridad
    • Apagado con Seguridad
    • Estacionamiento Seguro
    • Realización de Mantenimiento con Seguridad
    • Palabras Fi Nales para el Usuario
    • Introduction Section

      • Equipment Specifications
      • Operating Noise Level/Sound Pressure
      • Warranty Information
      • Key Operation Points
      • Rhino Limited Warranty
    • Assembly Section

      • Dealer Setup Instructions
      • Shield Assembly
      • TAIL WHEEL INSTALLATION (Standard or Quick Hitch)
      • A-FRAME INSTALLATION (Standard Hitch)
      • A-FRAME INSTALLATION (Quick Hitch)
      • SHEAR BOLT or SLIP CLUTCH DRIVELINE INSTALLATION
      • Front and Rear Deflectors (Standard Equipment)
      • Front Rubber Fabric Deflectors
      • Rear Deflector
      • CHAIN GUARDS (Optional Equipment)
      • Front Chain Guards
      • Rear Chain Guard
      • CHECK CHAINS (Extra Equipment)
      • Offset Adapter Hitch (Extra Equipment)
    • Operation Section

      • Operation Instructions
      • Operator Requirements
      • Personal Protective Equipment (Ppe)
      • Tractor Requirements
      • ROPS and Seat Belt
      • Tractor Safety Devices
      • Tractor Requirements and Capabilities
      • Tractor Horsepower
      • Point Hitch
      • Front End Weight
      • Power Take off (PTO)
      • Tire Spacing
      • Getting on and off the Tractor
      • Dismounting the Tractor
      • Boarding the Tractor
      • Connecting the Mower to the Tractor
      • Starting the Tractor
      • Connecting Mower-Lift Type
      • Connecting Mower - Lift Type (Quick Hitch)
      • Point Quick Hitch
      • Setting Mower Height- Lift Type - (Standard or Quick Hitch)
      • Setting the Mower
      • Safety Tow Chain
      • Driveline Attachment
      • Setting Deck Pitch
      • Driveline Length Check
      • Pre-Operation Inspection and Service
      • Tractor Pre-Operation Inspection/Service
      • Mower Pre-Operation Inspection/Service
      • Cutting Component Inspection
      • Blade Bolt Inspection
      • Driving the Tractor and Implement
      • Brake and Differential Lock Setting
      • Starting the Tractor
      • Driving the Tractor and Mower
      • Raising the Mower
      • Crossing Ditches and Steep Inclines
      • Operating the Tractor and Implement
      • Bystanders/Passersby Precautions
      • Foreign Debris Hazards
      • Engaging the Power Take off (PTO)
      • PTO RPM and Ground Speed
      • Operating the Mower
      • Right of Way (Highway) Mowing
      • Disconnecting the Mower from the Tractor
      • Shutting down the Implement
      • Transporting the Tractor and Implement
      • Mower Storage
      • Tire and Wheels
      • Transporting on Public Roadways
      • Hauling the Tractor and Implement
      • Troubleshooting Guide
    • Maintenance Section

      • Hazards with Maintenance of Implement
      • Parts Information
      • Lubrication
      • Gearbox Lubrication
      • Comer Gearbox
      • Driveline Lubrication
      • Shear Pin Yoke Lubrication
      • Blade Servicing
      • Blade Sharpening
      • Blade Carrier Inspection
      • Blade Carrier Removal
      • Blade Carrier Installation
      • Blade Removal
      • Blade Bolt Inspection
      • Slip Clutch
      • Storage
      • Proper Torque for Fasteners
      • Seasonal Clutch Maintenance

Advertisement

Published 02/11
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
®
RHINO
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
OPERATOR'S MANUAL
© 2011 Alamo Group Inc.
